for DLA-X90R,X70R,X30,XC988R,XC788R,XC388,RS65,RS55,RS45,RS4800
This manual describes how to update the firmware for the DLA-X90R,X70R,X30,XC988R,XC788R,XC388,
RS65,RS55,RS45,RS4800
Please carry out the update in the order shown below:
１. Install Software
２. Projector LAN Settings
３. Projector Software Update
１. Install Software
First download the projector update software from the JVC website to your desktop on your computer.
This example uses the DLA-X70R
(1) Double-click the downloaded file on the desktop. This will start the installer.
(2) The dialog box shown on the right will appear.
Click the [Next] button.
(3) The dialog box shown on the right will appear.
Click the [Next] button.
Firmware Update Manual
(Ver.1.1)
JVC KENWOOD Corporation
Projector Division
Advertisement
Related Manuals for JVC D-ILA DLA-X90R
Summary of Contents for JVC D-ILA DLA-X90R
- Page 1 ３. Projector Software Update １. Install Software First download the projector update software from the JVC website to your desktop on your computer. This example uses the DLA-X70R (1) Double-click the downloaded file on the desktop. This will start the installer.
- Page 2 (4) The dialog box shown on the right will appear. Click the [Next] button with the destination unchanged. （5）The dialog box shown on the right will appear. Click the [Next] button. （6) The dialog box shown on the right will appear. Click the [Install] button.
- Page 3 2. Projector LAN Settings (1) Connect the projector to a PC with a LAN cable. (2) Connect the power cord to the projector and turn on. (3) Set "Communication Terminal" under the "Function" tab in the menu to "LAN". (4) Open "Network" item under the "Function" tab in the menu. (5) Projector Network Settings Set the "DHCP Client"...
- Page 4 3. Projector Software Update The software is accepted when the projector in STAND-BY Mode. For example DLA-X70R (1) Clieck "Start" on PC →Select "ILA-FPJ X70R" from "ALL programs" This will start the ILA-FPJ Updater. Note: Press [Update Firmware] Set IP Address to projector's IP address if required. (2) The software update will start.
- Page 5 The three LEDs will flash when the update is complete. After a while, the STAND-BY light will light Red. The others will be off. Close Up LEDs (3) The update has been completed. Close the update program. (4) After updating, remove the power cable from the projector, wait until all lights go out, then reconnect power. Close Up LEDs Please check that the software version: 28.056 has been updated after finishing the update.
