MX3510
Installation and Operation Manual
This manual contains specific cautionary statements relative to worker safety. Read this manual thoroughly and follow
as directed. It is impossible to list all of the hazards of dust control equipment. It is important that use of the equipment
be discussed with a Micro-Air Representative. Persons involved with the equipment or systems should be instructed how
to operate in a safe manner.
MICRO AIR
www.microaironline.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MX3510 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MICRO-AIR MX3510

Summary of Contents for MICRO-AIR MX3510

  • Page 1 It is impossible to list all of the hazards of dust control equipment. It is important that use of the equipment be discussed with a Micro-Air Representative. Persons involved with the equipment or systems should be instructed how to operate in a safe manner.

  • Page 2: Package Contents

    Improper installation or operation of this equipment can cause damage to equipment and / or injury to personnel. The installation / operation manual must be read and followed in its entirety. MX3510 SPECIFICATIONS: Motor: 1-1/2 HP, 1725 RPM, 1 Phase, TEFC...

  • Page 3: Hanging Instructions

    MX3510 MICRO AIR PRE-OPERATING INSTRUCTIONS: 1. Inspect the unit for any visible damage that may have occurred during shipment. Report any damage to the delivery carrier. 2. Remove the shipping crate, shipping straps and plastic wrap from unit. Discard skid and hardware.

  • Page 4: Electrical Connections

    MX3510 MICRO AIR ELECTRICAL CONNECTIONS: All electrical work must be done by a qualified electrician according to local, state and national codes. Be sure that the designated circuit breaker is off until all wiring has been completed. NOTE: It is recommended that a properly sized motor starter and overload protector be used in the supply circuit of the 3 Phase motor.

  • Page 5: Air Flow Adjustment

    (more air flow), cover less of the opening. AIR FLOW ADJUSTMENT: Depending on the configuration, the MX3510 will be equipped with a variable diameter pulley on the motor to allow the air flow to be adjusted to the installation requirements. The pulley is set for maximum air flow from the factory.

  • Page 6: Changing Filters

    1. The MX3510 motor/blower module can be rotated so that the exhaust air exits from the side of the unit. Before rotating the motor/blower module be sure that all input power is disconnected and the unit is turned off.

  • Page 7: Installation

    MX3510 MICRO AIR UNITS WITH HEPA OR CHARCOAL AS A SECOND MAIN FILTER: INSTALLATION: On units with optional HEPA or charcoal filters, an adjustable filter track kit is used to 1. Place supports (Item # 2) in cabinet at a complete the seal of the filters to the filter dimension of 13-1/4”...
  • Page 8 MX3510 MICRO AIR UNITS WITH HEPA OR CHARCOAL AS A FIRST AND SECOND MAIN FILTER: INSTALLATION: On units with optional HEPA or charcoal filters, an adjustable filter track kit is used to complete 1. Place supports (Item # 2) in cabinet at a the seal of the filters to the filter stop (FIG.
  • Page 9 5. With filter track in place and handle pulled out away from cabinet load RCM modules into track. 6. With filters in place rotate handle 90º and lock filter modules in place. NOTE: The MX3510 requires two modules when used as a second main filter and four modules when used as a first and second main filter.
  • Page 10 MX3510 MICRO AIR OPTIONAL SILENCER INSTALLATION: 1. Remove exhaust grille from unit as shown in Fig. 7. 2. Slide silencer over blower assembly. 3. Align holes from silencer with those located on side of the blower assembly. 4. Attach silencer to blower assembly using 3/8” bolt, lock washer and flat washer.
  • Page 11 MX3510 MICRO AIR OPTIONAL WRAP AROUND PRE-FILTER INSTALLATION: Kit includes: PART NO. QTY. DESCRIPTION 38086-01 1 Ea. WAPF Assembly 5/16-18 x ¾” Hex Head Bolt P114 6 Ea. P222 6 Ea. 5/16-18 Hex But 5/16” Flat Washer P233 6 Ea.

  • Page 12: Wiring Diagram

    MX3510 MICRO AIR WIRING DIAGRAM: All electrical work must be done by a qualified electrician according to local, state and national codes. FIG. 9...

  • Page 13: Troubleshooting

    MX3510 MICRO AIR TROUBLESHOOTING: CAUTION: Before disassembling the unit or doing any inspecting of the parts, make certain that the power has been cut off and the blower has come to a complete stop. NEVER run the unit with the access door opened or the panels removed.
  • Page 14 MX3510 MICRO AIR MX3510 ASSEMBLY PARTS LIST: FIG. 10...
  • Page 15 MX3510 MICRO AIR MX3510 ASSEMBLY PARTS LIST: ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION P1977 Grille P1710 4.95" Blower Pulley 38010-01 Blower Access Panel P1504 5.45" Blower Pulley P1429 Light (120V) P1974 6.25" Blower Pulley P1481 Light (230V, 460V) P3218 8.00"...
  • Page 16 MX3510 MICRO AIR Notes: Serial Number: Supply Voltage: Date Installed: Installed By: L1469 11/23...
