Lenovo
IdeaPad S10
-2
User Guide
V1.0

Advertisement

Troubleshooting

   Related Manuals for Lenovo IdeaPad S10-2

   Summary of Contents for Lenovo IdeaPad S10-2

  • Page 1

    Lenovo IdeaPad S10 User Guide V1.0...

  • Page 2

    RESTRICTED RIGHTS. Use, duplication or disclosure by the Government is subject to the GSA ADP Schedule contract with Lenovo, if any, or the standard terms of this commercial license, or if the agency is unable to accept this Program under these terms, then we provide this Program under the provisions set forth in Commercial Computer Software–Restricted Rights at FAR 52.227-19, when applicable, or under Rights in Data-General, FAR...

  • Page 3

    If your product is not working correctly, DO NOT RETURN IT TO THE STORE. For technical assistance, contact a Lenovo support specialist 24 hours a day by calling toll free 1-877-4 LENOVO (1-877-453-6686). Additionally, you can find support information and updates on the Lenovo Web site located at http://consumersupport.lenovo.com.

  • Page 4

    User Guide carefully. We are most honored to have you as our customer. In order to make sure you master the usage of Lenovo notebook soon, we have prepared this User Guide for you. This manual has been made very simple and comprehensive.

  • Page 5: Explanation Of Hard Disk Capacity

    Explanation of hard disk capacity Dear user, While using your computer, you may find that the nominal hard disk capacity indicated is somewhat different from the disk capacity displayed by the operating system. For example, a nominal 40GB hard disk will appear as less than 40GB in the operating system. This discrepancy is not an error in hard disk installation nor any other problem, but a normal phenomenon of computers.

  • Page 6

    X × 0.931 G. II. A portion of the hard disk space is used for specific purposes Lenovo computers may come with preinstalled OneKey Rescue System, so the hard disk has a special portion partitioned before delivery, which is used to store hard disk mirror and OneKey Rescue System program files.

  • Page 8: Table Of Contents

    Using the keyboard... 15 Special buttons... 18 System status indicators... 20 Securing your computer... 21 Connecting external devices... 23 Using Lenovo Quick Start (specific models only) ... 27 Chapter 3. Using the Internet ... 29 Wired connection ... 29 Wireless connection ... 31 Chapter 4.

  • Page 9

    Contents Appendix C. Lenovo limited warranty ... 82 Warranty information ... 91 Appendix D. Customer replaceable units (CRUs)... 95 Appendix E. Notices... 97 Notices ... 97 ENERGY STAR model information ... 100 Wireless related information ... 102 Electronic emissions notices... 106 WEEE and recycling statements ...

  • Page 10: Important Safety Information

    Follow and retain all information included with your computer. The information in this document does not alter the terms of your purchase agreement or the Lenovo Limited Warranty. For more information, see “Appendix C. Lenovo limited warranty” on page 82.

  • Page 11

    Important safety information Unpack Inspect the covers of the computer and the AC adapter, especially parts with the following labels attached for any crack or damage. Danger: • Hazardous voltage, current, and energy levels are present inside any component that has this label attached.

  • Page 12

    Working place Do NOT use the computer in humid places such as a bathroom. Keep the computer and other parts away from liquids. Danger: • An electric shock may be caused by spilled liquid. Do NOT use the computer during a lightning storm. Attention: •...

  • Page 13

    Important safety information On using Use ONLY the power cord, power adapter and battery pack shipped with the computer and never use them with another product. Be sure the power outlet is suitable for the plug and provides the correct voltage and current for the product you are installing. Danger: •...

  • Page 14

    Do NOT wrap the power cord around the power adapter or other objects. Do NOT squeeze or pinch the cord, or place heavy objects on it. Attention: • Stressing the cord may cause the cord to fray, crack or crimp which may present a safety hazard.

  • Page 15

    For a list of service and support phone numbers, go to http://consumersupport.lenovo.com. Lenovo provides documentation with instructions when it is appropriate for customers to install options or replace units (CRUs). Closely follow all instructions when installing or replacing parts.

  • Page 16: Chapter 1. Getting To Know Your Computer

    Chapter 1. Getting to know your computer Top view - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Note: The illustrations in this manual may differ from the actual product.

  • Page 17

    When the computer is powered-off, press this button to enter the Lenovo Quick Start if it has been installed. Use the camera for video communication. The built-in antennas ensure optimal reception of wireless communication radio.

  • Page 18: Left-side View

    Left-side view - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - RJ-45 port Connects to an Ethernet network.

