Natron WE-A
Addressable fire
alarm wireless
(network gateway)
module with built-in
ATTENTION: Read carefully this installation Instructions before installing the device!
This manual is subject to change without notice!
1. General Description
Natron WE-A is an addressable wireless expander (network gateway) module, designed for
operation with iRIS8 and iRIS4 addressable fire alarm panels. Natron WE-A is powered directly by
the loop line and can be controlled via the communication protocol. Natron WE-A has a built-in
isolator module.
Natron WE-A communicates with Natron series wireless devices enrolled to its configuration. The
wireless devices are automatically recognized from the fire panel and are set in consecutive
addresses after the set address of the expander (network gateway) module. Up to 32 wireless
devices can be enrolled to a specific expander (network gateway), forming a linear network. Up to
5 Natron WE-A wireless expander (network gateway) modules can be connected to a single
iRIS8/iRIS4 fire alarm control panel.
Natron WE-A is mounted in a compact plastic enclosure box suitable for wall mounting. The
information of the status of the enrolled wireless devices is presented on a LCD text display.
A dipole SMA type antenna is supplied with the expander (network gateway) module to ensure
wide covering range and stable communication with the enrolled wireless devices.
2. Functional Features
• Loop powered
• Built-in isolator module
• Up to 5 wireless expander (network gateway) modules to iRIS8/iRIS4 addressable panel
• Up to 32 NATRON series wireless devices enrolled to single Natron WE-A module
• Dipole antenna, SMA connector type
• Event messages for wireless device status: low battery, tamper, lost device
• Menu for reviewing the signal strength of the enrolled devices
• LCD display, dot matrix 16x2
• Multilanguage menus
• Standards applied: EN 54-18; EN 54-17; EN 54-25
expander
EN 54-18:2005/AC:2007
EN 54-17:2005/AC:2007
isolator
23
2918
DoP No: 226
EN 54-18:2005
EN 54-17:2005
EN 54-25:2008
1
Teletek Electronics JSC
Address: 2 Iliyansko Shose Str,
1220 Sofia, Bulgaria
Advertisement
Table of Contents
Related Manuals for Teletek electronics Natron WE-A
Summary of Contents for Teletek electronics Natron WE-A
- Page 1 Natron WE-A is an addressable wireless expander (network gateway) module, designed for operation with iRIS8 and iRIS4 addressable fire alarm panels. Natron WE-A is powered directly by the loop line and can be controlled via the communication protocol. Natron WE-A has a built-in isolator module.
-
Page 2: Technical Specifications
4. Installation Place and Mounting It is strongly recommended to design the Natron wireless system in advance on paper, before starting the installation. Natron WE-A expander (network gateway) module should be installed at 2-2.5m above the floor level. Attention: Avoid installation of Natron WE-A module and the wireless devices near to: •... - Page 3 General View and Dimensions Opening the enclosure box Mounting holes Positioning of the antenna Use fixing elements according the mounting surface Openings for running cables For achieving the best signal strength and coverage it is recommended the antenna to be mounted in straight up position! There are two openings for running cables The SMA antenna is mounted to the module...
-
Page 4: System Topology
5. System Topology Natron WE-A wireless expander (network gateway) module is powered on directly from the loop line and is addressed like all other addressable devices in the system architecture of iRIS8/iRIS4 fire alarm panel. The enrolled to the module Natron series devices, operate in linear network. - Page 5 Attention: The connection to the loop line of Natron WE-A must be done with switched off main and back-up power supply of iRIS8/iRIS4 fire alarm panel! The module is equipped with 5-position plug terminal for easy connection to the loop line.
-
Page 6: Front Panel
8. Front Panel At the front panel of Natron WE-A, are located LCD text display and operation buttons. 1 – Antenna (mounted to the antenna connector on the PCB). 2 – LCD text display, dot matrix 16x2. 3 – LED indication for the module status:... - Page 7 3. Open the enclosure box of the expander (network gateway) module and mount it on the place of installation – see item 4. 4. Connect Natron WE-A module to the loop line observing the polarity of the connection – see item 7.
- Page 8 1 long flash in red and 1 long flash in green. 2. Enter in programming mode of Natron WE-A. Select menu 1. ADD DEVICE and press ENTER button. A list with already enrolled devices is shown on the screen with an order number and type of the device: SD (optical-smoke detector), TD (heat detector), MD (combined detector), MCP (manual call point), WSS (sounder with strobe), MIO (input-output module) –...
- Page 9 The procedure of removing is common for all devices. 1. Enter in programming mode of Natron WE-A. Scroll to menu 2. REMOVE DEVICE and press ENTER button. A list with present enrolled devices is shown on the screen with an order number and type of the device.
-
Page 10: Channel Setup
17. Setting the Language The menus of Natron WE-A are available in different languages. To change the language of the menus, enter programming mode and scroll to 6. LANGUAGE menu. Press ENTER button. Use the arrow buttons to review the languages. - Page 11 18. Events Reviewing Mode Natron WE-A wireless expander (network gateway) module informs the users about different type of events concerning the current state of wireless devices enrolled to its configuration. In case of alarm, fault or warning event, it is displayed first on the screen of iRIS8/iRIS4 fire panel (Faults menu).
- Page 12 19. Settings Menu of Natron WE-A in iRIS8/iRIS4 Fire Alarm Panel The settings menu of Natron WE-A wireless expander (network gateway) module is accessed at Level 3. Enter in SYSTEM-PROGRAMMING-DEVICES-LOOP menu and find the address number of the module. Fields description: (1) System Name (2) System Status –...
