AD120-DC / AD60-DC
120 / 60W DC to DC board and 120 / 60W AC to DC adapter combo kit
Maximum Output of 120W / 60W
120 / 60W DC-DC power board with 120 / 60W 12V efficiency level VI AC-DC Power Adapter & power cord
Mylar insulation design, easy to install
Black wire design
Built-in multiple protection circuitry for maximum protection during operation
Advertisement
Table of Contents
Related Manuals for SilverStone AD120-DC
Summary of Contents for SilverStone AD120-DC
- Page 1 AD120-DC / AD60-DC 120 / 60W DC to DC board and 120 / 60W AC to DC adapter combo kit Maximum Output of 120W / 60W 120 / 60W DC-DC power board with 120 / 60W 12V efficiency level VI AC-DC Power Adapter & power cord...
-
Page 3: Specification
SPECIFICATION Adapter Series SST-AD60-DC SST-AD120-DC 60W / 120W WATTS SWITCHING POWER SUPPLY with AC adapter A. DC Board 1.0 INPUT: 1.1 VOLTAGE MINIMUM NOMINAL MAXIMUM UNITS 11.4 12.6 1.2 CURRENT AD60-DC 12Vdc / 6.0A max AD120-DC 12Vdc / 12.0A max 1.3 POWER EFFICIENCY... - Page 4 2.0A LOAD4 7.0A 2.5A 1.0A 0.1A 0.5A LOAD5 3.0A 7.0A 1.5A 0.1A 0.5A LOAD 6 0.0A 0.0A 5.0A 0.0A 0.0A AD120-DC Voltage +3.3V +12V -12V +5Vsb ＊ 12.0A 12.0A 10.0A 0.15A 3.0A Max load ＊ +5,-5 ﹪ ﹪ +5,-5 ﹪...
-
Page 5: Remote On/Off
＊1 When input voltage 11.4~11.8V regulation +5,-10﹪of +12Vdc output. ＊2 The continuous total output power is 60W max. •Total combined +12V output load not exceed 5.0A ＊3 Add 0.1uF and 10uF capacitors across output terminal during ripple & noise test. ＊4 LOAD REGULATION TEST TABLE: +3.3V +12V... - Page 6 : 10A max. 3.2 UNDER VOLTAGE PROTECTION AD60-DC +3.3V output 2.4 Vmax. +5.0V output 3.7 Vmax. +12.0V output 9.5 Vmax. AD120-DC +3.3V output 2.0 Vmax. +5.0V output 3.3 Vmax. +12.0V output 8.5 Vmax. 3.3 OVER VOLTAGE PROTECTION +3.3V output 4.1 Vmax.
- Page 7 20% to 90%,non-condensing 4.4 STORAGE HUMIDITY 5% to 95%, non-condensing 4.5 OPERATING ALTITUDE 0 to 10,000feet 4.6 STORAGE ALTITUDE 0 to 50,000 feet 5.0 MTBF at 25°C(demonstrated) 100K hrs minimum 6.0 DIMENSIONS AD60-DC DC board dimension: WxLxH=148.5x30x25mm AD120-DC DC board dimension: WxLxH=160x45x25mm...
-
Page 8: Input Voltage Range
B. AC adapter 1.0 Input voltage range Power supply shall operate within specification from 90 to 264Vrms or provide automatic switching in two ranges. The table below shows common input voltage range. Input Range Minimum Nominal Maximum Unit 100 -240 Vac, rms Input current Maximum steady state input current shall not exceed 1.7 A for any line voltage specified... - Page 9 120W Output power Unit total output power, under steady state conditions, shall not exceed 120 W . Output voltage and current Under any combination of line and load variation and environmental conditions, all outputs shall remain within tolerance defined in Table 2. Output voltage(s) shall be measured at the load side of output connector.
- Page 10 Test condition Over current protection Output Voltage Lower Limit Upper Limit Input voltage:100Vac 60Hz or 240Vac 5.80 A 9.00A +12.0V 50Hz. Table 4 –Over current protection 120W Over current protection shall be operated within specify 14.5A (min) ~ 20A (Max) , defined in section 2.3.1 at 100~240Vac line input or temperature conditions.
-
Page 11: Installation
Installation Step 1: Place the 120W DC to DC power board in the Шаг 1: Поместите плату питания 120 Вт chassis and secure it with screws. (Put the transparent DC - DC в корпус и закрепите её винтами. Mylar sheet at the back) (Положите... - Page 12 Installation Step 2: Connect 24pin to 20+4pin cable to the 120 W Шаг 2: Подключите кабель 24pin - 20+4pin к DC to DC power board. (Connect 20+4pin cable to the плате 120 Вт DC - DC. (Подключите кабель motherboard, 24pin cable to the DC board) 20 + 4pin к...
- Page 13 Installation Step 3: Connect CPU connector, 20+4pin connector, Шаг 3: Подключите коннектор питания and other cables to the device. процессора, коннектор 20 + 4pin и другие кабели к устройству. Schritt 3: Verbinden Sie den CPU-Anschluss, den 步驟3:將CPU,20+4pin及其他相關線材連接到裝置 20+4-Pin-Anschluss und andere Kabel mit dem Gerät. Étape 3 : Raccordez le connecteur du processeur, le 步骤3:将CPU,20+4pin及其他相关线材连接到装置...
- Page 14 Installation Step 4: Connect the internal power cord to the Шаг 4: Подключите внутренний кабель питания DC to DC board, and secure the DC jack connector к плате DC - DC, изакрепите коннектор DC в in the chassis with screws. корпусе...
- Page 15 Installation Step 5: Make sure every cable is connected. Шаг 5: Убедитесь, что все кабели подключены. Schritt 5: Stellen Sie sicher, dass alle Kabel 步驟5:確認所有線材均已經連接完成 angeschlossen sind. Étape 5 : Assurez-vous que tous les câbles sont raccordés.. 步骤5:确认所有线材均已经连接完成 Paso 5: Asegúrese de que cada cable está conectado. ステップ5: ケーブル全部が接続されたことを...
- Page 16 Installation Step 6: Connect the AC adapter to the DC cable to Шаг 6: Подключите адаптер AC к кабелю DC, complete the installation. чтобы завершить установку. Schritt 6: Verbinden Sie zum Abschließen der Installation 步驟6:將AC adapter連接至DC線完成安裝 das Netzteil mit dem Gleichspannungskabel. Étape 6 : Raccordez l’adaptateur CA au câble CC pour 步骤6:将AC adapter连接至DC线完成安装...
- Page 17 Replacement product will be warranted for remainder of the warranty period or thirty days, whichever is longer. All products should be sent back to the place of purchase if it is within 30 days of purchase, after 30 days, customers need to initiate RMA procedure with SilverStone Technology in USA by first downloading the “USA RMA form for end-users”...
- Page 18 (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. The power supply is only suitable for Information Technology & Audio/Video equipment. ※付属の電源コードは当該製品専用です。他の機器に使用しないでください。 Please refer to SilverStone website for latest specifications updates.
- Page 20 G11240920...