  • Page 19: Right-side View

    Chapter 1. Getting to know your computer Right-side view Integrated wireless device switch USB port Note: For details, see “Connecting a universal serial bus (USB) device” on page 25. Kensington slot Note: For details, see “Attaching a security lock (not supplied)” on page 21. AC power adapter jack Note: For details, see “Using AC adapter and battery”...

  • Page 20: Front View

    Chapter 1. Getting to know your computer Front view - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Memory card slot Insert memory cards (not supplied) here.

  • Page 21: Bottom View

    Chapter 1. Getting to know your computer Bottom view - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -...

  • Page 22

    Battery latch - The manual battery latch is used to keep the battery pack secured in place. manual Speakers The stereo speakers provide rich and powerful sound. PCI Mini ExpressCard slot/hard disk drive (HDD) compartment Battery pack For details, see “Using AC adapter and battery” on page 11. Memory compartment Battery latch -...

  • Page 23: Chapter 2. Learning The Basics

    Chapter 2. Learning the basics First use - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Read the manuals Read the supplied manuals before using your computer.

  • Page 24

    Chapter 2. Learning the basics Turn on the computer Press the power button to turn on the computer. Configure the operating system You may need to configure the operation system when it is first used. The configuration process may include the procedures below. •...

  • Page 25: Shutting Down Your Computer

    Chapter 2. Learning the basics To put the computer into standby state, do one of the following. • Click start and select Stand By from the Turn Off Computer menu. • Press Fn + F1. Note: Wait until the power indicator light starts blinking (indicating that the computer is in standby state) before you move your computer.

  • Page 26: Using Ac Adapter And Battery

    Using AC adapter and battery Checking battery status You can determine the percentage of battery power remaining by using Windows Power Options. Note: As each computer user has different habits and needs, it is difficult to predict how long a battery charge will last. There are two main factors: •...

  • Page 27: Removing The Battery Pack

    If you are not going to use the computer for an extended period of time, or if you need to send your computer to Lenovo for service, etc., remove the battery pack from the computer. Before removing the battery pack, make...

  • Page 28: Handling The Battery

    To avoid possible injury and detriment to the environment, pay attention to the following points. Notes: • Replace only with a battery of the type recommended by Lenovo. Keep the battery pack away from fire. • Do not expose the battery pack to water or rain.

  • Page 29: Using The Touchpad

    Chapter 2. Learning the basics Using the touchpad Touchpad Left click button Right click button Note: You can enable/disable the touchpad using Fn+F8. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - To move the cursor on the screen, slide your fingertip over the pad in the direction in which you want the cursor to move.

  • Page 30: Using The Keyboard

    Chapter 2. Learning the basics Using the keyboard - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Your computer has a numeric keypad and function keys incorporated in its standard keyboard.

  • Page 31

    Chapter 2. Learning the basics Function key combinations Through the use of the function keys, you can change operational features instantly. To use this function, press and hold Fn function keys ; then press one of the...

  • Page 32

    The following describes the features of each function key. Fn + Esc: Turn on/off the integrated camera. Fn + F1: Enter standby/sleep mode. Turn on/off the LCD screen. Fn + F2: Fn + F3: Shift to other connected display devices. Open the interface for integrated wireless devices Fn + F5: settings (enable/disable).

  • Page 33: Special Buttons

    Chapter 2. Learning the basics Special buttons - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -...

  • Page 34

    • When the computer is powered-off, press this button to enter Lenovo Quick Start if it has been installed. Note: For details, see “Using Lenovo Quick Start (specific models only)” on page 27. • Under Windows operating systems, press this button to launch a self- defined program, file or a Website.

  • Page 35: System Status Indicators

    Chapter 2. Learning the basics System status indicators These indicators inform you of the computer status. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Hard disk drive indicator Caps lock indicator Num lock indicator...

  • Page 36: Securing Your Computer

    You are responsible for evaluating, selecting, and implementing the locking • devices and security features. Lenovo offers no comment, judgement, or warranty regarding the function, quality or performance of locking devices and security features. Chapter 2. Learning the basics...

  • Page 37: Using Passwords

    For details about how to set the password, see the help to the right of the screen in BIOS setup utility. Note: To enter BIOS setup utility, press F2 when the Lenovo logo appears on the screen while the computer is starting up.

  • Page 38: Connecting External Devices

    Connecting external devices Your computer has a wide range of built-in features and connection capabilities. Using memory cards (not supplied) Your computer supports the following types of memory cards: • Secure Digital (SD) card • MultiMediaCard (MMC) • Memory Stick (MS) •...

