Gree WK-010PN Owner's Manual

Gree WK-010PN Owner's Manual

Central air conditioner thermostat
Hide thumbs

Advertisement

Quick Links

Download this manual
Central Air Conditioner Thermostat
Model:
WK-010PN
WK-011PN

Advertisement

loading
Need help?

Need help?

Do you have a question about the WK-010PN and is the answer not in the manual?

Questions and answers

Related Manuals for Gree WK-010PN

Summary of Contents for Gree WK-010PN

  • Page 1 Central Air Conditioner Thermostat Model: WK-010PN WK-011PN...
  • Page 2 To Users Thank you for selecting Gree’s product. Please read this instruction manual carefully before installing and using the product, so as to master and correctly use the product. In order to guide you to correctly install and use our product...

  • Page 3: Table Of Contents

    Contents Safety notices (Please be sure to abide) ........1 1 Thermostat panel and keys ............2 2 Technical parameters ..............3 3 Components inside the packing box..........3 4 Installation of the thermostat .............4 6 Ambient temperature sensor failure.........23 7 Failure handling ...............24...

  • Page 4: Safety Notices (Please Be Sure To Abide)

    Central Air Conditioner Thermostat Safety notices (Please be sure to abide) Thank you for choosing the Gree’s thermostat. Read the Manual and retain it for a proper and safe operation of the product before use. Special notice: the pictures provided by the Manual may be different from the actual objects and the latter always prevail.

  • Page 5: Thermostat Panel And Keys

    Central Air Conditioner Thermostat 1 Thermostat panel and keys Cooling mode Temperature or failure codes Air supplying mode Child lock Heating mode ON/OFF Fan speed MODE Timer SPEED Drying function Sleep function DOWN...

  • Page 6: Technical Parameters

    Central Air Conditioner Thermostat 2 Technical parameters Item Description Supply voltage AC85~265V 50/60Hz Temperature setting 16~35°C Operation temperature 0~50°C Humidity Relative humidity 5~95% (no condensate) Load current 2A (resistive load); 1A (inductive load) Connecting terminal Less than 2.5mm wires Outline dimensions 86×86×10mm (Width ×...

