56 Inch Rectangle Gas-Burning Firepit Table
R
C
US
Please keep this instruction manual for future reference
READ INSTRUCTION MANUAL BEFORE ATTEMPTING TO ASSEMBLE
Contact the Customer Service Team at e-mail: customercare@yimohome.com
Assembly Instructions
・
・
・
・
・
・
・
・
OR OPERATE THIS PRODUCT.
Keep the screws and parts out of reach of children.
(Made in China)
DANGER
LEAKING LP-GAS MAY CAUSE A FIRE OR EXPLOSION IF IGNITED
CAUSING SERIOUS BODILY INJURY OR DEATH.
CONTACT LP GAS SUPPLIER FOR REPAIRS, OR DISPOSAL OF THIS
WARNING
DO NOT USE OR STORE CYLINDER IN A
GARAGE OR ENCLOSED AREA.
WARNING:
Know the odor of LP-gas. If you hear, see or smell
leaking LP-gas, immediately get everyone away
from the cylinder and call the Fire Department.
Do not attempt repairs.
Caution your LP-gas supplier to:
Be certain cylinder is purged of trapped air prior
to first filling.
Be certain not to over fill the cylinder.
Be certain cylinder requalification date is checked.
LP-gas is heavier than air and may settle in low
places when dissipating.
Contact with the liquid contents of cylinder will
cause freeze burns to the skin.
Do not allow children to tamper or play with cylinder.
When not connected for use, keep cylinder valve
turned off. Self contained appliances shall be limited
to a cylinder of 30 lb capacity or less.
Do not use, store or transport cylinder where it would
be exposed to high temperatures. Relief valve may
open allowing a large amount of flammable gas to
escape.
When transporting, keep cylinder secured in
an upright position which cylinder valve turned off.
DO NOT REMOVE, DEFACE, OR OBLITERATE THIS LABEL
*EXCEPT AS AUTHORIZED BY ANSI/NFPA 58.
DANGER. Do not store a spare LP cylinder under or near a barbecue grill, or other
heat sources. NEVER fill an LP cylinder beyond 80% full: a fire causing death or
serious injury may occour.
WARNING
ITEM NO.
GYM-81008
·
FLAMMABLE GAS UNDER PRESSURE.
CYLINDER OR UNUSED LP-GAS.
·
FOR OUTDOOR USE ONLY.*
BUILDING,
WHEN CONNECTING FOR USE:
・
Use only in compliance with appliable codes.
・
Read and follow manufacturer's instructions.
・
Consult manufacturer's instructions
concerning the cylinder connection provided
with your appliance.
・
Be sure regulator vent is not pointing up.
・
Turn off all valves on the appliance.
・
Do not check for gas leaks with a match or
open flame. Apply soapy water at areas
marked "X". Open cylinder valve. If bubble
appears, close valve and have LP-gas
service person make needed repairs. Also,
check appliance valves and connections to
make sure they do not leak before lighting
appliance.
・
Light appliance(s) following manufacturer's
instructions.
・
When appliance is not is use, keep the
cylinder valve closed.
X
Pressure relief valve
X
Cylinder
X
Cylinder valve hand wheel
Point of connection
X
X
Liquid level indicator
(optional)

Advertisement

Table of Contents
loading

Related Manuals for Better Homes and Gardens GYM-81008

Summary of Contents for Better Homes and Gardens GYM-81008

  • Page 1 ITEM NO. GYM-81008 Assembly Instructions 56 Inch Rectangle Gas-Burning Firepit Table · DANGER FLAMMABLE GAS UNDER PRESSURE. LEAKING LP-GAS MAY CAUSE A FIRE OR EXPLOSION IF IGNITED CAUSING SERIOUS BODILY INJURY OR DEATH. CONTACT LP GAS SUPPLIER FOR REPAIRS, OR DISPOSAL OF THIS CYLINDER OR UNUSED LP-GAS.