  • Page 39: Inserting A Memory Card

    Chapter 2. Learning the basics Inserting a memory card Push the dummy card until you hear a click. Gently pull the dummy card out of the memory card slot. Note: The dummy card is used for preventing dust and small particles from entering the inside of your computer when the memory card slot is not in use.

  • Page 40

    Connecting a universal serial bus (USB) device Your computer comes with three USB ports compatible with USB devices. Note: When using a high power consumption USB device such as USB ODD, use the external device’s power adapter. Otherwise, the device may not be recognized, or system shut down may result.

  • Page 41

    Chapter 2. Learning the basics Pairing devices Enable the Bluetooth function on the devices that you need to connect to the computer. Open My Bluetooth Places in All Programs from start menu, click Add a Bluetooth Device, follow the Bluetooth Setup Wizard to pair the devices.

  • Page 42: Using Lenovo Quick Start (specific Models Only)

    Using Lenovo Quick Start (specific models only) With a boot time of just a few seconds, Lenovo Quick Start offers a handy environment that allows you to enjoy an instant access to functions such as Web browsing, instant messaging and other entertainment functions without entering the traditional operating system.

  • Page 43

    Chapter 2. Learning the basics Starting Lenovo Quick Start Press the QS button when the computer is powered-off. The following will appear on the screen after a few seconds. Exiting Lenovo Quick Start • Click to restart the computer. • Click...

  • Page 44: Chapter 3. Using The Internet

    Chapter 3. Using the Internet As a global network, the Internet connects computers worldwide, providing services such as e-mailing, information searching, electronic commerce, Web browsing and entertainment. You can connect the computer to the Internet in the following ways: Wired connection: uses physical wiring to connect. Wireless network technology: connect without wiring.

  • Page 45: Hardware Connection

    Chapter 3. Using the Internet Hardware connection: Cable TV cable Splitter * Cable modem * * Not supplied. Note: The above diagrams are for reference only. Actual connection method may vary. Software configuration Consult your Internet Service Provider (ISP) for details on how to configure your computer.

  • Page 46: Wireless Connection

    Wireless connection Wireless connection provides mobile access to the Internet, allowing you to stay online anywhere the wireless signal covers. Divided by the signal scales, wireless connection to the Internet can be built based on the following standards. Wi-Fi Wi-Fi networks cover a small physical area, like a home, office, or small group of buildings.

  • Page 47

    Chapter 3. Using the Internet Using Wi-Fi/WiMax (specific models only) Enabling wireless connection To enable wireless communications, do the following: Slide the integrated wireless device switch to Press Fn + F5 to make configuration. Hardware connection Access point * Wi-Fi/WiMax network * Not supplied Software configuration Consult your Internet Service Provider (ISP) and search Windows Help and...

  • Page 48

    Notes: Various standards are in use by mobile operators to provide Mobile Broadband • services. The Lenovo Mobile Broadband module may support one or more of the following standards: GSM (Global System for Mobile Communications) TD-SCDMA (Time Division-Synchronous Code Division Multiple Access)

  • Page 49

    Chapter 3. Using the Internet • A connection management utility to connect/disconnect to your Mobile Broadband network. Note: In general, your mobile service provider provides this utility. Inserting the SIM card To insert the SIM card: Turn off the computer; then disconnect the AC adapter and all cables from the computer.

  • Page 50

    Put the battery back in place, turn the computer over again, and reconnect the cables. Removing the SIM card To remove the SIM card: Turn off the computer, then disconnect the AC adapter and all cables from the computer. Close the computer display and turn it over. Remove the battery.

  • Page 51: Chapter 4. Onekey Rescue System

    OneKey Rescue System Introduction The Lenovo OneKey Rescue System is an easy-to-use application that can be used to back up the data on your system partition (C drive) for easy restore when required. You can run Lenovo OneKey Recovery under a Windows operating system, and the OneKey Rescue System without starting the Windows operating system.

  • Page 52

    The program will save the backed up data to the default location, i.e., to D:\Lenovo\OneKey App\OneKey Recovery. You may also select another destination, such as a removable storage device, network drive or a CD/ DVD.

  • Page 53

    If your hard disk fails and you are unable to use Lenovo OneKey Recovery on your computer, you can use these discs to recover your system on a reformatted hard drive.

  • Page 54

    Windows system and data. Pressing the OneKey Rescue System key will activate Lenovo OneKey Rescue System when your PC is turned off. Within the program, you can restore your system partition to the original factory status, or to a previously generated backup. You may also transfer critical data or documents to other storage devices.

  • Page 55

    In order to save application files and the initial backed up files of the system, the hard disk in a Lenovo PC includes a hidden partition when it is shipped. If you need to restore the system to the point of your first boot up, just enter the Lenovo OneKey Rescue System and run Restore to factory default.

