- Page 1 AIR-R Multi-reader RFID+Bluetooth Manual...
-
Page 2: Table Of Contents
Local Wi-Fi AP settings ______________________________ 10 Cloud connection settings ____________________________ 11 RS485 Settings ______________________________________ 11 Wiegand Settings ___________________________________ 11 Built-in Reader settings ______________________________ 12 Copy protection settings _____________________________ 12 Bluetooth Settings ___________________________________ 12 Maintain ___________________________________________ 13 Security ____________________________________________ 13 HARDWARE RESET _____________________________________ 13 AIR-R 1.01... -
Page 3: Purpose And General Information
2022 PURPOSE AND GENERAL INFORMATION The AIR-R Reader is designed to work with any controller of the access control system. The reader supports work with RFID identifiers at 125Khz and 13.56Mhz frequencies. Device support works with two kinds of mobile credentials: Bluetooth type AIRKEY; Cloud type VIKEY. -
Page 4: Description Of Connection Methods
-22 ~ 158 F IP Protection Level IP65 Enclosure material ABS Fire Retardant Description of connection methods A wired interface is used to connect the AIR to any peripheral or executive equipment. Figure 1 - Color designation of interface wires AIR-R 1.01... -
Page 5: Installation Recommendations
After laying the cables, make sure that the supply voltage of the controller with the locks turned on is not lower than 12 V. Figure 3. Recommended RS485 connection diagram AIR-R 1.01... -
Page 6: Typical Usage Cases
2022 TYPICAL USAGE CASES One door. One direction. Third-party controller. Figure 4 One door. Two directions. AIR-CR controller. Figure 5 AIR-R 1.01... -
Page 7: Bluetooth Credentials (Airkey)
2022 Bluetooth credentials (AIRKEY) Third-party access control system. Figure 6 AIR-R 1.01... -
Page 8: Macs Lite App
2022 MACS Lite App Figure 7 AIR-R 1.01... -
Page 9: Access Control In Two Directions
Figure 8 WEB-BASED INTERFACE Please do the Initial configuration of AIR-R Reader through the built-in web interface. To connect to this interface, the User must join the device's Wi-Fi access point, which has the "AIR" prefix and does not have a password. After connecting to the device, the User must enter the factory IP address of the controller - 192.168.4.1 in the browser line. -
Page 10: Main Network Settings
After the timer expires, the Wi-Fi point will be turned off. By default, the local hotspot is not password protected. We strongly recommend that you set a password (3) during the initial setup. AIR-R 1.01... -
Page 11: Cloud Connection Settings
2022 Cloud connection settings The cloud service functionality is available in a specialized version of the AIR-R firmware and is delivered to developers on demand. This solution allows you to connect the device to an arbitrary cloud MQTT server and interact with the device from your own service or application. -
Page 12: Built-In Reader Settings
- Remote opening with confirmation. In this mode, the User's mobile phone is remotely identified, but the door is opened with confirmation by the proximity sensor built into the device. Sensor distance (3) - allows you to set the range of the optical proximity sensor AIR-R 1.01... -
Page 13: Maintain
4 minutes. After the reset is completed, the device will automatically switch to standby mode, which it will inform about by changing the display mode and beeping. 6. Power OFF the device. 7. Return the D1 (Gray), D0 (Brown), and GND (Black) wires to their original condition. AIR-R 1.01...
