Summary of Contents for HomeMatic HM-LGW-O-TW-W-EU-2

  • Page 1 Montage- und Bedienungsanleitung (S. 2) Mounting instruction and operating manual (p. 21) Funk LAN Gateway Wireless LAN Gateway HM-LGW-O-TW-W-EU-2...
  • Page 2 Dokumentation © 2015 eQ-3 AG, Deutschland Alle Rechte vorbehalten. Ohne schriftliche Zustim- mung des Herausgebers darf dieses Handbuch auch nicht auszugsweise in irgendeiner Form reproduziert werden oder unter Verwendung elektronischer, mecha- nischer oder chemischer Verfahren vervielfältigt oder verarbeitet werden. Es ist möglich, dass das vorliegende Handbuch noch drucktechnische Mängel oder Druckfehler aufweist.
  • Page 3: Table Of Contents

    Funktion ......6 Allgemeine Systeminformation zu Homematic. 8 Inbetriebnahme ......8 Wandmontage .
  • Page 4: Hinweise Zu Dieser Anleitung

    Hinweise zu dieser Anleitung Lesen Sie diese Anleitung sorgfältig, bevor Sie Ihre Homematic Komponenten in Betrieb nehmen. Bewah- ren Sie die Anleitung zum späteren Nachschlagen auf! Wenn Sie das Gerät anderen Personen zur Nutzung überlassen, übergeben Sie auch diese Bedienungs- anleitung.
  • Page 5 Öffnen Sie das Gerät nicht. Es enthält keine durch den Anwender zu wartenden Teile. Im Fehlerfall schicken Sie das Gerät an den Service. Das Gerät nicht verwenden, wenn es von außen erkennbare Schäden z. B. am Gehäu- se, an Bedienelementen oder an den An- schlussbuchsen bzw.
  • Page 6: Funktion

    Haftungsausschluss. Das Gerät ist nur für den Einsatz in woh- nungsähnlichen Umgebungen geeignet. Funktion Das Homematic Funk LAN Gateway dient als Erweiterung der Funkreichweite Ihrer CCU2 in einem Homematic System. Wenn Sie Homematic Geräte außerhalb der direkten Reichweite Ihrer CCU...
  • Page 7 B. im Keller, im Obergeschoss Ihres Hauses oder im Gartenhaus, unterstützt das Funk LAN Gateway bei der Übertragung von Funkbefehlen an diese Geräte. Sie können mehrere Funk LAN Gateways in Ihrem Homematic System verwenden. Übersicht und Anschlüsse Power Network...
  • Page 8: Allgemeine Systeminformation Zu Homematic.

    Allgemeine Systeminformation zu Homematic Dieses Gerät ist Teil des Homematic Haussteuer- systems und arbeitet mit dem bidirektionalen Funkpro- tokoll BidCoS®. Alle technischen Dokumente und Updates finden Sie stets aktuell unter www.homematic.com. Inbetriebnahme Um das Funk LAN Gateway in Betrieb zu nehmen, führen Sie die folgenden Schritte durch:...
  • Page 9 Verwenden Sie für die Wandmontage die zwei mitge- lieferten Schrauben und Dübel. Stellen Sie bei der Auswahl des Montageortes und beim Bohren in der Nähe vorhandener Schalter oder Steckdosen sicher, dass in der Wand keine Leitungen verlaufen. • Halten Sie die beiliegende Bohrschablone an die vorgesehene Montagestelle und richten Sie die Bohrschablone senkrecht bzw.
  • Page 10: Funk Lan Gateway Mit Dem Netzwerk Verbinden

    5.2 Funk LAN Gateway mit dem Netzwerk verbinden • Ziehen Sie zunächst die Abdeckkappe nach oben ab. • Schließen Sie das Funk LAN Gateway mit dem mit- gelieferten Netzwerkkabel (F) an Ihren DSL-Router bzw. an Ihr Kabelmodem an.
  • Page 11: Funk Lan Gateway An Die Stromversorgung Anschließen

