BEFORE YOU BEGIN
BEFORE YOU BEGIN
·
Please read these instructions carefully to familiarize
yourself with the required tools, materials, and installation
sequences. Follow the sections that pertain to your
particular installation. This will help you avoid costly
mistakes. In addition to proper installation, read all
operating and safety instructions.
·
All information in these instructions is based upon the
latest product information available at the time of
publication. Kohler China reserves the right to make
changes in product characteristics, packaging, or
availability at any time without notice.
·
These instructions contain important care, cleaning, and
warranty information-please leave instructions for the
consumer.
ORDERING INFORMATION
OVE WH Toilet(HT100 TL IWT)..........................K-24719T-S2
Includes Bowl...................................................K-19957T-2
Includes HYDRO-TOWER 100
Touchless Inwall Tank..................K-6281T-VES2
Includes
OVE Quiet-close Toilet Seat ...............K-17676T
®
OVE WH Toilet(HT100 TL IWT) ............................K-24719T-2
Includes Bowl...................................................K-19957T-2
Includes HYDRO-TOWER 100
Touchless Inwall Tank ....................K-6281T-VE2
Includes
OVE Toilet Seat...................................K-17671T
®
OVE WH Toilet(HT300 MEC IWT) ......................K-24720T-S2
Includes Bowl...................................................K-19957T-2
Includes HYDRO-TOWER 300
Inwall Tank with Frame ................K-4178T-VES2
Includes
OVE Quiet-close Toilet Seat ...............K-17676T
®
OVE WH Toilet(HT300 MEC IWT) ........................K-24720T-2
Includes Bowl...................................................K-19957T-2
Includes HYDRO-TOWER 300
Inwall Tank with Frame...................K-4178T-VE2
Includes
OVE Toilet Seat...................................K-17671T
®
OVE WH Toilet(HT100 MEC IWT) ......................K-24721T-S2
Includes Bowl...................................................K-19957T-2
Includes HYDRO-TOWER 100
In-Wall Tank with Frame ..............K-6284T-VES2
Includes
OVE Quiet-close Toilet Seat ...............K-17676T
®
OVE WH Toilet(HT100 MEC IWT) ........................K-24721T-2
Includes Bowl...................................................K-19957T-2
Includes HYDRO-TOWER 100
In-Wall Tank with Frame.................K-6284T-VE2
Includes
OVE Toilet Seat...................................K-17671T
®
KOHLER CHINA INVESTMENT CO., LTD
1363380-T01-B
K-24719T-S2/K-24719T-2/K-24720T-S2/K-24720T-2/K-24721T-S2/K-24721T-2
K-24083T-GS2/K-24081T-CPS2/K-24081T-BNS2/K-24082T-CPS2/K-24082T-BNS2
JING'AN DISTRICT, SHANGHAI, PRC
(
)
VITREOUS CHINA WALL-HUNG P-TRAP TOILET
·
·
·
(
..............................................................K-19957T-2
100
(
..............................................................K-19957T-2
100
...............................................K-17671T
(
..............................................................K-19957T-2
300
.......................................K-4178T-VES2
(
..............................................................K-19957T-2
300
.........................................K-4178T-VE2
...............................................K-17671T
(
..............................................................K-19957T-2
100
.......................................K-6284T-VES2
(
..............................................................K-19957T-2
100
.........................................K-6284T-VE2
...............................................K-17671T
NO.158, JIANG CHANG SAN ROAD,
POST CODE: 200436
158
©
Copyright Kohler China Investment Co., Ltd. 2018
-1-
©
OVE
INSTALLATION INSTRUCTIONS
100
) .......K-24719T-S2
........................K-6281T-VES2
........................................K-17676T
100
)..........K-24719T-2
...........................K-6281T-VE2
300
) ..............K-24720T-S2
........................................K-17676T
300
).................K-24720T-2
100
) ..............K-24721T-S2
........................................K-17676T
100
).................K-24721T-2
200436
-
2018
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Kohler OVE K-24719T-S2
Summary of Contents for Kohler OVE K-24719T-S2
- Page 1 · · All information in these instructions is based upon the latest product information available at the time of publication. Kohler China reserves the right to make changes in product characteristics, packaging, or availability at any time without notice. ·...
