Summary of Contents for Lupo Dayled Series
- Page 1 Dayled User Manual DAYLED 650 / DAYLED 650 DUAL COLOR DAYLED 1000 / DAYLED 1000 DUAL COLOR DAYLED 2000 / DAYLED 2000 DUAL COLOR...
-
Page 2: Warranty
Thanks for having purchased Lupo products. All the products are made in Italy and all the efforts have been put to keep the quality standards high. We hope this product can help you in your job and make your life easier as a professional. -
Page 3: Package Contents
Instructions • Device for indoor use only. • Protection standard IP20. • Maximum ambient temperature: 35 °C. • Make sure power supply plug is suitable to power required. • As prescribed by international regulations, a safety cable must be used when the fixture is suspended from ceiling. -
Page 4: Getting Started
Getting Started Dayled 2000 Locking knob Tilt lock knob Barndoors screw lock ON/OFF DMX INPUT (Male 5 PIN XLR) Battery DMX THROUGH connector Barndoors (Female 5 PIN XLR) (Male 3 PIN XLR) bracket – button MODE button + button Focus knob (Flood/spot) Dayled 1000 Locking knob... -
Page 5: Control Panel
Functioning CONTROL PANEL – MODE Dayled 2000 Dayled 650 / 1000 OPERATION MODE Manual Operation « » Press the MODE button to shift between the functions DIMMER, COLOR*, DMX (ON/OFF) and « » RESET DEVICE. The indicator shows the selected function. - DIMMER: Use the «... -
Page 6: Manual Options
ADVANCED FEATURES Manual Options 1. Use the buttons to select between the MONOCOLOR / CCT MODE* and EFFECT MODE. 2. Press the button to confirm the selection. *The mode name changes according to the Dayled model (monocolor or dual color). EFFECT MODE: 1. - Page 7 COMPLETE KIT OF V-MOUNT BATTERY POWER SUPPLY FOR DAYLED 650 AND 1000. The items are also sold separately. 95 Wh battery (cod.271) Battery charger (cod.272) This battery allows to power all Lupo This charger works with Lupo models with AC/DC functioning. 95 Wh and 160 Wh batteries.
-
Page 8: Dmx Protocol
3. COLOR TEMPERATURE - byte 1 * 4. COLOR TEMPERATURE - byte 2 * *Channel in use only the Dual Color version. Lupo srl - Via V. Sassi 28/30 Collegno (TO) - 10093 - Italy Phone: +39 011 411 9919 / e-mail: contact@lupo.it / website: www.lupo.it...