  • Page 56

    Back up my data Within the Lenovo OneKey Rescue System you can transfer your data from your computer’s hard disk to other devices, so you may easily find it if your Windows system ever encounters a critical failure.

  • Page 57: Chapter 5. Troubleshooting

    This section lists frequently asked questions and tell where you can find detailed answers. For details about each publication included in the package with your computer, see Lenovo IdeaPad S10-2 Setup Poster. What safety precautions should I follow when using my computer? See “Important safety information”...

  • Page 58

    See “Appendix A. Getting help and service” on page 64 of this guide. Where can I find warranty information? For the warranty applicable to your computer, including the warranty period and type of warranty service, see “Appendix C. Lenovo limited warranty” on page 82. How can I install the device drivers? A compatible device driver is a requirement to ensure correct operation and performance of each component in your computer.

  • Page 59

    Chapter 5. Troubleshooting When do I need to use the Restore to factory default feature? You can use this feature when your system fails or you need to re-install your operating system. This will restore your computer back to the initial status when you first booted up your computer after receiving it from the store.

  • Page 60: Troubleshooting

    Troubleshooting If you do not find your problem here, see Chapter 2. The following section only describes problems that might negate the need to refer to the more comprehensive information in Chapter 2. Display problems When I turn on the compu- ter, nothing appears on the screen.

  • Page 61

    - Press any key on the keyboard. - Press the power button. • If you forget your user password, you must take your computer to a Lenovo authorized servicer or a marketing representative to have the password changed. • If you forget your HDD password, a Lenovo authorized servicer cannot reset your password or recover data from the hard disk.

  • Page 62

    Keyboard problems A number appears when you enter a letter. Standby or hibernation problems The computer enters standby mode unexpect- edly. The computer enters standby mode immediately after Power-on self-test (POST). Note: If the battery is charged and the temperature is within range, have the computer serviced.

  • Page 63

    Chapter 5. Troubleshooting The computer does not return from standby mode and does not work. Note: If the system still does not return from standby mode, your system has stopped responding, and you cannot turn off the computer, reset the computer. However, unsaved data may be lost.

  • Page 64

    Computer screen problems The screen is blank. The screen is unreadable or distorted. Incorrect characters appear on the screen. Chapter 5. Troubleshooting • Do the following: - If you are using the AC adapter, or using the battery, and the battery status indicator is on, press Fn + ↑...

  • Page 65

    Chapter 5. Troubleshooting Sound problems No sound can be heard from the speaker even when the volume is turned Battery problems Your computer shuts down before the battery status indicator shows empty. -or- Your computer operates after the battery status indicator shows empty.

  • Page 66

    A startup problem ® The Microsoft Windows operating system does not start. OneKey Rescue System problems Full backup cannot be made. Incremental backup cannot be made. Chapter 5. Troubleshooting • Use the OneKey Rescue System to help solve or identify your problem. For details on the OneKey Rescue System, see “Chapter 4.

  • Page 67

    Chapter 5. Troubleshooting A prompt to repair system kernel files appears. Restore to factory default feature cannot be used. Other problems The computer does not respond. The computer does not start from the desired device. The connected external device does not work. •...

  • Page 68: Chapter 6. Upgrading And Replacing Devices

    Chapter 6. Upgrading and replacing devices Replacing the battery Note: Use only the battery provided by Lenovo. Any other battery could ignite or explode. To replace the battery Turn off the computer, or enter hibernation mode. Disconnect the AC adapter and all cables from the computer.

  • Page 69

    Chapter 6. Upgrading and replacing devices Install a fully charged battery. Slide the manual battery latch to the locked position. Turn the computer over again. Connect the AC adapter and the cables to the computer again.

  • Page 70: Replacing The Hard Disk Drive

    Replacing the hard disk drive You can increase the storage capacity of your computer by replacing the hard disk drive with one of greater capacity. You can purchase a new hard disk drive from your reseller or Lenovo marketing representative. Notes: •...

  • Page 71

    Chapter 6. Upgrading and replacing devices To replace the hard disk drive, do the following: Turn off the computer; then disconnect the AC adapter and all cables from the computer. Close the computer display, and then turn the computer over. Remove the battery pack.

  • Page 72

    Remove the screw that secures the hard disk. Pull the tab in the direction shown by arrow Chapter 6. Upgrading and replacing devices...

  • Page 73

    Chapter 6. Upgrading and replacing devices Take out the hard disk drive secured in a metal frame Remove the screws and detach the metal frame from the hard disk drive. Attach the metal frame to a new hard disk drive; then tighten the screws.

