Otto REVO NC2 V2-R2BT53133 Series Instructions Manual

Speaker microphone

Advertisement

Quick Links

BLUETOOTH
REVO NC2
®
SPEAKER MICROPHONE
The Bluetooth
Revo
®
NC2
brings wireless
convenience and HD-Voice
audio to a speaker mic. It
offers hands-free listening,
a noise-canceling mic and
clear, convenient, push-to-
talk audio transmissions for
Bluetooth
-enabled two-way
®
radios, mobile phones and
tablets.
Models V2-R2BT53133-x and V2-R2BT13133-x

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the REVO NC2 V2-R2BT53133 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Otto REVO NC2 V2-R2BT53133 Series

  • Page 1 BLUETOOTH REVO NC2 ® ™ SPEAKER MICROPHONE The Bluetooth Revo ® brings wireless ™ convenience and HD-Voice audio to a speaker mic. It offers hands-free listening, a noise-canceling mic and clear, convenient, push-to- talk audio transmissions for Bluetooth -enabled two-way ®...
  • Page 2: Safety Precautions

    USE AND SAFETY CAUTIONS • Do not drop, disassemble, open, crush, bend, deform, puncture, shred, microwave, incinerate, paint, or insert foreign objects into the OTTO Bluetooth Revo NC2 Speaker Microphone. Such actions could result in ®...
  • Page 3 Bluetooth REVO NC2 ® ™ INTRODUCTION The Bluetooth Revo NC2 features an ergonomic design ideal for ® ™ demanding public safety, disaster recovery and emergency response ® teams, or teams using Bluetooth -enabled two-way radios, phones and tablets to extend its communications network. Compatible with selected two-way radios and mobile apps like ESChat ®...
  • Page 4: Supplied Equipment

    SUPPLIED EQUIPMENT Noise-Canceling Microphone Emergency Button Push-to-Talk Volume Button USB to Micro-USB Button Charging Cable Volume Down Button Lanyard Loops Micro USB Charging Port 360° Rotating Multi-function Clothing Clip Earphone Jack On/Off Button with Cover LED Indicator Lights Color Indicates Color Indicates Solid Red...
  • Page 5: Operation

    Bluetooth REVO NC2 ® ™ OPERATION Charge the Speaker Microphone The Bluetooth Revo NC2 is powered by an integrated rechargeable ® ™ battery. The battery should be fully charged before first use. • Plug the charging cable into the Micro-USB charging port on the back of the unit (Figure 1).
  • Page 6 OPERATION, CONTINUED Pairing The Bluetooth Revo NC2 speaker microphone may be paired with a ® ™ compatible Bluetooth -enabled two-way radio or mobile device. Once ® connected, the microphone and speaker of the Bluetooth Revo NC2 ® ™ will be available for use. When successfully paired, the Bluetooth Revo NC2 will remain...
  • Page 7 Bluetooth REVO NC2 ® ™ OPERATION, CONTINUED device does not have a display and multiple devices are being paired with multiple speaker mics, only put one device into pairing mode at a time to avoid pairing the Bluetooth Revo NC2 ™...
  • Page 8 (Figure 3).(Lanyard not included) Figure 3 Attach an Earphone Kit An optional earphone kit may be plugged into the audio jack to silence the external speaker and enable private listening. A full assortment of compatible earphone kits is available at www.otto-comm.com.
  • Page 9: Operating Modes

    Bluetooth REVO NC2 ® ™ OPERATING MODES Two-Way Radio Functions The Bluetooth Revo NC2 connects wirelessly to compat- ® ™ ible two-way radios. To use the speaker microphone with a radio, follow the instructions in the radio manufacturer’s user manual. •...
  • Page 10 OPERATING MODES, CONTINUED Call Mode, continued To toggle to a call waiting: • Push and release the PTT button once to end the first call and answer the second call. • Push and release the multi-function button once quickly to put the first call on hold and answer the second call.
  • Page 11: Care And Maintenance

    REVO NC2 ® ™ CARE AND MAINTENANCE • Clean the OTTO Speaker Microphone only with a dry cloth. ® • Do not clean the speaker microphone when it is being charged. Always unplug the charger first before cleaning the speaker microphone.
  • Page 12 FCC STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 13 Bluetooth REVO NC2 ® ™ INDUSTRY CANADA NOTICE This device complies with Industry Canada’s license-exempt RSS standard(s). Operation is subject to the following two conditions: 1. This device may not cause interference 2. This device must accept any interference, including interference that may cause undesired operation of the device.
  • Page 14 Earphone with acoustic tube, 2.5 mm right angle V1-11550 plug, coil cord, black, high output Dual Earphone with SureFire noise attenuation, V1-11149 3.5mm plug Dual Earphone with SureFire noise attenuation, V1-11148 2.5mm plug Additional accessory options are available at otto-comm.com...
  • Page 16 For warranty information, customer service or replacement parts, please contact: 10 West Main Street • Carpentersville, IL U.S.A. 60110 Toll Free Phone: +1-888-234-OTTO (6886) Phone: +1-847-428-7171 • Fax: +1-847-428-1956 E-mail: info@ottoexcellence.com www.otto-comm.com 804470 02/20 © 2020 OTTO Engineering, Inc.
