Comfast CF-XR186 Quick Installation Manual page 9

Mesh pairing:
After enabling Mesh, a button for Mesh pairing will appear on the page.
On the pages of the two nodes, click the "Trigger easymesh" button to start
building Mesh.
Light control status
6
You can turn off the lights in advanced settings. NOTE: The power light
cannot be turned off.
Power light
Network cable light
WiFi status light
AP/Route Mode
Always bright
Always bright
Blue light is
always on
Trunk/Bridge Mode
Always bright
Connect to the network cable light on,
unplug the network cable light off
After successfully connecting to the superior, the
corresponding signal will be displayed.
Blue light: strong signal
Green light: Normal signal
Red light: weak signal