  • Page 74

    Reinstall the screws. Reinstall the battery pack. Turn the computer over again. Connect the AC adapter and the cables to the computer again. Chapter 6. Upgrading and replacing devices...

  • Page 75: Replacing Memory

    Chapter 6. Upgrading and replacing devices Replacing memory You can increase the amount of memory in your computer by replacing a double data rate (DDR2) small outline dual inline memory module (SO- DIMM)-available as an option-in the memory slot of your computer. SO- DIMMs are available in various capacities.

  • Page 76

    Chapter 6. Upgrading and replacing devices Remove the Memory compartment cover. a. Remove the screws that secure the compartment cover b. Remove the compartment cover...

  • Page 77

    Chapter 6. Upgrading and replacing devices Press outwards on the latches on both edges of the socket at the same time, remove the SO-DIMM. Be sure to save the old SO-DIMM for future use. Insert the notched end of the DIMM into the socket. Press the DIMM firmly, and pivot it until it snaps into place.

  • Page 78

    To make sure that the SO-DIMM is installed correctly, do as follows: Turn the computer on. Hold F2 during startup. The BIOS setup utility screen opens. The System Memory item shows the total amount of memory installed in your computer. The following table provides a list of CRUs (Customer Replaceable Units) for your computer, and informs you of where to find replacement instructions.

  • Page 79: Appendix A. Getting Help And Service

    Appendix A. Getting help and service If you need help, service, technical assistance, or just want more information about Lenovo computers, you will find a wide variety of sources available from Lenovo to assist you. This section contains information about where to go for additional information about Lenovo computers, what to do if you experience a problem with your computer, and whom to call for service should it be necessary.

  • Page 80: Getting Help On The Web

    • Lenovo hardware repair - If the problem is determined to be caused by Lenovo hardware under warranty, trained service personnel are available to provide the applicable level of service.

  • Page 81

    Appendix A. Getting help and service • Engineering change management - Occasionally, there might be changes that are required after a product has been sold. Lenovo or your reseller, if authorized by Lenovo, will make selected Engineering Changes (ECs) available that apply to your hardware.

  • Page 82

    Note: For the latest list of customer support center telephone numbers and hours of operation, visit the Support Web site at http://consumersupport.lenovo.com. If the number for your country or region is not listed, contact your Lenovo reseller or Lenovo marketing representative.

  • Page 83: Getting Help Around The World

    A list of warranty service telephone numbers is available at www.lenovo.com/support/phone. For the latest warranty service number in a country or region, please contact Lenovo, or your reseller in your country or region. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -...

  • Page 84: Appendix B. Use, And Care Information

    Appendix B. Use, and care Information Caring your computer Though your computer is designed to function reliably in normal work environments, you need to use common sense in handling it. By following these important tips, you will get the most use and enjoyment out of your computer.

  • Page 85

    Appendix B. Use, and care Information discharge from your body or clothing to the computer, it poses the same risk of a computer malfunction. Your computer is designed and manufactured to minimize any effects of electrostatic charge. An electrostatic charge above a certain limit, however, can increase the risk of ESD.

  • Page 86

    - When you install a static-sensitive option or CRU, touch the static- protective package containing the part to a metal expansion-slot cover or other unpainted metal surface on the computer for at least two seconds. This reduces static electricity in the package and your body. - Whenever possible, remove the static-sensitive part from the static- protective packaging and install the part without setting it down.

  • Page 87

    Appendix B. Use, and care Information • When picking up your open computer, hold it by the bottom. Do not pick up or hold your computer by the display. • Use a quality carrying case that provides adequate cushion and protection.

  • Page 88

    Take care in setting passwords • Remember your passwords. If you forget a supervisor or hard disk password, Lenovo authorized service providers will not reset it, and you might have to replace your system board or hard disk drive. Other important tips •...

  • Page 89

    Appendix B. Use, and care Information • Register your Lenovo products with Lenovo (refer to the Web page: http://consumersupport.lenovo.com). This can help authorities return your computer to you if it is lost or stolen. Registering your computer also enables Lenovo to notify you about possible technical information and upgrades.

  • Page 90: Accessibility And Comfort

    Accessibility and comfort Ergonomic information Working in the virtual office may mean adapting to frequent changes in your environment. Following some simple rules will make things easier and bring you the maximum benefits of your computer. Keeping in mind such basics as good lighting and proper seating, for example, can help you improve your performance and achieve greater comfort.

