  • Page 1 SCENE SETTER 48 SC - 2448 48CH User Manual Dimmer Console...
  • Page 2 SCENE SETTER / DC-1224 24 CH Dimmer Console. Improvement and changes to specifications, design and this manual, may be made at any time without prior notice. All Rights Reserved...

  • Page 3: Table Of Contents

    Contents Features General Instructions 1. Overview 1.1 Front View 1.2 Rear View 2. Operation Guide 2.1 Begin Programming 2.1.1 Record Enable 2.1.2 Security for Your Programs 2.1.3 Program Scenes 2.2 Editing 2.2.1 Edit Enable 2.2.2 Erase a Program 2.2.3 Erase all Programs 2.2.4 Clear a Scene or Scenes 2.2.5 Delete a Step or Steps 2.2.6 Insert a Step or Steps...

  • Page 4: Features

    Features Thank you for your purchase. This product features include: Digital Technology Adopted. As a stage light controller, the unit can control intelligent unit and ordinary light. Power Failure Memory. Automatically recover to the last condition when you turn on the machine. Standard MIDI and DMX ports.

  • Page 5: General Instructions

    General Instructions Read the instruction in this manual carefully and thoroughly, as they give important information regarding safety during use and maintenance. Keep this manual with the unit, in order to consult it in the future. If the unit is sold or given to another operator, make certain that it always has its manual, to enable the new owner to read about its operation and re lative instructions.

  • Page 6: Overview

    1. Overview 1.1 Front View...
  • Page 7 1. Overview 1.1 Front View Show the current intensity of the relevant channel Preset A LEDs numbered from 1 to 24. These 24 sliders are used to control and /or program Channel Sliders 1-24 intensities of channels 1-24. These 24 buttons are used to bring an individual Flash Buttons 1-24 channel, to full intensity.
  • Page 8 1. Overview 1.1 Front View Edit is used to activate Edit mode. Edit / All Rev All Rev is to reverse the chasing direction of all programs. In Add mode, multiple scenes or Flash buttons will Add or Kill/ Rec Exit be on at a time.

  • Page 9: Rear View

    1. Overview 1.2 Rear view Power Switch This switch controls turning on or off of the power. DC 12-20V, 500 mA Min. DC Input MIDI ports for connection to a sequencer or MIDI MIDI Thru/Out/In device. This connector sends your DMX value to the DMX DMX Out fixture or DMX pack.

  • Page 10: Operation Guide

    2. Operation Guide 2.1 Begin Programming 2.1.1 Record Enable 1. Press and hold down the Record button. 2. While holding down the Record button, tap the Flash buttons 1, 6, 6 and 8 sequence. 3. Release the Record button, the Record LED lights up, now you can begin programming your chase patterns.

  • Page 11: Program Scenes

    2. Operation Guide 2.1.2 Security for Your Programs 3. While holding the Record and Edit buttons, tap the desired Flash button to enter a new Record Code. The Record Code consists of 4 Flash buttons(the same button or different buttons), be sure your new Record Code consists of 4 Flash buttons.
  • Page 12 2. Operation Guide 2.1.3 Program Scenes 3. Create a desired scene using Channel Sliders 1-48. At 0% or DMX 0, these sliders should be at 0 position, and at 100% or DMX 255, these sliders should be at 10 position. 4.
  • Page 13 2. Operation Guide 2.1.3 Program Scenes 7. Press a Flash button between 25- 48 while holding down the Record button. All LED will flash indicating the scenes have been programmed into memory. 8. You can continue programming or exit. To exit Program mode, tap the Exit button while holding down the Record button, the Record LED should go out.

  • Page 14: Editing

    2. Operation Guide 2.2 Editing 2.2.1 Edit Enable 1. Record enable. 2. Use the Page button to select the page the program you wish to edit is 3. Tap the Mode Select button to select CHNS SCENES. 4. Press and hold down the Edit button.

  • Page 15: Erase A Program

    2. Operation Guide 2.2.1 Edit Enable 5. While holding down the Edit button, tap the Flash button that corresponds to the program you wish to edit. 6. Release the Edit button, the relevant scene LED should light indicating you are in the Edit mode. 2.2.2 Erase a Program 1.

  • Page 16: Erase All Programs

    2. Operation Guide 2.2 Editing 2.2.3 Erase All Programs 1. Press and hold the Record button. 2. Tap the Flash buttons 1, 4, 2 and 3 in sequence while holding the Record button. All LEDs will flash, indicating all programs stored in memory have been erased.

  • Page 17: Delete A Step Or Steps

    2. Operation Guide 2.2.5 Delete a Step or Steps 1. Enter the Edit mode. 2. Tap the Step button to scroll to the step you wish to delete. 3. Tap the Delete button when you reach to the step you wish to delete, all LEDs will flash briefly indicating the deletion of the step.

  • Page 18: Insert A Step Or Steps

    2. Operation Guide 2.2.5 Delete a Step or Steps EXAMPLE: Delete the third step of the program on Flash button 25 on Page 2. 1. Record enable. 2. Tap the Mode Select button to select CHNS SCENE mode. 3. Tap the Page button until Page 2 LED lights. 4.
  • Page 19 2. Operation Guide 2.2.6 Delete a Step or Steps 4. Tap the Insert button to insert the step you’ve created before, all LEDs will flash, indicating the step is inserted. EXAMPLE: Insert a step with channels 1-12 fully on at a time between step 4 and step 5 of program 35.

