OtalgiaFX MOSFET BOOST “A nice clean Mosfet booster based on a popular crackling boutique pedal ” Build Guide October 2019 www.otalgiafx.co.uk...
PART VALUE DEVICE TYPE BILL OF REQUIREMENTS CAPACITORS PART LIST 100nf 5mm Polyester Box, 63v (or higher) 10uF Polarised Electrolytic, 25v (or higher) DIODES Zener RESISTORS 1/4W Through Hole, Metal Film 1/4W Through Hole, Metal Film 1/4W Through Hole, Metal Film 100K 1/4W Through Hole, Metal Film TRANSISTOR...
Page 3
BUILDERS NOTES In the parts list each component has a component number. This number corresponds to the placement number silk screen printed on the top of the PCB. Components should be mounted on the printed side of the PCB and soldered into place on the underside of the board.
Page 4
BUILDERS NOTES (ctd) Diodes - A diode has 2 sides - a Cathode and Anode. The Cathode side of a diode has a circular band printed around the body of the component to aid identification. The PCB is printed to also showing this this marking to aid correct orientation.
Page 5
BUILDERS NOTES (ctd) When mounting this circuit into an enclosure the potentiometer will hold the PCB in place within the enclosure and stop the circuit board from moving around. Please take care when mounting the potentiometer not to over tighten the nut or you might damage the potentiometers thread.
Page 6
7. Plug in the power supply and test the circuit is working. If it is then you can proceed to off board wiring. The easiest way to perform off board wiring is to use a 3PDT switch daughterboard - https://www.otalgiafx.co.uk/wp-content/uploads/2017/09/3PDT-Instructions.pdf...
