High-boy multiposition oil-fired furnace
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
INSTALLATION INSTRUCTIONS AND
INSTALLER / SERVICE TECHNICIAN:
USE THE INFORMATION IN THIS MANUAL FOR THE
INSTALLATION AND SERVICING OF THE FURNACE AND
KEEP THE DOCUMENT NEAR THE UNIT FOR FUTURE
REFERENCE.
HOMEOWNER:
PLEASE KEEP THIS MANUAL NEAR THE FURNACE FOR
FUTURE REFERENCE.
Printed in Canada on 100%
recycled paper
HOMEOWNER'S MANUAL
AMP SERIES
HIGH-BOY MULTIPOSITION
OIL-FIRED FURNACE
Models:
AMP154SD
AMP154SV
Attention:
Do not tamper with the unit or its controls.
Call a qualified service technician.
Manufactured by: Dettson Industries Inc.
for Innovair Solutions
Sherbrooke,
Qc,
www.dettson.com
2023-10
Canada
X40183 Rev.L

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AMP Series and is the answer not in the manual?

Questions and answers

Related Manuals for innovair AMP Series

Summary of Contents for innovair AMP Series

  • Page 1 INSTALLATION INSTRUCTIONS AND HOMEOWNER’S MANUAL AMP SERIES HIGH-BOY MULTIPOSITION OIL-FIRED FURNACE Models: AMP154SD AMP154SV INSTALLER / SERVICE TECHNICIAN: Attention: USE THE INFORMATION IN THIS MANUAL FOR THE INSTALLATION AND SERVICING OF THE FURNACE AND Do not tamper with the unit or its controls.
