Rotary MACH18 Installation Operation & Maintenance

Mobile column lift 24v dc powered

Advertisement

Quick Links

Reference Safety Requirements
IMPORTANT
for Installation and Service of
Automotive Lifts before installing lift.
MACH18
Mobile Column Lift
24V DC Powered
4 Column Lift Capacity 32,800 kg.
6 Column Lift Capacity 49,200 kg.
8,200 kg. per column
I
I
N
N
S
S
T
T
A
A
L
L
L
L
A
A
T
T
I
I
O
O
N
N
-
-
S
S
A
A
F
F
E
E
T
T
Y
Y
-
-
O
O
P
P
E
E
R
R
A
A
T
T
I
I
O
O
N
N
-
-
M
M
A
A
I
I
N
N
T
T
E
E
N
N
A
A
N
N
C
C
E
E
IN60118
Rev. A 6/21/2016

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MACH18 and is the answer not in the manual?

Questions and answers

Summary of Contents for Rotary MACH18

  • Page 1 MACH18 Mobile Column Lift 24V DC Powered 4 Column Lift Capacity 32,800 kg. 6 Column Lift Capacity 49,200 kg. 8,200 kg. per column Reference Safety Requirements IMPORTANT for Installation and Service of Automotive Lifts before installing lift. IN60118 Rev. A 6/21/2016...
  • Page 2 Intended use The lift is intended to be used to lift and lower commercial vehicles for repair, maintenance and cleaning during normal workshop operation. Specifications Value The lift is only to be used as intended, in techni- Lifting System Inverted Rod Hydraulic cally sound condition according to technical Cylinder specifications.
  • Page 3: Table Of Contents

    Index Set-Up Instructions ..........2 Battery Charging ............11 Safety Instructions ........... 5 Maintenance Instructions ........12 Owner/Employer Responsibilities ......5 Trouble Shooting ............13 Quick Start Operating Instructions ......7 Lift Lockout/Tagout Procedure ......14 Emergency Lowering ..........9 Wiring Diagram ............
  • Page 4 Power Unit Tank Battery Locations M20 Bolt Adjust For Ground Fig. 1 Clearance Socket Head Adjust For Ground Clearance DO NOT use on asphalt. Lift must be Ensure tires are properly inflated before lifting. DO WARNING on concrete with a minimum strength of 20.6 MPa and NOT exceed tire load rating when raising vehicle.
  • Page 5 6. Bleed mobile columns: Raise forks 150-200mm do not lift forks high enough to engage locks. Loosen bleed screw to release air from system. Close screw and repeat steps a and b until there is no air in the system and fluid runs clear. Bleed Screw Do Not Exceed Torque Values IMPORTANT...
  • Page 6: Safety Instructions

    SAFETY INSTRUCTIONS • Inspect your lift daily. Never operate if it malfunctions or • Load vehicle on lift carefully. Position lift forks to fully if it has broken or damaged parts. Use only qualified lift contact the vehicle tires. Release parking break on service personnel and genuine parts to make repairs.
  • Page 7 RF Exposure: A separation distance of 20 cm or more should be maintained between the antenna of the device and persons during device operation. To ensure compliance, operations at closer than this distance is not recommended. The antenna used for this transmitter must not be co-located in conjunction with any other antenna or transmitter.
  • Page 8: Quick Start Operating Instructions

    Quick Start Operating Instructions Control Panel Diagram Depress To Clear Data Information Error Codes Display and Buttons Height Limit Setting Battery Charge Indicator Lights on/off (Optional Accessory) Yellow, Green, Red Activation LED’s (8 Total) System Configuration Activate Column Buttons Lock/Unlock (8 Total) Turns Red On One Column When Max Single/Pair/All Mode...
  • Page 9 Fig. 2 Power Up Switch Fig. 4 Fig. 3...
  • Page 10 Monitor the safety locks while raising the lift by listening for Before attempting to lift any vehicle, be WARNING the mechanical lock clicking. sure that: A. Vehicle individual axle weight does not exceed two lift Do Not go under vehicle unless all tires are in secure columns combined capacity.
  • Page 11: Emergency Lowering

    Emergency (no power) Lowering: • During lowering of lifts, ensure that vehicle does not move into an inclined position. NOTE: Top cover not shown for clarity. • Lower columns equally. • Remove tool trays, safety stands, etc. from area. Pull To •...
  • Page 12 Operating Instruction Details/Options A. The configuration will not lock if there is not an Changing the System Configuration acceptable pairing of columns. Columns must be paired left/right directly across from one another. Columns may only be added to, or removed from, a system by unlocking the existing configuration and then configuring B.
  • Page 13: Battery Charging

    Battery Charging WARNING RISK OF EXPLOSIVE GASES 1. Battery chargers can be plugged in nearly continuously or WORKING IN THE VICINITY OF A LEAD ACID BATTERY IS DANGEROUS. BATTERIES CONTAIN SULFURIC ACID AND as needed. Life of the battery can be prolonged if the batteries PRODUCE EXPLOSIVE GASES.
  • Page 14: Maintenance Instructions

    Maintenance Instructions • Monthly Lubrication If you are not completely familiar with WARNING 1. Lower lift, check oil level in oil tanks on each column: automotive lift maintenance procedures Stop: contact Open Power Unit Cover. If necessary, add ISOAW32 factory for instructions. hydraulic oil, until it reaches the full mark on the tank.
  • Page 15: Trouble Shooting

    TROUBLE SHOOTING Code Description Troubleshooting steps CPU error The processor has detected an error. Press “x” to clear. If the problem continues, call for service. Improper configuration The column has not been assigned a position, and is connected to a locked system. Press “x”...
  • Page 16: Lift Lockout/Tagout Procedure

    LIFT LOCKOUT/TAGOUT PROCEDURE Purpose This procedure establishes the minimum requirements for the lockout of energy that could cause injury to personnel by the operation of lifts in need of repair or being serviced. All employees shall comply with this procedure. Responsibility The responsibility for assuring that this procedure is followed is binding upon all employees and service personnel from outside service companies (i.e., Authorized Installers, contactors, etc.).
  • Page 17 Software Update/Service Card Instructions Wireless Operation Software Updates: To install a software update: Power down the column by turning off the disconnect switch. Open the control panel door using 11mm socket wrench. Place the software update card into the memory card slot on the control board. Flip switch down to wireless.
  • Page 18 Software Menus: Service menus can be accessed when a service card is placed in the memory card slot. Menus are displayed on the menu screen and can be scrolled using the up, down, enter, and cancel keys. Menu Item Menu Selections Description [Height] Shows current column height (default menu for locked columns)
  • Page 19: Wiring Diagram

    COLUMN WIRING DIAGRAM...
  • Page 20 HYDRAULIC SCHEMATIC...
  • Page 21 NOTES...
  • Page 22 NOTES...
  • Page 23 NOTES...
  • Page 24 Thank You Trained Operators and Regular Maintenance Ensures Satisfactory Performance of Your Rotary Lift. Contact Your Nearest Authorized Rotary Parts Distributor for Genuine Rotary Replacement Parts. See Literature Package for Parts Breakdown. Rotary World Headquarters Rotary Lift Consolidated (Haimen) Co.,Ltd 2700 Lanier Drive No.1388,East Xiushan Road,Haimen,...
