SofTec Microsystems ZK-HC08AX-A User Manual

ZK-HC08AX-A
Starter Kit for Freescale
MC68HC908AB/AS/AZ Family
(64-Pin QFP ZIF Socket)
User's Manual
1. Introduction
Copyright © 2005 SofTec Microsystems
DC00906
Downloaded from Elcodis.com electronic components distributor
Overview
The ZK-HC08AX-A Starter Kit has been designed for the evaluation of
the Freescale MC68HC908AB/AS/AZ family and the debugging of user
applications. The ZK-HC08AX-A Starter Kit can be used as a standalone
application, or via its built-in USB to MON08 bridge, or together with an
external debugger through a MON08-compatible connection.
Starter Kit Features
The ZK-HC08AX-A Starter Kit features the following sections.
1. An "MCU" section containing:
An MC68HC908AZ60A microcontroller (in 64-pin QFP package,
already programmed with a demo application—in addition, you
can also use any other pin-to-pin-compatible device);