- Page 2 OVE WH Toilet (BEAM M FV)......K-24083T-GS2 )....K-24083T-GS2 Includes Bowl ..........K-80175T-GS2 ............K-80175T-GS2 Includes BEAM Manual Toilet/Squat ............K-77682K-G Flush Valve........K-77682K-G ........K-17676T Includes OVE Quiet-close Toilet Seat ....K-17676T ® ) ....K-24081T-CPS2 OVE WH Toilet (BEAM SR D/CP)....K-24081T-CPS2 ............K-24084T-DPS2 Includes Bowl ...........K-24084T-DPS2 .........K-30947T-CP Includes BEAM Toilet Sensor (DC) ....K-30947T-CP Includes OVE Quiet-close Toilet Seat ....K-17676T ........K-17676T...
- Page 3 ROUGHING-IN UNIT: mm Reference Value of Outlet Fig.#1 Kohler reserves the right to change marked dimensions without prior notice. INSTALLATION 1. Install Flushing Mechanism 1-1. Install The Tank 1-1. 1) Turn the water supply off before installing the new toilet.
- Page 4 2. Set The Spacing Of The Bowl After you install the tank, be careful to set the spacing of the bowl on wall according to the dimensions as shown. Unit: mm Carrier Studs 25 2 Fig.#2 3. Attach Connection Pipe ·...
-
Page 5: Finish The Installation
4. Install The New Bowl Apply a little silicone sealant along the edge, to fill the gap between bowl and wall. See Fig. 4a. Fig. #4a Place the new bowl on the wall through the carrier. Wrench the nut to tighten and make them attached securely. See Fig. - Page 6 CAUTION: Do not use any cement while installing the toilet. Heat expansion of the toilet may damage the feet of the toilet. Kohler will not be responsible for any damage because of using cement. WARNING: Risk of product damage. Do not throw into the toilet what is easy to block it, such as newspaper, paper pilch, sanitary towel.
-
Page 7: Before You Begin
Kohler will not be responsible for any damage related to above mentioned cleanser or solvent. Mild detergent can be used. Do not apply spares that are not provided by Kohler, and please note that glass adhesive tape shall not be applied to the installation of Kohler spares. -
Page 8: Function Explanation
) ..........................K-4178T 3.0/6.0 ) ......................K-4178T-VES2 3.0/6.0 ) ......................K-4178T-VE2 3.5/6.0 ) ....................K-4178T-ESS 300 3.0/4.5 ............................K-4179T 3.5/5.0 ) ......................K-4179T-VLS 3.5/5.0 ) ....................K-4179T-DNSW 3.5/5.0 ).......................K-4179T-DNW 3.5/5.0 ) ......................K-4179T-VABW 3.5/5.0 ) ......................K-4179T-RES 300 3.0/4.5 ........................K-10611T 3.5/5.0 ) .....................K-10611T-RES 3.5/5.0 ) ..................K-10611T-ESS 3 /4.5 ) ....................K-10611T-VLS 3 /4.5 ) ....................K-10611T-VLSL )............................K-4177T... -
Page 9: Specifications
Advantages Of In-wall Tank Made of macromolecular materials that prevents corrison and leaking. Advanced water tank fitting, which makes possible the adjustment of the water discharge and double flush. Will not affect the structure of the wall and provides excellent sound insulation. Easy installation and time efficient. - Page 10 RECOMMENDES TOOLS AND MATERIALS RECOMMENDES TOOLS AND MATERIALS Open end/adjustable wrenches Allen wrench Knife File Hacksaw Masonry Level Screw driver Insulation tape Tape measure Seal tape Bushing Lubricant ROUGHING-IN Reference Value UNIT: mm K-4179T/K-4179T-VLS/K-4179T-DNSW K-4179T-DNW/K-4179T-VABW/K-4179T-RES K-10611T/K-10611T-RES K-4178T/K-4178T-VES2/K-4178T-VE2/K-4178T-ESS K-10611T-ESS/K-10611T-VLS/K-10611T-VLSL 478 3 438 3 90~142 18~62...
