Calcinara Tap
TAP9160, TAP8320
Guarantee (UK only):
Your tap has the benefit of a comprehensive manufacturer's guarantee, details of which are shown on your Proof
of Purchase Document. Any claim during the period of the guarantee must be accompanied by the Proof of
Purchase. The product must be correctly installed and operated in accordance with the manufacturer's instructions
and used for normal domestic purposes. This guarantee does not cover accidental damage, misuse or alterations
which are likely to affect the product. The guarantee is invalid if the product is tampered with, or repaired by any
unauthorised person. The guarantee in no way affects your statutory or legal rights.
Care Instructions for your Kitchen Sink Mixer:
To maintain the appearance of this tap, ensure that it is regularly cleaned only using a clean, soft damp cloth. A
solution of warm water and a mild liquid detergent may be used where necessary, and then the fitting rinsed
thoroughly and wiped dry. Any other cleaning action will invalidate your warranty.
Abrasive cleaners, scouring cleaners and acidic cleaners must not be used under any circumstances. Avoid
contact with all solvents (including chlorinated solvents, ketones or acetones as these may result in surface
deterioration or etching). Also avoid contact with any harsh household chemicals such as oven cleaners, drain
cleaners, rust removers, paint strippers and toilet bowl cleaners, bar keepers friend or Brasso.
Where the tap has a removable aerator on the spout exit it can be removed and cleaned periodically to maintain
optimum flow performance.
Important Technical Data:
Minimum operating pressure: 1.0 bar
Maximum operating pressure: 5.5 bar*
Flow characteristics: Single flow
*If these temperatures or pressures are exceeded, even for short periods, damage can result. In these instances a
thermostatic mixing or pressure reducing valve should be installed.
This product is either manufactured in accordance with recognised European standards. Please ensure that your
Kitchen mixer is fitted in accordance with Local Water Byelaws. Where hot and cold water mix within the mixertap,
then suitable non return (check) valves should be installed to the hot and cold supplies to prevent backflow.
Hot and cold supply pressures should be as closely balanced as possible for best results. Supply pipes should
maintain the maximum diameter until immediately before the fitting. The differential between the hot and cold water
supply temperatures should be sufficient to allow correct mixing function.
These installation guidelines have been prepared for your direction and you must exercise due care at all times.
We do not accept responsibility for problems that may occur through improper installation. Whilst assembling the
tap take care not to accidentally loosen any factory fixed assemblies.
This tap has been 100% assembly tested; therefore you may expect a small residual amount of water to remain in
the tap when delivered. Any water marks can be removed using the above care advice.
Installation Preparation:
Maximum hot water temperature: 70°C*
Recommended hot water temperature: 46°C
07-21
TAP9160, TAP8320-v3

Advertisement

loading
Need help?

Need help?

Do you have a question about the TAP9160 and is the answer not in the manual?

Questions and answers

Summary of Contents for Lamona TAP9160

  • Page 1 Calcinara Tap TAP9160, TAP8320 07-21 Guarantee (UK only): Your tap has the benefit of a comprehensive manufacturer’s guarantee, details of which are shown on your Proof of Purchase Document. Any claim during the period of the guarantee must be accompanied by the Proof of Purchase.
  • Page 2 All parts should be removed from their packaging and inspected for completeness and transport damage prior to installation. Before installing the new mixer it is essential that you thoroughly flush through the supply pipes in order to remove any remaining solder, swarf or impurities from your system. Failure to carry out this simple procedure could cause problems or damage to the workings of the mixertap and invalidate the warranty.
  • Page 3 Lower gasket Rubber horseshoe Metal horseshoe Fixing nut Hot water flexible tail pipe Cold water flexible tail pipe After installation: Once you have visually checked the installation of the new tap and all connections, ensure that all other fittings are closed except the new tap which should be left open.
  • Page 4 • The braiding on the flexible hose must not be in contact with any scarcely aggressive chemicals, internal or external room walls or dissimilar metals or materials. • Observe the minimum bend radius of 50mm, hoses must not be 50mmØ kinked or looped.