    Um eine sichere Bedienung des Gerätes ge- währleisten zu können, wird ein Ethernetkabel mit mindestens der Kategorie 5 (CAT5 SF/UTP) benötigt. 5.3 Funk LAN Gateway an die Stromversor- gung anschließen Um Schäden am Gerät zu vermeiden, benut- zen Sie ausschließlich das mitgelieferte Origi- nalnetzteil des Funk LAN Gateways für die Stromversorgung (5 V /1500 mA).
  • Page 12 Gehen Sie dafür wie folgt vor: • Öffnen Sie Ihren Webbrowser. • Geben Sie in Ihrem Browser die URL „http://homematic-ccu2“ ein. Anschließend gelangen Sie auf die Startseite Ihrer WebUI. • Klicken Sie dort unter „Einstellungen“ auf „System- steuerung“. • Da-...
  • Page 13 • Wählen Sie den Typ „RF: Homematic RF-LAN Gate- way“ aus. • Entnehmen Sie die Seriennummer und den Zugriffs- code Ihres Funk LAN Gateways Ihren Notizen oder den Aufklebern auf der Gehäuserückseite. • Geben Sie diese in den entsprechenden Feldern ein.
  • Page 14 • Klicken Sie dafür auf „Einstellungen“ „System- steuerung“ „Zentralen-Wartung“ „Neustart“ und melden sich neu an. Anschließend müssen Sie alle Geräte, die über das Funk LAN Gateway erreicht werden sollen, mit dem Funk LAN Gateway über die WebUI verbinden. • Klicken Sie dafür in der Geräteansicht („Einstellungen“ „Systemsteuerung“...
  • Page 15: Rück- Und Fehlermeldungendurch Die Geräte Led

    Jetzt können Sie die ausgewählten Geräte Ihres Homematic Systems über das Funk LAN Gateway erreichen. Rück- und Fehlermeldungen durch die Geräte LED Power LED Bedeutung Gerät ist abgeschaltet Gerät ist betriebsbereit Schnelles Blinken Bootloader aktiv Langsames Blinken Werkseinstellungen wieder- herstellen...
  • Page 16: Werkseinstellungen Des Gerätes Wiederherstellen

    10 s für die Übertragung der Meldungen möglich. Werkseinstellungen des Gerätes wiederherstellen Die Werkseinstellungen des Homematic Funk LAN Gateways können manuell wieder hergestellt werden. Dabei gehen alle Einstellungen und Informationen verloren. Bevor Sie die Werkseinstellungen des Gerätes wieder herstellen, löschen Sie es zuerst aus der...
  • Page 17: Duty Cycle

    1 % einer Stunde (also 36 Sekunden in einer Stunde). Die Geräte dürfen bei Erreichen des 1 %-Limits nicht mehr senden, bis diese zeitliche Begrenzung vorüber ist. Gemäß dieser Richtlinie, werden Homematic- Geräte zu 100 % normenkonform entwickelt und produziert.
  • Page 18: Wartung Und Reinigung

    Tuch leicht mit lauwarmem Wasser angefeuchtet werden. Verwenden Sie keine lösemittelhaltigen Reinigungsmittel, das Kunst- stoffgehäuse und die Beschriftung kann dadurch angegriffen werden. 10 Lieferumfang • Homematic Funk LAN Gateway • Steckernetzteil • Netzwerkkabel • Montagematerial • Bohrschablone • Montage- und Bedienungsanleitung...
  • Page 19: Technische Daten

    11 Technische Daten Geräte-Kurzbezeichnung: HM-LGW-O-TW-W-EU-2 Versorgungsspannung: Stromaufnahme: 250 mA max. Leistungsaufnahme Ruhebetrieb: 0,8 W Funkfrequenz: 868,3 MHz Empfängerkategorie: SRD Category 2 Typ. Funk-Freifeldreichweite: 500 m Duty Cycle: < 1 % pro h Schutzart: IP20 Umgebungstemperatur: 5 bis 35 °C Abmessungen (B x H x T):...
  • Page 20 Entsorgungshinweis: Gerät nicht im Hausmüll entsorgen! Elektro- nische Geräte sind entsprechend der Richtli- nie über Elektro- und Elektronik-Altgeräte über die örtlichen Sammelstellen für Elektronik- Altgeräte zu entsorgen. Das CE-Zeichen ist ein Freiverkehrszeichen, das sich ausschließlich an die Behörden wendet und keine Zusicherung von Eigen- schaften beinhaltet.
  • Page 21 Documentation © 2015 eQ-3 AG, Germany All rights reserved. This manual may not be repro- duced in any format, either in whole or in part, nor may it be duplicated or edited by electronic, mechanical or chemical means, without the written consent of the publisher.
  • Page 22 Function ......25 General system information about Homematic 27 Start-up......27 Wall mounting.
  • Page 23: Information About This Manual

    Information about this manual Read this manual carefully before beginning operation with your Homematic components. Keep the manual handy for later consultation! If you hand over the de- vice to other persons for use, please hand over the operating manual as well.
  • Page 24 Do not open the device. It does not contain any parts that can be maintained by the user. In the event of an error, have the device che- cked by an expert. Do not use the device if there are signs of damage to the housing, control elements or connecting sockets, for example, or if it de- monstrates a malfunction.
  • Page 25: Function

