KV-9PT50/60
MOUNTING BRACKET
10 3/8"
MIN. TO THE WALL
NOTE:
WHERE THERE ARE CLOSE TOLERANCES
OR APPLICATIONS WHICH REQUIRE A GREAT DEGREE OF PRECISION
RECOMMEND THAT THE PRODUCT ITSELF
MEASUREMENTS.
IN THE DESIGN OR MANUFACTURE OF ENCLOSURES .
Sony Electronics Inc • Consumer Integrated Systems • Park Ridge, New Jersey 07656 • FAX (201) 930-7891
Features and specifications subject to change without notice. • Non-metric weights and measurements are approximate.
MODEL:
DESCRIPTION:
DESCRIPTION:
DIMENSIONS
DIMENSIONS
(WHD):
(WHD):
WEIGHT:
1/4 inch = 1 inch Scale 4:1
5 3/4"
6 1/8"
5 3/4"
4"
NOTE: MOUNTING BRACKET ON KV9PT50 ONLY!
SONY WILL NOT BE RESPONSIBLE FOR
9'" Trinitron
Monitor /Receiver
10 1/4" x 11 1/2" x 12 1/8"
12 Lbs 9 oz
7 1/8"
7 1/2"
2 1/8"
+
+
-
-
6"
10 1/4"
12 1/8"
INVOLVED IN CABINET BUILDING
BE USED TO MAKE THE ACTUAL
®
POWER
REQUIREMENTS:
POWER
CONSUMPTION:
53 Watts
FRONT
VIEW
4 1/2"
REMOTE SENSOR
10 1/2"
SIDE
VIEW
11 1/2"
WE
INACCURACIES
120V
AC
