Related Manuals for OtalgiaFX BC182L FUZZ
Summary of Contents for OtalgiaFX BC182L FUZZ
- Page 1 OtalgiaFX BC182L FUZZ “Meaty fuzz in both standard and dark flavours” Build Guide October 2019 www.otalgiafx.co.uk...
- Page 2 PART VALUE DEVICE TYPE BILL OF REQUIREMENTS CAPACITORS PART LIST 47uF Polarised Electrolytic, 25v (or higher) 10nf 5mm Polyester Box, 63v (or higher) 470pf Ceramic, 50v (or higher) 47pf Ceramic, 50v (or higher) 22nf 5mm Polyester Box, 63v (or higher) 10uF Polarised Electrolytic, 25v (or higher) ** If building the “Dark”...
- Page 3 BILL OF REQUIREMENTS PART VALUE DEVICE TYPE PART LIST (ctd) POTENTIOMETERS B500K 16mm Linear, Pin Terminals...
- Page 4 BUILDERS NOTES In the parts list each component has a component number. This number corresponds to the placement number silk screen printed on the top of the PCB. Components should be mounted on the printed side of the PCB and soldered into place on the underside of the board.
- Page 5 BUILDERS NOTES (ctd) Transistors- The transistors will need to be orientated correct and match the placement image marked on the PCB. If you intend to use transistors that differ from the build list then please be aware than the Collector, Base and Emitter legs may be in a different order.
- Page 6 BUILDERS NOTES (ctd) When mounting this circuit into an enclosure the potentiometer will hold the PCB in place within the enclosure and stop the circuit board from moving around. Please take care when mounting the potentiometer not to over tighten the nut or you might damage the potentiometers thread.
- Page 7 7. Plug in the power supply and test the circuit is working. If it is then you can proceed to off board wiring. The easiest way to perform off board wiring is to use a 3PDT switch daughterboard - https://www.otalgiafx.co.uk/wp-content/uploads/2017/09/3PDT-Instructions.pdf...
- Page 8 Schematic...