  • Page 91

    Appendix B. Use, and care Information What if you are traveling? It may not be possible to observe the best ergonomic practices when you are using your computer while on the move or in a casual setting. Regardless of the setting, try to observe as many of the tips as possible. Sitting properly and using adequate lighting, for example, will help you maintain desirable levels of comfort and performance.

  • Page 92: Maintenance

    • At least once a week, make a point to back up your data. If critical data is present, it is a good idea to perform a daily backup. Lenovo has many backup options available for your computer. CD-RW drives and CD-RW/DVD drives are available for most computers and are easily installed.

  • Page 93

    • Profile your machine at http://consumersupport.lenovo.com to keep up to date with current drivers and revisions. • Keep up to date on device drivers on other non-Lenovo hardware. You might want to read the device driver information release notes prior to updating for compatibility or known issues.

  • Page 94

    Cleaning the cover of your computer Occasionally clean your computer as follows: Prepare a mixture of a gentle kitchen-use detergent (one that does not contain abrasive powder or strong chemicals such as acid or alkaline). Use 5 parts water to 1 part detergent. Absorb the diluted detergent into a sponge.

  • Page 95: Cleaning Your Computer Keyboard

    Appendix B. Use, and care Information Cleaning your computer keyboard Absorb some isopropyl rubbing alcohol on a soft, dust-free cloth. Wipe each keytop surface with the cloth. Wipe the keys one by one; if you wipe several keys at a time, the cloth may hook onto an adjacent key and possibly damage it.

  • Page 96

    Cleaning your computer display Gently wipe the display with a dry, soft lint-free cloth. If you see a scratchlike mark on your display, it might be a stain transferred from the keyboard when the cover was pressed from the outside. Wipe or dust the stain gently with a soft, dry cloth.

  • Page 97: Appendix C. Lenovo Limited Warranty

    What this warranty covers Lenovo warrants that each hardware product that you purchase is free from defects in materials and workmanship under normal use during the warranty period. The warranty period for the product starts on the original date of purchase specified on your sales receipt or invoice unless Lenovo informs you otherwise in writing.

  • Page 98

    How to obtain warranty service If the product does not function as warranted during the warranty period, you may obtain warranty service by contacting Lenovo or an approved service provider. Each of them is referred to as a “Service Provider.” A list of Service Providers and their telephone numbers is available at www.lenovo.com/support/phone.

  • Page 99

    If your Service Provider determines that it is unable to either repair or replace your product, your sole remedy is to return the product to your place of purchase or to Lenovo for a refund of your purchase price.

  • Page 100

    Only unaltered Lenovo products and parts are eligible for replacement. The replacement product or part provided by Lenovo may not be new, but it will be in good working order and at least functionally equivalent to the original product or part. The replacement product or part shall be warranted for the balance of the period remaining on the original product.

  • Page 101

    Personal Data that you did not delete, you are in compliance with all applicable laws. Use of personal information If you obtain service under this warranty, Lenovo will store, use and process information about your warranty service and your contact information, including name, phone numbers, address, and e-mail address. Lenovo will use this information to perform service under this warranty and to improve our business relationship with you.

  • Page 102

    • damage caused by a non-authorized service provider; • failure of, or damage caused by, any third party products, including those that Lenovo may provide or integrate into the Lenovo product at your request; and • any technical or other support, such as assistance with “how-to”...

  • Page 103

    Appendix C. Lenovo limited warranty Limitation of liability Lenovo is responsible for loss or damage to your product only while it is: 1) in your Service Provider’s possession; or 2) in transit in those cases where the Service Provider is responsible for the transportation.

  • Page 104

    Appendix C. Lenovo limited warranty UNDER NO CIRCUMSTANCES SHALL LENOVO, ITS SUPPLIERS, RESELLERS, OR SERVICE PROVIDERS BE LIABLE FOR ANY OF THE FOLLOWING EVEN IF INFORMED OF THEIR POSSIBILITY: 1) THIRD PARTY CLAIMS AGAINST YOU FOR DAMAGES; 2) LOSS OR DAMAGE TO YOUR DATA;...

  • Page 105

    CANNOT BE WAIVED OR LIMITED BY CONTRACT. European Economic Area (EEA) Customers in the EEA may contact Lenovo at the following address: EMEA Service Organisation, Lenovo (International) B.V., Floor 2, Einsteinova 21, 851 01, Bratislava, Slovakia. Service under this warranty for Lenovo hardware products purchased in EEA countries may be obtained in any EEA country in which the product has been announced and made available by Lenovo.

  • Page 106: Warranty Information

    Appendix C. Lenovo limited warranty - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -...