  • Page 7: Installation Of The Thermostat

    Central Air Conditioner Thermostat 4 Installation of the thermostat It should not be fitted in the positions below: (4) Closed thermal pipelines and flues. (5) Near cool and hot air pipes and radiators. (6) Near direct sunlight, airflow and other heating objects (such as a television).
  • Page 8 Central Air Conditioner Thermostat (5) When removing the flexible flat cable (FFP), unplug its end with the thumb and the index finger but not pull its main body. (6) Do not hurl it or press forcibly its LCD. (7) Don’t hit and drop it, and protect it from deformation. (8) Keep its inside clean against other objects such as water and mud.
  • Page 9 Central Air Conditioner Thermostat 4.2 Installation preparations (1) Cut off the main power supply. (2) Label each conductor and wire them according to the wiring diagram. (3) Remove the protective film on the LCD before use. 4.3 Installation procedures Follow the installation diagram to assemble the components. 60mm VAL2 VAL1...
  • Page 10 Central Air Conditioner Thermostat a. Put a 3.5mm slotted screwdriver into b. Remove the seven-core FFP on the the groove, and then separate the front control board. panel from the clasp by proper upward force. c. Wire conductors according to the d.
  • Page 11 Notes: Remote controller model YB1FA (MOTO) is recommended for WK-011PN, not for WK-010PN which does not support remote control. Use the remote controller to set the temperature between 16 to 30°C.
  • Page 12 Central Air Conditioner Thermostat 5.1 ON/OFF As shown in Figure 1, press (ON/ OFF) to start or stop the unit. If it is on, the screen provides the operation mode, temperature and fan speed, among which only temperature appears if it is off. Figure 1 5.2 Mode setting As shown in the Figure 2, press...
  • Page 13 Central Air Conditioner Thermostat 5.3 Fan speed As shown in the Figure 2, press (SPEED) to switch between four speeds of the fan after starting the unit. Switch sequence: Medium High Automatic speed speed speed speed 5.4 Temperature setting (1) During the operation of the unit, press (UP) or (DOWN) to raise or lower the temperatures.
  • Page 14 Central Air Conditioner Thermostat Celsius Fahrenheit Figure 3 5.5 Timer (1) The unit is timed to start or stop, ranging from 0.5 to 24 hours. (2) As shown in the Figure 4, after starting the unit, to keep pressing (SPEED) for about 5 seconds (press keeping hereinafter lasts 5 seconds) can disable or enable the timer.
  • Page 15 Central Air Conditioner Thermostat (UP) or (DOWN) increases or reduces 0.5 hour in the amount of time. A press of (SPEED) ensures saving the timer setting. The symbol stops flashing and continue to be visible, which means the timer has been working and the countdown is displayed.
  • Page 16 Central Air Conditioner Thermostat 5.7 Sleep function As shown in the Figure 6, during the operation of the unit, press keeping of (MODE) enables or disables the function. When it is enabled, the homepage displays the symbol Notice: In the cooling mode, using the sleep function, the set temperature will rise 1°C after operating in 1 hour and another 1°C in another 1 hour.
  • Page 17 Central Air Conditioner Thermostat 5.8 Parameter setting (1) After a stop of the unit, press keeping of both (SPEED) and (UP) is an access to parameter setting page. Set the serial numbers of parameters by tapping (MODE) and decide the parameter values by (UP) or (DOWN).
  • Page 18 Central Air Conditioner Thermostat Name Description Temperature control 1: narrow ; 2: medium (by default); 3: wide range Adjustable range: 16°C~35°C (a precision of Cooling temperature 0.5°C, 16°C by default); set in the energy saving When the temperature unit is Fahrenheit, the mode adjustment range of the temperature is 61°F~95°F (a precision of 1°F).
  • Page 19 Central Air Conditioner Thermostat When the function is disabled, if a power failure occurred while the unit was stopped, it will automatically restart with a unit stop display when power is restored. As shown in the Figure 7 (the function has been disabled), on the parameter setting page, press (MODE) to switch...
  • Page 20 Central Air Conditioner Thermostat As shown in the Figure 8, on the parameter setting page, press (MODE) to switch the option number to 02. (UP) (DOWN) is provided to allow a switch between ON and OFF. Figure 8 (3) Drying function If it is enabled while the unit is working in the cooling condition, the symbol will be displayed.
  • Page 21 Central Air Conditioner Thermostat parameter setting page, press (MODE) to switch the option number to 03. (UP) or (DOWN) is provided to allow a switch between ON and OFF. (4) Temperature unit setting Celsius (°C) or Fahrenheit (°F) is available. As shown in the Figure 10, on the parameter setting page, press (MODE) to switch the option number to 04.
  • Page 22 Central Air Conditioner Thermostat is provided to allow a switch between “00”, “01” and “03”, adjusting the fan operation. (6) Temperature calibration The ambient temperature is allowed to calibrated between -5°C and +5°C with a precision of 0.5°C. As shown in the Figure 12, on the parameter setting page, press (MODE) to switch the option number to 06.
  • Page 23 Central Air Conditioner Thermostat As shown in the Figure 13, on the parameter setting page, press (MODE) to switch the option number to 07. (UP) (DOWN) is provided to a switch between “1”, “2” and “3” (the three ranges). Figure 13 (8) Cooling temperature set in the energy saving mode It is available when energy saving...
  • Page 24 Central Air Conditioner Thermostat drop on the temperature. If the temperature unit is Celsius, the adjustment range is 16°C~35°C with a precision of 0.5°C. If the temperature unit is Fahrenheit, the adjustment range is 61°F~95°F with a precision of 1°F. (9) Heating temperature set in the energy saving mode It is available when energy saving function is enabled.
  • Page 25 Central Air Conditioner Thermostat (10) Ambient temperature display If the user enables the indoor ambient temperature display after the start-up of the unit, the indoor ambient temperature will be displayed by default. While the user is setting a desirable temperature, the screen provides the desirable temperature.

  • Page 26: Ambient Temperature Sensor Failure

    Central Air Conditioner Thermostat (11) Factory data reset All parameters [5.8 (3)] can be reset to factory defaults. As shown in the Figure 17, on the parameter setting page, press (MODE) to switch the option number to 11. (UP) (DOWN) is provided to allow a switch between ON and OFF.

  • Page 27: Failure Handling

    Central Air Conditioner Thermostat Code Description Indoor ambient temperature sensor failure 7 Failure handling The product maintenance is performed by qualified technicians only. Status Maintenance approaches 1. Check if L/N lines work well and wiring is safe. Start-up failure 2. Check if ON/OFF key is effective. 3.
  • Page 28 Central Air Conditioner Thermostat GREE ELECTRIC APPLIANCES, INC. OF ZHUHAI Add: West Jinji Rd, Qianshan, Zhuhai,Guangdong, China, 519070 Tel: (+86-756) 8522218 Fax: (+86-756) 8669426 E-mail: global@cn.gree.com www.gree.com...

This manual is also suitable for:

Wk-011pn
