- Page 1 Device version by Pometkov MANUAL M 1.15 Fw. v. 1.128 November 2023...
-
Page 2: Table Of Contents
(Connection Diagram) Open Supervised Device Protocol (OSDP) Reader (Connection Diagram) Coming soon! Bluetooth Keys Coming soon! Connecting to the Built-in Wi-Fi Access Point Login System Network Main OSDP is coming soon! Maintenance Hardware reset with wires Glossary For Notes AIR-R... -
Page 3: Introduction
Introduction This document provides detailed information on the AIR-R Pro reader device structure and steps for installing and connecting it. It also includes instructions for preventing or troubleshooting many common problems. This guide is for informational purposes only, and in the event of any discrepancies, the actual product takes precedence. -
Page 4: Device Specifications
Device Specifications Device info • Model AIR-R Pro • Processor ESP32-S3 • Over-the-air (OTA) update • Built-in web server • Support for 125 kHz identifiers EM Marin • Support for 13.56 MHz identifiers MIFARE DESFire; MIFARE Plus; MIFARE Ultra Light; MIFARE Classic mini/1K/4K;... -
Page 5: Device Dimensions
Device Dimensions RFID CARD 125, 65535 3.375" AIR-R... -
Page 6: Wire Designation
Orange White The current hardware version of the AIR-R Pro reader has more wires than is needed for installation and use. This is necessary for future improvements and extensions of the device. The wires required to connect the AIR-R Pro reader are highlighted in color. -
Page 7: Installation Recommendations
The power supply line wires for the reader should be kept as short as possible to avoid a significant voltage drop across them. After cabling, ensure that the power supply voltage to the reader is at least 12 VDC with the locks switched on. AIR-R... -
Page 8: Wiegand Interface (Connection Diagram)
The voltage level at the power supply and at the reader may differ depending on the cable length and the resistance of the conductor. The recommended voltage should be at least +10 VDC. Use a multimeter in the VDC measurement mode to verify that the power supply voltage meets the recommended requirements. Warning AIR-R... -
Page 9: Wiegand Interface With Additional Power Supply (Connection Diagram)
BE SURE TO CONNECT THE GND OF THE CABLE FROM THE CONTROLLER TO THE GND OF THE AUXILIARY POWER SUPPLY! Warning DO NOT USE POWER SUPPLIES WITH DIFFERENT VOLTAGE LEVELS! Use a multimeter in the VDC measurement mode to verify that the power supply voltage meets the recommended requirements. AIR-R... -
Page 10: Open Supervised Device Protocol (Osdp) Reader (Connection Diagram) Coming Soon
BE SURE TO CONNECT THE GND OF THE CABLE FROM THE CONTROLLER TO THE GND OF THE AUXILIARY POWER SUPPLY! Warning DO NOT USE POWER SUPPLIES WITH DIFFERENT VOLTAGE LEVELS! Use a multimeter in the VDC measurement mode to verify that the power supply voltage meets the recommended requirements. AIR-R 10 10... - Page 11 The nominal resistance of the resistors corresponds to the wave impedance of the cable, and for twisted-pair cables is typically 100 to 120 ohms. Warning Install a 120 ohm terminating resistor on the outermost reader if the cable runs more than 150 feet. See RS-485 interface specifications for more information. AIR-R...
-
Page 12: Bluetooth Keys Coming Soon
Access Control System 2022-06-28 10:05:07 73 5D 72 A1 1 935 504 033 WG26 115. 23922 WG34 29533. 29345 5. Add the AIR key code to the access control system you are using as a normal card. AIR-R... -
Page 13: Connecting To The Built-In Wi-Fi Access Point
Step 2: Search for Wi-Fi networks. Step 3: Connect to the Wi-Fi network named AIR-R Pro_xxxxxxxxxxxx, where xxxxxxxxxxxxx is the serial number found on the sticker on your device. Step 4: In the address bar of the browser, enter the network address 192.168.4.1 and click "Go."... -
Page 14: System
◦ Device’s IP address. ◦ Network mode - Manual or Dynamic Host Configuration Protocol (DHCP). ◦ Network mask. ◦ Domain Name Service (DNS). ◦ Network port of the device. ◦ Built-in Wi-Fi AP operation mode ◦ ("Always on" or use a "Timed"). AIR-R... -
Page 15: Network
AP availability time from 1 to 60 minutes. • ”Always on”: if checked, makes the device • HTTP port: By default, the device uses hotspot searchable all the time. If port 80. unchecked, makes the device's hotspot available for 30 minutes after an active connection. AIR-R... -
Page 16: Main Osdp Is Coming Soon
13.56 MHz identifiers. The Wiegand Settings section and OSDP functionality • Check the “Enable copy protection” are under development and will be available soon. Keep an eye on the updates. checkbox to use the 13.56 MHz format ID AIR-R... -
Page 17: Maintenance
A power failure or network connection interruption during the update may cause a firmware update application error. If this happens, disconnect power from the device for 10 seconds and reconnect. Leave the unit switched on for 5 minutes without AIR-R... -
Page 18: Hardware Reset With Wires
8. The hardware reset procedure is complete, and the device is ready for use. When performing a hardware reset, all data stored in the device memory and all related settings will be deleted. This procedure cannot be undone. Warning AIR-R... -
Page 19: Glossary
Open collector - A transistor switch configuration in which the collector is left unconnected or open, typically used for signal grounding. • OSDP - Open Supervised Device Protocol. A secure communication protocol used in access control systems for device-to-device data exchange. AIR-R... - Page 20 • Wiegand interface - A standard interface used in access control systems to communicate data between card readers and access control panels. • Wi-Fi AP - Wireless access point. A device that allows wireless devices to connect to a network. AIR-R...
-
Page 21: For Notes
For Notes AIR-R www.lumiring.com...
