KidKraft 16701D Assembly Instructions

© 2002 KidKraft, LP
Please retain this information for future reference
HARDWARE: PARTS LIST:
A. Flat Washer
x 8 pcs
1
B. Spring Washer
x 8 pcs
C. Hex Bolt x 2 pcs
1 9/16 in, 40 mm
D. Hex Bolt x 2 pcs
3 in, 75 mm
E. Nut x 4 pcs
F. Bolt Anchor
x 2 pcs
Step 3
G. Threaded Rod
x 4 pcs
2 3/8 in, 60 mm
Allen Wrench x 1 pc
Wrench x 1 pc
The following tool
(not included) is
required for
assembly:
Flathead screwdriver
CAUTION:
ADULT ASSEMBLY REQUIRED. Hardware contains
small screws with sharp points. Keep unassembled
parts out of the reach of small children.
Brighton Chair
Assembly Instructions
Step 1
2
3
4
Step 4

USE AND MAINTENANCE:

-Use on level surfaces only CHOKING HAZARD. Small parts and sharp points, not suitable
for children under 3 years.
-Please check assembly at regular intervals, and
frequently tighten hardware if necessary. If
maintenance is not carried out, the product could
cease to function properly.
1
4
C
B
A
B A

WARNING:

Item #16701D, 16704D, 16705D,
To order replacement parts, please visit www.kidkraft.com
Step 2
Step 5
2
3
A
B
Before calling customer service, please
locate the batch code number
(example: 2693/65006/04) found on the
bottom or back of your product.
16706D, 16707D, 16708C
D
B
A
E
Customer Service
1-800-933-0771
www.kidkraft.com
1
