- Page 1 MICROWAVE OVEN KOR-1Q0A OPERATING INSTRUCTIONS & COOK BOOK Before operating this oven, please read these instructions completely. KOR-1Q0A(영)_DAEWOO.indd 2 2012-10-23 오후 4:05:04...
-
Page 2: Table Of Contents
• USE YOUR MICROWAVE OVEN SAFELY ....................21 • ARCING ................................21 • COOKING TECHNIQUES ..........................22 • DEFROSTING GUIDE ............................ 23 • COOKING & REHEATING CHART ........................ 24 • VEGETABLE CHART ............................. 25 • RECIPES ................................ 26 KOR-1Q0A(영)_DAEWOO.indd 3 2012-10-23 오후 4:05:04... -
Page 3: Important Safety Instructions
Do not overcook food. Carefully attend appliance when paper, plastic, or other combustible materials re placed inside the oven to facilitate cooking. b) Remove wire twist-ties from paper or plastic bags before placing bag in oven. SAVE THESE INSTRUCTIONS KOR-1Q0A(영)_DAEWOO.indd 2 2012-10-23 오후 4:05:05... -
Page 4: Federal Communications Commission Radio Frequency Interference Statement
(2) Do not use an extension cord, if the power supply cord is too short, have a qualified electrician or serviceman install an outlet near the appliance. WARNING: Do not cut or remove the third (ground) prong from the power cord under any circumstances. KOR-1Q0A(영)_DAEWOO.indd 3 2012-10-23 오후 4:05:05... -
Page 5: Installation Guide
When use grounding adaptor, make sure the receptacle box is fully grounded. 3-prong Receptacle Receptacle Box Cover Grounding Receptacle Lead Box Cover 3-prong Plug Grounding Receptacle Adaptor “THE CANADIAN ELECTRICAL CODE DOES NOT ALLOW THE USE OF THE GROUNDING ADAPTOR” KOR-1Q0A(영)_DAEWOO.indd 4 2012-10-23 오후 4:05:05... -
Page 6: Specifications
CAVITY DIMENSIONS (W x H x D) 15.1 x 10.2 x 14.7 in. CAVITY VOLUME 1.3 cu.ft NET WEIGHT APPROX. 30.4 lbs. TIMER 59 min. 99 sec. POWER SELECTIONS 11 Levels * Specifications are subject to change without notice. 21.3 15.4 KOR-1Q0A(영)_DAEWOO.indd 5 2012-10-23 오후 4:05:05... -
Page 7: Features Diagram
Viewing screen - Allows viewing of food. The screen is designed so that light can pass through, but not the microwave. 7 Door open button - To open the door push the door open button. KOR-1Q0A(영)_DAEWOO.indd 6 2012-10-23 오후 4:05:05... -
Page 8: Features Diagram (Continued)
START / +30 SEC - Used to start the oven and also used to set a reheat time. 7 LESS Pad - Press to subtract an extra cooking time during working. KOR-1Q0A(영)_DAEWOO.indd 7 2012-10-23 오후 4:05:05... -
Page 9: Operation Procedure
APPROXIMATE PERCENTAGE OF POWER once P-HI 100% twice P-90 3 times P-80 4 times P-70 5 times P-60 6 times P-50 7 times P-40 8 times P-30 9 times P-20 10 times P-10 11 times P-00 KOR-1Q0A(영)_DAEWOO.indd 8 2012-10-23 오후 4:05:05... -
Page 10: Controls
3. Touch START pad. The TIMER indicator starts blinking and the display counts down the time remaining in KITCHEN TIMER mode. When KITCHEN TIMER mode ends, you will hear 3 beeps. KOR-1Q0A(영)_DAEWOO.indd 9 2012-10-23 오후 4:05:05... -
Page 11: Kitchen Timer Mode (Continued)
The M/W indicator goes off and TIMER indicator starts blinking. The display counts down the time remaining in KITCHEN TIMER mode. When the KITCHEN TIMER mode ends, you will hear 3 beeps. NOTE : Your oven can be programmed for 59 minutes 99 seconds. (59 : 99) KOR-1Q0A(영)_DAEWOO.indd 10 2012-10-23 오후 4:05:05... -
Page 12: Weight Defrosting
When you touch START pad, the lb indicator goes off and the DEF indicator blinks and the defrosting time counts down in the display window. The oven beeps during the defrosting cycle to signal that the food needs to be turned or rearranged. When the defrosting time ends, you will hear 3 beeps. KOR-1Q0A(영)_DAEWOO.indd 11 2012-10-23 오후 4:05:06... -
Page 13: Time Defrosting
DEFROST mode. The oven beeps during the defrosting cycle to signal that the food needs to be turned or rearranged. When the defrosting time ends, you will hear 3 beeps. KOR-1Q0A(영)_DAEWOO.indd 12 2012-10-23 오후 4:05:06... -
Page 14: Cooking In One Stage
At the end of DEFROST mode, the oven will beep and start M/W cook. The DEF indicator goes off and the M/W indicator starts blinking. The display counts down the time remaining in M/W mode. When M/W cook ends, you will hear 3 beeps. KOR-1Q0A(영)_DAEWOO.indd 13 2012-10-23 오후 4:05:06... -
Page 15: +30 Sec