  • Page 20: Modify A Step Or Steps

    2. Operation Guide 2.2.5 Modify a Step or Steps 1. Enter Edit mode. 2. Tap the Step button to scroll to the step you wish to modify. 3. Press and hold the Up button if you want to raise the intensity. If you want to lower the intensity, press and hold down the Down button.

  • Page 21: Running

    2. Operation Guide 2.3 Running 2.3.1 Running Chase Programs 1. Tap the Mode Select button to select CHNS SCENE mode indicated by the red LED. 2. Tap the Page button to select the correct page the program you wish to run is located.

  • Page 22: Running A Program To Audio

    2. Operation Guide 2.3.1 Running Chase Programs 4. Move the desired Channel slider (25- 48) to its maximum position to trigger the program, and the program will fade in depending upon current fade time. You may press and hold down the relevant Flash button(25-48) to trigger the program.

  • Page 23: Running A Program With The Speed Slider

    2. Operation Guide 2.3.2 Running a Program To Audio 4. Use the Audio Level slider to adjust the music sensitivity. 5. To return to normal mode, tap the Audio button a second time causing its LED goes out, the Audio mode is disengaged.

  • Page 24: Running A Program With The Standard Beat

    2. Operation Guide 2.3.3 Running a Program With the Speed Slider 4. Now you may move the Speed Slider to select your desired speed. NOTE: The step 3 is not necessary if the selected program is not recorded with the Standard Beat. 2.3.4 Running a Program With the Standard Beat 1.

  • Page 25: Change The Speed Mode Between 5 Minutes And 10 Minutes

    2. Operation Guide 2.3.4 Running a Program With the Standard Beat 5. While pressing and holding down the Rec Speed button, tap the Flash button(25-48) that stores the program. 6. The program will then run with the set time or beat when engaged. 7.

  • Page 26: Midi Operation & Dmx Channel Setup

    3. MIDI Operation & DMX Channel Setup 3.1 Setting MIDI IN 1. Tap the Flash button 1 three times while holding down the Record button, the Segment Display reads “CHI” indicating MIDI IN channel setup is available. 2. Tap the Flash button numbered from 1-16 to assign MIDI IN channel 1-16, the relevant channel LED lights indicating MIDI IN channel is set.

  • Page 27: Exit Midi Setting

    3. MIDI Operation & DMX Channel Setup 3.2 Setting MIDI OUT 2. Tap the Flash button numbered from 1-16 to assign MIDI OUT channel 1-16, the relevant channel LED lights indicating MIDI OUT channel is set. 3.3 Exit MIDI Setting Press and hold down the Record button.

  • Page 28: Sending Midi File Dump

    3. MIDI Operation & DMX Channel Setup 3.5 Sending MIDI File Dump Tap the Flash button 4 three times while holding down the Record button, the Segment Display reads “OUT” indicating the controller is ready to send a file. NOTE: 1.
  • Page 29 3. MIDI Operation & DMX Channel Setup 3.6 Implementation 4. There are two types of file dump mode described as below: Open Loop Mode CONTROLLER RECEIVER MIDI OUT MIDI IN MIDI OUT MIDI IN Close Loop Mode CONTROLLER RECEIVER MIDI OUT MIDI IN MIDI OUT MIDI IN...

  • Page 30: Dmx Channel Setup

    3. MIDI Operation & DMX Channel Setup 1. Be sure this unit has been in Record mode. Press and hold down Record button. 2. Tapping Flash 8 button three times while holding down Record button allows you to access DMX channel setup.

  • Page 31: Clear Of Dmx Channel Setup

    3. MIDI Operation & DMX Channel Setup 3.8 Clear of DMX Channel Setup 1. Be sure this unit has been in Record mode. Press and hold down Record button. 2. Tapping Flash 7 button three times while holding down Record button allows you to clear DMX channel setup and resume DMX channel to factory setting, i.e., 1-48 channel in...
  • Page 32 4. Brief of Main Functions Reverse the direction of the scene 1. Reverse the direction of all the scenes: Press the ALL REV Button, all the scenes should change their directions. 2. Reverse the chasing direction of all the programs with speed control. Press the Chase Rev Button.
  • Page 33 4. Brief of Main Functions Single Mode 1. All programs will run in sequential order starting in the order of program number. 2. The Segment Display will read the running program number. 3. All programs will be controlled by the same Speed Slider. 4.
  • Page 34 4. Brief of Main Functions Park 1. In CHNS SCENES Mode, press down the button you can change the chasing mode of programs between Single Mode and Mix Mode. 2. In Double Preset Mode, pressing down this button is equal to pushing Master Slider B to the top.

  • Page 35: Technical Specifications

    Technical Specifications Power Input DC 12~20V, 500 mA min. DMX Output 3 pin female XLR MIDI Signal 5 pin standard interface Audio Input 100 mV~1Vpp Fuse(internal) F0.5A 250V 5x20mm Dimensions 711x264x85mm Weight(appro.) 7.2 kg Attention! 1. To retain your programs from loss, this unit must be powered not less than two hour every month.