    The device may only be operated whitin residential buildings. Function The Homematic Wireless LAN Gateway increases the transmission range of your Homematic CCU2 within a Homematic installation. If you want to use Homematic devices that are not within the scope of radio trans-...
  • Page 26 CCU (e.g. in the cellar, the top floor of your house or your summer house) the repeater increases the radio transmission of your devices. You can use several Wireless LAN Gateways within your Homematic system. Overview and connections Power Network...
  • Page 27: General System Information About Homematic

    General system information about Homematic This device is part of the Homematic home control system and works with the bidirectional BidCoS® wireless protocol. All current technical documents and updates are provided at www.homematic.com. Start-up To start up your Wireless LAN Gateway, please pro- ceed as follows: •...
  • Page 28 Hold the drilling template supplied (see additional sheet) at your intended mounting location and align it vertically and/or horizontally. When selecting a mounting location and drill- ing in the vicinity of switches or socket outlets, make sure that there are no cables in the wall. •...
  • Page 29: Connecting The Wireless Lan Gateway To The Network

    5.2 Connecting the Wireless LAN Gateway to the network • First pull the cap up and off the Wireless LAN Gate- way. • Connect the Wireless LAN Gateway to your DSL router or cable modem using the network cable supplied (F). To ensure secure operation of the device, an Ethernet cable of at least category 5 (CAT5 SF/UTP) is required.
  • Page 30: Connecting The Wireless Lan Gateway To The Power Supply

    5.3 Connecting the Wireless LAN Gateway to the power supply For the power supply, only use the Wireless LAN Gateway original power supply unit (5 V /1500 mA) delivered with the device in order to avoid damage. • Attach the supplied plug-in main adapter (E) to the Wireless LAN Gateway and plug it into the socket outlet.
  • Page 31 Therefore, please proceed as follows: • Open your web browser. • Enter the URL „http://homematic-ccu2“ into your browser. You will then be taken to the homepage of your WebUI. • Please click on "Settings" and "Control panel".
  • Page 32 • To integrate your Wireless LAN Gateway into the network, please click "Add" in the next window. • Select the type "RF: Homematic RF-LAN Gateway". • In the next step, you will need the serial number and access code of your Wireless LAN Gateway.
  • Page 33 • Therefore, please click "Settings" "Control "CCU maintenance" "Restart" and panel" log in again. Afterwards, please use the WebUI interface to connect the Wireless LAN Gateway with all the devices that have to be reached via the Wireless LAN Gateway. •...
  • Page 34: Device Led Information And Error Messages

    Now the selected devices of your Homematic system can be reached via the Wireless LAN Gateway. Device LED information and error messages Power LED Meaning Device is turned off Device is ready for operation Fast flashing Boot loader active Slow flashing...
  • Page 35: Restore Factory Settings Of The Device

    10s. Restore factory settings of the device The factory settings of the Homematic Wireless LAN Gateway can be restored manually. If you do this, you will lose all your settings. Before restoring the factory settings, please delete the device from the user interface WebUI first.
  • Page 36: Duty Cycle

    If the duty cycle limit is exceeded, this is indicated if your Homematic device is temporarily working incorrectly. The device will start working cor- rectly again after a short period (max. 1 hour).
  • Page 37: Maintenance And Cleaning

    Do not use any detergents containing solvents, as they could corrode the plastic housing and label. 10 Scope of delivery • Homematic Wireless LAN Gateway • Plug-in mains adapter • Network cable • Mounting material • Drilling template...
  • Page 38: Technical Data

    11 Technical data Device short description: HM-LGW-O-TW-W-EU-2 Supply voltage: Current consumption: 250 mA max. Power consumption in standby: 0.8 W Receive frequency: 868.3 MHz Receiver category: SRD category 2 Typ. open area RF range: 500 m Duty cycle: < 1 % per h...
  • Page 39 Instructions for disposal: Do not dispose of the device with regular domestic waste. Electronic equipment must be disposed of at local collection points for waste electronic equipment in compliance with the Waste Electrical and Electronic Equipment Directive. The CE sign is a free trading sign addressed exclusively to the authorities and does not include any warranty of any properties.
  • Page 40 Bevollmächtigter des Herstellers: Manufacturer’s authorised representative: eQ-3 AG Maiburger Straße 29 26789 Leer / GERMANY www.eQ-3.de...
