Summary of Contents for AGT INDUSTRIAL AGT-SSRPB80
- Page 1 AGT Industrial Product manuals Skid Steer Rock Picker Bucket Model:AGT-SSRPB80 Ver.1.1.4 https://www.agrotkindustrial.com/...
- Page 2 https://www.agrotkindustrial.com/ Directory Product introduction 1/14 Operator 2/14 Safety precautions 3/14 Technical parameters 4/14 Installation 7/14 Handing safety 9/14 Limited Warranty 14/14...
-
Page 3: Product Introduction
https://www.agrotkindustrial.com/ Product introduction The speed of moving, removing and sorting rocks from farms or work sites is very fast, and can remove rocks as small as 2 inches or as large as 2 feet in diameter. With its 1-inch-thick high-carbon steel tines and hydraulic power that can rotate 360 degrees, the reel can quickly and easily pick up concrete, gravel, wood and other general debris. - Page 4 https://www.agrotkindustrial.com/ Operator Congratulations on owning this Skid Steer Rock Picker Bucket! Your Skid Steer Rock Picker Bucket are carefully designed and manufactured to provide you with years of reliable service. Your Skid Steer Rock Picker Bucket will need some minor maintenance to keep it in excellent working condition.
-
Page 5: Safety Precautions
https://www.agrotkindustrial.com/ Safety precautions BEFORE OPERATION 1. The operator must read the operation manual carefully before installation, operation or maintenance. Improper operation will cause the machine damaged or the operator dead. 2. Read all the safe signs and safe declarations. Obey all the professional safe terms, local laws or the professional directions. -
Page 6: Technical Parameters
https://www.agrotkindustrial.com/ Technical parameters Model: SSRPB80 Hydraulic circuits： Working width： 78 in Total width: 63″ Total height: 41″ Total length： 88″ Total weight：（lb） 1499 Motor: Cycloid Motor Working Width: 78 in Working Pressure (MPa) Flow (L/min) 60-100 Maximum Speed of Picking Up Stones (r/min) Min. - Page 7 https://www.agrotkindustrial.com/ Technical parameters sales@agrotkindustrial.com...
- Page 8 https://www.agrotkindustrial.com/ PART DESCRIPTION QTYS NOTE Frame welded Holding claw shaft welding Sprocket guard soldered 11 tooth sprocket welding 25 tooth sprocket welding After netting Sprocket guard retaining rod Sprocket tension adjusting wheel Bearing seat baffle plate Long clamp Short clips Bolt(M12*80) Bolt(M12*130) Spring washers(φ16)
-
Page 9: Installation
https://www.agrotkindustrial.com/ Installation Unpack and check Check for missing or damaged components according to the packing list. If you have any questions, please contact the supplier. List of details As the table above: Machine installation Equipment must be installed on a solid concrete floor or similar. If the ground is not firm, it will not be able to connect to the loader. - Page 10 https://www.agrotkindustrial.com/ Installation Note: this drawing does not represent the appearance of the equipment For actual purchase, this figure is only for installation location reference. Tubing connection: the rock bucket is equipped with two tubing, one is the inlet tubing and the other is the outlet tubing. Connect the tubing to the loader tubing connection.
-
Page 11: Handling Safety
https://www.agrotkindustrial.com/ Handling safety Maintenance Overview The maintenance procedures described in this manual should only be carried out by qualified mechanics who have been trained to repair this machine. Some procedures require special tools and skills to complete. DO NOT attempt to repair or perform service work on this machine unless you have the skills and tools to do so. -
Page 12: Storage Tips
https://www.agrotkindustrial.com/ Handling safety Storage Tips To get years of quality use out of your rock bucket, follow these storage tips: Ensure rock bucket is free of debris, dirt, grime and grease. Store your in a dry shed or garage. rock bucket When storing your rock bucket for the season,... - Page 13 https://www.agrotkindustrial.com/ Handling safety OSHA 1910.266 Appendix A - First-aid Kits Source: http://www.osha.gov/pls/oshaweb/owadisp.show_document?p_table=STANDARDS&p_id=9863. Accessed: 16 Dec 09 The first-aid kit information below was directly obtained from OSHA regulations. Having a kit available at the job site is required by OSHA for logging operations and is highly recommended by AGT Manufacturing.
-
Page 14: Inspection Checklist
https://www.agrotkindustrial.com/ Handling safety Inspection Checklist This checklist is to be completed prior to every use of the rock bucket. DO NOT use a rock bucket that fails inspection until it has been repaired. Check for damaged hoses or hydraulic leaks. See hydraulic safety precautions in this manual. Check for cracked welds. - Page 15 https://www.agrotkindustrial.com/ Safely Checking for Hydraulic Leaks WARNING: There is significant risk of injection from the high pressure spray at hydraulic leaks The tremendous energy used to operate the machine and attachments can be stored in the hydraulic system even when the machine engine is off. Very serious injuries from hydraulic fluid injection can seem insignificant at first.
-
Page 16: Limited Warranty
https://www.agrotkindustrial.com/ Limited Warranty The goal of agrotkindustrial.(“AGT”) warranty policy is to assure confidence, reduce downtime and minimize cost of ownership. Should you want to verify warranty, or should potential issues arise,please contact your authorized dealer or AGT’s Customer Service Team at service@agrotkindustrial.com, +1 913-244-6269 and we will strive to resolve any issues in a timely manner. - Page 17 https://www.agrotkindustrial.com/ sales@agrotkindustrial.com...