2. Use only frozen pizza made for microwave ovens. 3. If the cheese of frozen pizza does not melt sufficiently, cook a few seconds longer. 4. Some brands of frozen pizza may require more or less cooking time. KOR-1Q0A(영)_DAEWOO.indd 14 2012-10-23 오후 4:05:06... -
Page 16: One Touch Cook (Continued)
5. Touch the AUTO COOK pad five Then touch the START pad. The display will be times for 7 oz of FROZEN changed into cooking time of quantity and the VEGETABLE. AC-5 will be oven starts cooking. displayed. KOR-1Q0A(영)_DAEWOO.indd 15 2012-10-23 오후 4:05:06... -
Page 17: Child Safety Lock
• Touch the STOP/CLEAR pad once more to erase all instructions. • You must enter in new instructions. 2. Open the door. • You can restart the oven by closing the door and touching the START pad. NOTE: Oven stops operating when door is opened. KOR-1Q0A(영)_DAEWOO.indd 16 2012-10-23 오후 4:05:06... -
Page 18: Care Of Your Microwave Oven
DO NOT use any other Glass Tray with this oven. If Glass Tray is hot, ALLOW TO COOL before cleaning or placing it in water. DO NOT cook directly on the Glass Tray. (Except for popcorn) KOR-1Q0A(영)_DAEWOO.indd 17 2012-10-23 오후 4:05:06... -
Page 19: Before You Call For Service
It is particularly important that the oven closes properly and that there is no damage to the: i) Door(bent) ii) Hinges and Hookes(broken or loosened) iii) Door seals and sealing surfaces. KOR-1Q0A(영)_DAEWOO.indd 18 2012-10-23 오후 4:05:06... -
Page 20: Questions And Answer
Standing time for joints of meat, large every 1 or 2 seconds. Do not repop unpopped vegetables and cakes is to allow the inside to cook kernels. Do not pop popcorn in glass cookware. completely, without overcooking the outside. KOR-1Q0A(영)_DAEWOO.indd 19 2012-10-23 오후 4:05:06... -
Page 21: Cooking Instructions
Only if boilable or oven-proof. Should not be airtight.Prick • Freezer bags with a fork, if necessary. Wax or grease-proof paper Can be used to retain moisture and prevent spattering. : Recommended use : Limited Use : Not Recommended KOR-1Q0A(영)_DAEWOO.indd 20 2012-10-23 오후 4:05:07... -
Page 22: Use Your Microwave Oven Safely
• Metal, such as twist-ties, poultry pins, or gold rimmed • Foil not molded to food (upturned edges act like dishes, in the microwave. antennas). • Recycled paper towels containing small metal pieces being used in the microwave. KOR-1Q0A(영)_DAEWOO.indd 21 2012-10-23 오후 4:05:07... -
Page 23: Cooking Techniques
Cover foods with microwave cling film or a lid. Cover fish, vegetables, casseroles, soups. Do not cover Foods cook more quickly and evenly if spaced apart. cakes, sauces, jacket potatoes or pastry items. NEVER pile foods on top of each other. KOR-1Q0A(영)_DAEWOO.indd 22 2012-10-23 오후 4:05:07... -
Page 24: Defrosting Guide
NOTE : The above times should be regarded only as a guide. Allow for difference in individual tastes and preferences. The times may vary due to the shape, cut, and composition of the food. Frozen meat, poultry and fish must be thoroughly thawed before cooking. KOR-1Q0A(영)_DAEWOO.indd 23 2012-10-23 오후 4:05:07... -
Page 25: Cooking & Reheating Chart
2-3 min. Cook covered, in microwaveable casserole. Stir once halfway through cooking. Ravioli or pasta in sauce 1 cup 2-3 min. Cook covered, in microwaveable casserole. 4 cups 6-9 min. Stir once halfway through cooking. KOR-1Q0A(영)_DAEWOO.indd 24 2012-10-23 오후 4:05:07... -
Page 26: Vegetable Chart
Add 30ml(2 tbsp.) cold water. Peas ½ lb./250g 2½-4 min Add 15ml(1 tbsp.) cold water. Green beans ½ lb./250g 3-5 min Add 30ml(2t tbsp.) cold water. Mixed vegetables ½ lb./250g 2½-4 min Add 15ml(1ttbsp.) cold water. (carrots/peas/corn) KOR-1Q0A(영)_DAEWOO.indd 25 2012-10-23 오후 4:05:07... -
Page 27: Recipes
Salt and pepper to taste. 1/2 tsp(2.5ml) dried tarragon 3. Cook on P-HI for 13-14 minutes. Rearrange and 1 tbsp(15ml) tomato puree coat the chicken with the sauce twice during 1/4 pint(150ml) chicken stock cooking. KOR-1Q0A(영)_DAEWOO.indd 26 2012-10-23 오후 4:05:07... - Page 28 1 minute, until melted. Coat the dish with the melted salt & pepper butter. 3. Pour omelette mixture into flan dish. Cook on P-HI for 2 minutes. whisk mixture and cook again on P-HI for 1 minutes. KOR-1Q0A(영)_DAEWOO.indd 27 2012-10-23 오후 4:05:07...
- Page 29 3. Cover and cook on P-HI for 5 minutes then P-50 for 1 tbsp(15ml) tomato puree 8-13 minutes or until the meat is cooked. 1 tsp(5ml) mixed herbs 8 oz.(225g) minced beef salt and pepper KOR-1Q0A(영)_DAEWOO.indd 28 2012-10-23 오후 4:05:07...