  • Page 107

    An optional service offering may be available for purchase from Lenovo to have Lenovo install Self-service CRUs for you. You may find a list of CRUs and their designation in the publication that ships with your product or at www.lenovo.com/CRUs.

  • Page 108

    Under On-Site Service, your Service Provider will either repair or exchange the product at your location. You must provide a suitable working area to allow disassembly and reassembly of the Lenovo product. For some products, certain repairs may require your Service Provider to send the product to a designated service center.

  • Page 109

    You may be charged for the replacement product if Lenovo does not receive the failed product within thirty (30) days of your receipt of the replacement product.

  • Page 110: Appendix D. Customer Replaceable Units (crus)

    Customers are responsible for replacing all external CRUs. Internal CRUs can be removed and installed by customers or by a Lenovo service technician during the warranty period. Your computer contains the following types of external CRUs: •...

  • Page 111

    Appendix D. Customer replaceable units (CRUs) Your computer contains the following types of internal CRUs: • Internal CRUs (located behind an access panel): These CRUs are isolated parts within the computer that are concealed by an access panel that is typically secured by either one or two screws. Once the access panel is removed, only the specific CRU is visible.

  • Page 112: Appendix E. Notices

    Consult your local Lenovo representative for information on the products and services currently available in your area. Any reference to a Lenovo product, program, or service is not intended to state or imply that only that Lenovo product, program, or service may be used.

  • Page 113

    Web sites. The materials at those Web sites are not part of the materials for this Lenovo product, and use of those Web sites is at your own risk. Any performance data contained herein was determined in a controlled environment.

  • Page 114

    Appendix E. Notices made on development-level systems and there is no guarantee that these measurements will be the same on generally available systems. Furthermore, some measurements may have been estimated through extrapolation. Actual results may vary. Users of this document should verify the applicable data for their specific environment.

  • Page 115: Energy Star Model Information

    Lenovo is proud to offer our customers products with an ENERGY STAR compliant designation. Lenovo computers of the following machine types, if the ENERGY STAR mark is affixed, have been designed and tested to conform to the ENERGY STAR program requirements for computers.

  • Page 116

    Lenovo encourages you to make efficient use of energy an integral part of your day-to-day operations. To help in this endeavor, Lenovo has preset the following power-management features to take effect when your computer has been inactive for a specified duration: Table 1.

  • Page 117: Wireless Related Information

    Appendix E. Notices Wireless related information Wireless interoperability Wireless LAN PCI Express Mini Card is designed to be interoperable with any wireless LAN product that is based on Direct Sequence Spread Spectrum (DSSS), Complementary Code Keying (CCK), and/or Orthogonal Frequency Division Multiplexing (OFDM) radio technology, and is compliant to: •...

  • Page 118

    Due to the fact that wireless LAN PCI Express Mini Card and Bluetooth Daughter Card operate within the guidelines found in radio frequency safety standards and recommendations, Lenovo believes the integrated wireless cards are safe for use by consumers. These standards and...

  • Page 119

    Appendix E. Notices result from deliberations of panels and committees of scientists who continually review and interpret the extensive research literature. In some situation or environment, the use of wireless LAN PCI Express Mini Card or Bluetooth Daughter Card may be restricted by the proprietor of the building or responsible representatives of the organization.

  • Page 120

    Use of mobile devices on board aircraft is explicitly prohibited by many airlines companies, especially during take-off and landing. The built-in Mobile Broadband module on your computer is a low-power radio transceiver. When it is turned on, it intermittently receives and transmits radio frequency (RF) energy which could cause interference with the operation of the airplane communication or navigation system.

  • Page 121: Electronic Emissions Notices

    Appendix E. Notices Electronic emissions notices The following information refers to Lenovo IdeaPad S10-2, machine type 20027 2957. Federal Communications Commission (FCC) Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 122

    Appendix E. Notices available from Lenovo authorized dealers. Lenovo is not responsible for any radio or television interference caused by using other than recommended cables or connectors or by unauthorized changes or modifications to this equipment. Unauthorized changes or modifications could void the user’s authority to operate the equipment.

  • Page 123

    Um dieses sicherzustellen, sind die Geräte wie in den Handbüchern beschrieben zu installieren und zu betreiben. Des Weiteren dürfen auch nur von der Lenovo empfohlene Kabel angeschlossen werden. Lenovo übernimmt keine Verantwortung für die Einhaltung der Schutzanforderungen, wenn das Produkt ohne Zustimmung der Lenovo verändert bzw.

