Silver Eagle SE351 Operating Instructions Manual

Straight line die grinder
Table of Contents

Advertisement

Available languages

Available languages

Quick Links

Operating Instructions
SPECIFICATIONS
Rec. Air Pressure . . . . . . . . . . . . . . . . . . . . . . . . 90 PSI
Air Consumption . . . . . . . . . . . . . . . . . . . . . . . . 4 CFM
RPM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25,000
Air Inlet Thread . . . . . . . . . . . . . . . . . . . . . . 1/4" NPTF
Rec. Hose ID. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3/8"
• MAXIMUM RPM OF 25,000
• MAX AIR PRESSURE: 90
PSIG, 6.2 BAR
• RPM OF THE ACCESSORY
MUST EXCEED TOOL RPM
ALWAYS READ
INSTRUCTIONS
BEFORE USING
POWER TOOLS
ALWAYS WEAR
SAFETY GOGGLES
WEAR HEARING
PROTECTION
AVOID
PROLONGED
EXPOSURE TO
VIBRATION
SE351
.30 HP Straight Line Die Grinder
Warning Information
Collet Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1/4"
Sound Power Level . . . . . . . . . . . . . . . . . . . . 87.1 dBA
Sound Pressure Level . . . . . . . . . . . . . . . . . . 74.1 dBA
Overall Length . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1/2"
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 Lb.
Some dust created by power sanding, sawing, grinding, drilling, and other construction
activities contains chemicals known to cause cancer, birth defects or other reproductive
harm. Some examples of these chemicals are:
• Lead from lead-based paints,
• Crystalline silica from bricks and cement and other masonry products, and
• Arsenic and chromium from chemically-treated lumber.
Your risk from these exposures varies, depending on how often you do this type of
work. To reduce your exposure to these chemicals: work in a well ventilated area, and
work with approved safety equipment, such as those dust masks that are specially
designed to filter out microscopic particles.
Copyright © Professional Tool Products, 2006
1
SE351
Parts Breakdown
All rights reserved.
09/06/06