- Page 11 Elbow Drain outlet 90mm, welding A B C 90mm Water Tank Bracket Discharge Elbow Drain outlet 110mm 110mm Water Tank Bracket Discharge Elbow Drain outlet 110mm, welding 110mm Kohler reserves the right to change marked dimensions without prior notice. 1263048-T01-D...
-
Page 12: Installation
INSTALLATION Way of Installation There are two ways to install this product: in-wall tank with frame & in-wall tank without frame In-wall Tank With Frame In-wall Tank Without Frame Installation For In-wall Tank With Frame Plug Paper Board Board A. Installation of In-wall Tank 1. - Page 13 3. Drill four holes with diameter of 10mm and depth of 80mm Bulge Screw with churn drilling as shown. A. Fill the bulge nail into the instruction hole on the wall, fix Mounting the fixing frame to the bulge nail, adjust the gasket and Bracket tighten the nut.
- Page 14 2. Tighten the long screw into the holes of the tank bracket Inlet Hole and cover the drainage hole with the big cap, cover the Tank Bracket inlet hole with the small cap. Small Cap Long Screw Drainage Hole Big Cap 3.
- Page 15 2. Tighten the long screw into the holes of the tank bracket Small Cap and cover the drainage hole with the big cap, cover the Inlet Hole inlet hole with the small cap. Long Screw Drainage Hole Big Cap Tank Bracket 3.
- Page 16 3. Install the big and small leak-proof gaskets on inlet pipe and outlet pipe ,then install it to corresponding pipes on the toilet tank. Small Leak-proof Gasket Inlet Pipe Drainage Pipe Big Leak-proof Gasket 4. 48mm-58mm of the long screw shall be reserved outside the wall as shown in the illustration.
-
Page 17: Faceplate Installation
E. Faceplate Installation Mask Slot B 1. Push slot A and slot B of the break water board forward and then insert into the detent. Break Water Board Tip 1: When installing the break water board, please make Slot A sure the slot is align with the detent. - Page 18 5. Install the faceplate as shown in the illustration. Put the lock on the faceplate directly on the reversed lock on supporting board, then push the faceplate and lock it. The installation shall begin from bottom to top. Faceplate Lock Supporting Faceplate Board...
- Page 19 2. Make sure of h according to dimensions of bowl and then Bulge Screw locate the installation hole of fixing bracket. Mark on the wall for appropriate position for fixing bracket, and drill four Fixing Bracket holes with diameter of 10mm and depth of 80mm with churn drilling as shown in illustration, and fill in the holes with bulge screw and tighten the screw to set the fixing bracket.
- Page 20 Mask 6. When finishing the brickwork, eliminate unwanted part of the mask, the drainage pipe and the inlet pipe. Sharp Knife Note: When building the wall, the product cannot be cast and filled by cement or be squeezed. Inlet Pipe Drainage Pipe 7.
- Page 21 2. Loosen the long screws as shown. Supporting Board 3. Tighten the locknut to the marked position of OPEN to " " take out the supporting board. Locknut OPEN Supporting Board 4. Take out the supporting board as shown. Supporting Board 5.
- Page 22 7. Hold the top of the bracket, and unplug the locknut by pulling the bracket. Bracket 8. Turn on/off the water supply Turn on /off the water supply by turning the valve. Valve 9. Take out the bracket as shown. Bracket 10.
- Page 23 12. Hold the upside of the fixing lock, and take it out as shown. Fixing Lock Fixing Lock 13. Pull discharge valve along the arrow direction as shown to remove discharge valve. Outlet Valve 14. Remove discharge valve as shown and then take valve out for cleaning.
-
Page 24: Troubleshooting Procedures
B. Adjust Inlet Valve Inlet Valve Hoist and reduce the water level in the tank by adjusting Control Pole the control pole. Turn the control pole counterclockwise to lower down the floating box and reduce the water level of the tank .turn the control pole clockwise to hoist the floating box and increase the water level in the tank. - Page 25 1263048-T01-D -19-...