  • Page 124

    Dieses Gerät ist berechtigt, in Übereinstimmung mit dem Deutschen EMVG das EG-Konformitätszeichen - CE - zu führen. Verantwortlich für die Konformitätserklärung nach Paragraf 5 des EMVG ist die Lenovo (Deutschland) GmbH, Gropiusplatz 10, D-70563 Stuttgart. Informationen in Hinsicht EMVG Paragraf 4 Abs. (1) 4: Das Gerät erfüllt die Schutzanforderungen nach EN 55024 und EN 55022...

  • Page 125

    TV communications and to other electrical or electronic equipment. Such cables and connectors are available from Lenovo authorized dealers. Lenovo cannot accept responsibility for any interference caused by using other than recommended cables and connectors.

  • Page 126

    Appendix E. Notices Lenovo Product Service Information Japanese VCCI Class B Statement...

  • Page 127

    Appendix E. Notices Japan Compliance Statement for Power line Harmonics A statement of compliance to the IEC 61000-3-2 harmonics standard is required for all products connecting to the power mains and rated less than 20A per phase. Korea Class B...

  • Page 128: Weee And Recycling Statements

    General recycling statement Lenovo encourages owners of information technology (IT) equipment to responsibly recycle their equipment when it is no longer needed. Lenovo offers a variety of programs and services to assist equipment owners in recycling their IT products. Information on product recycling offerings can be found on Lenovo’s Internet site at...

  • Page 129: Eu Weee Statements

    For additional WEEE information go to: http://consumersupport.lenovo.com. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -...

  • Page 130: Japan Recycling Statements

    Collecting and Recycling a Disused Lenovo Computer or Monitor If you are a company employee and need to dispose of a Lenovo computer or monitor that is the property of the company, you must do so in accordance with the Law for Promotion of Effective Utilization of Resources.

  • Page 131

    You also can refer to the instructions at www.ibm.com/jp/pc/environment/recycle/battery http://www.ibm.com/jp/pc/environment/recycle/battery If you use a Lenovo notebook computer at home and need to dispose of a battery pack, you must comply with local ordinances and regulations. You also can refer to the instructions at www.ibm.com/jp/pc/environment/recycle/battery...

  • Page 132: Notice For Users In The U.s.a

    Appendix E. Notices Notice for users in the U.S.A. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - California Perchlorate Information: Products containing CR (manganese dioxide) lithium coin cell batteries may contain perchlorate.

  • Page 133

    Appendix E. Notices • Format your hard disk, using the software for initializing it. • Using the preinstalled recovery program, bring the hard disk back to factory-ship state. These operations, however, only change the file allocation of the data; they do not delete the data itself.

  • Page 134: Appendix F. Features And Specifications

    Appendix F. Features and specifications Model Name: IdeaPad S10-2 Note: The following specifications may contain technical inaccuracies or typographical errors. Lenovo reserves the right to improve and/or change specifications at any time without notice. Form Factor Size Weight System Memory...

  • Page 135

    Appendix F. Features and specifications I/O Ports Communication Audio Video Memory card slot Kensington slot USB 2.0 port x 3 RJ-45 port Headphone/Mic-In Jack D-sub port 4 in 1 slot x 1 (MMC/SD/MS/MS PRO)

  • Page 136: Trademarks

    - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Trademarks Lenovo, the Lenovo logo, IdeaPad, VeriFace, OneKey Rescue (OneKey Recovery, OneKey AntiVirus), APS, Power Express, Energy Management and ReadyComm are either registered trademarks or trademarks of Lenovo in the United States and/or other countries.

  • Page 137: Index

    Index AC adapter ... 11 Using Battery ... 11 Charging Bluetooth ... 25 Connecting ... 102 Interoperability ... 103 Usage environment ... 2, 17 Camera ... 23 Card reader ... 69 Caring your computer Cleaning ... 79 Computer cover ... 81 Computer display Computer keyboard ...

  • Page 138

    ... 4 Kensington slot Keyboard ... 79 Cleaning ... 47 Problems ... 15 Using ... 82 Lenovo Limited Warranty Maintenance ... 77 Microphone ... 2 Built-in Notice ... 106 Electronic emissions for US users ... 117 ... 15 Numeric Keypad...

  • Page 139

    Index ... 21 Security Storage media ... 72 Handling ... 14 Touch pad ... 121 Trademarks ... 45 Troubleshooting ... 3 USB port ... 22 VeriFace ... 91 Warranty information ... 65 Help Wireless LAN ... 2 Antennas ... 102 Interoperability ...

  • Page 140

    New World. New Thinking. www.lenovo.com P/N: 147002310 Printed in China...

This manual also for:

29577du, 29577mu, 2957l2u, 2957l3u

Comments to this Manuals

Symbols: 0
Latest comments:
