- Page 1 AGT INDUSTRIAL PRODUCT MANUAL Skid Steer Landscape Rake Attachment 72" Model:AGT-ECSSLR72 Ver.1.1.3 https://www.agrotkindustrial.com/...
- Page 2 TABLE OF CONTENTS TABLE OF CONTENTS TO THE OWNERS SAFETY PRECAUTIONS OPERATION INSTRUCTIONS NOTES sales@agrotkindustrial.com https://www.agrotkindustrial.com/...
- Page 3 TO THE OWNERS GENERAL COMMENTS Congratulations for having this Landscape Rake! Your Landscape Rake was carefully designed and manufactured to give you years of dependable service. Your Landscape Rake will require some minor maintenance to keep it in top working condition. Please observe all safety precautions and maintenance procedures as described in this manual.
- Page 4 SAFETY PRECAUTIONS BEFORE OPERATION 1. The operator must read the operation manual carefully before installation, operation or maintenance. Improper operation will cause the machine damage or the operator death. 2. Read all the safe signs and safe declarations. Follow all the professional safe terms, local laws or the professional directions.
- Page 5 SAFETY PRECAUTIONS Operator Safety ►Wear protective clothing and equipment appropriate for the job. Clothing should be snug fitting without fringes and pull strings to avoid entanglement with moving parts. ►Prolonged exposure to loud noise can cause hearing impairment or hearing loss. Wear suitable hearing protection such as earmuffs or earplugs. ►Operating equipment safely requires the operators all attention, Avoid wearing radio headphones while operating machinery.
- Page 6 SAFETY PRECAUTIONS Wear Protective Equipment ►Escaping fluid under pressure can penetrate the skin causing serious injury. ►Avoid the hazard by relieving pressure before disconnecting hydraulic lines or performing work on the system. ►Make sure all hydraulic fluid connections are tight and all hydraulic hoses and lines are in good condition before applying pressure to the system.
- Page 7 OPERATION INSTRUCTIONS Warning! • Never lift the product above the operator’s eye level or to a height where visibility is obstructed, whichever is lower. •Do not roll back the product so far that the load falls off toward or on the operator.
- Page 8 OPERATION INSTRUCTIONS Loader Raking All raking must be done while moving backward. 1.Activate auxiliary hydraulics for operating rake chain, (If rake chain does not move but hydraulic cylinder begins to retract, activate auxiliary hydraulics in opposite direction to get rake chain to operate.) 2.Lower loader arms completely and set loader arm control in float position, 3.Tilt rake forward until the weight of the rake portion is resting on the depth adjustment plates.
- Page 9 NOTES sales@agrotkindustrial.com https://www.agrotkindustrial.com/...