  • Page 2: Table Of Contents

    Table of Contents Assembly..………………………………………..…7-10 Table of Contents ............2 Operating Instructions .........11-13 Safety Information............2-4 Maintenance............14 Warranty.................5 Pre-Assembly...……………………...……………………. 5 Care and Cleaning ..........14 Troubleshooting ............15 Package Contents ..………………...……………………. 6 Service Parts ..........16 Safety Information Read the instruction before use. This appliance must be installed in accordance with such regulations as are enforced.

  • Page 3: Safety Information

    Safety Information (continued) WARNING: You must provide propane gas and propane cylinder. Use a standard 20 lb. propane cylinder only. Use this heater only with a propane vapor withdrawal supply system. See Chapter 5 of the Standard for Storage and Handling of Liquefied Petroleum Gas, ANS/NFPA 58.
  • Page 4 Safety Information (continued) WARNING: Solid fuels shall not be burned in this appliance. The installation must conform with local codes or, in the absence of local codes, ANSIZ223. 1/NFPA54, NFPA58 Natural Gas and Propane Installation Code, CSA B149.1, or Propane Storage and Handling Code, B149.2. This appliace must be isolated from the gas supply piping system by closing its individual manual shutoff valve during any pressure testing of the gas supply piping system at test pressures equal to or less than 1/2 psi (3.5 kPa).

  • Page 5: Warranty

    Warranty 1 YEAR LIMITED WARRANTY • We warrant the metal frame and burner to be free of manufacturing defects to the original purchaser for one years. • Proof of purchase (dated register receipt) is required for warranty claims. WHAT IS NOT COVER It remains the customer’s responsibility for freight and packaging charges to and from our service center.

  • Page 6: Package Contents

    Package Contents Part Description Quantity Part Description Quantity Leg A Side Panel Leg B Back panel Side Panel with Window Leg C Leg D Gas tank support Metal Lid Cross Bar Fire Glass Table top with Burner Door Panel...

  • Page 7: Assembly

    Assembly Assembling the front door frame □ Insert the door panel (H) to the Leg (D) by using one M6 x 10 mm Bolt (AA). Assembling the legs Attach the Legs (A,B,C)to the Table Top with Burner(G) by using eight M6x10mm Bolts □...
  • Page 8 Assembly (continued) Assembling the side panel with window □ Attach the side panel with window (K) to legs (A, B) by using four M6 x10 mm bolts (AA). Do not tighten the bolts at this step. □ Attach the control panel to the side panel with window (K) by using four M5x12 mm bolts (CC) and tighten them.
  • Page 9 Assembly (continued) Assembling the back panel □ Attach the back panel(J) to the legs (B,C) by using four M6 x 10 mm bolts (AA). □ Do not tighten the bolts at this step Assembling the gas tank support Attach the gas tank support (L) to side panels (K,I) with four M6x16 mm □...
  • Page 10 Assembly (continued) Fire Bowl Assembling the cylinder □ Put the cylinder into the gas tank support (L), and secure the cylinder by tightening the screw in the gas tank support (L). Connect the hose and regulator to the cylinder. □ Place the fire glass (F ) into the fire bowl.
  • Page 11 Operating WARNING: Never use this appliance for other than the intended use. DO NOT use this appliance to prepare food. Initial Lighting: When lit for the first time, the appliance emits a slight odor. This is a normal temporary condition caused by the “burn-in ”...

  • Page 12: Operating Instructions

    Operating (continued) LEAK TESTING OPERATION WARNING: A leak test must be performed annually or if a part of the gas system is replaced. WARNING: Never use an open flame to check for gas leaks. Be certain no sparks or open flames are in the area while you check for leaks.
  • Page 13 Operating (continued) LIGHTING CAUTION: Keep the outdoor gas appliance area clear and free from combustible materials, gasoline and other flammable vapors and liquids. CAUTION: Do NOT obstruct the flow of combustion and ventilation air. CAUTION: Check and clean burner/venturi tubes for insects and insect nests. A clogged tube can lead to a fire.

  • Page 14: Maintenance

    Maintenance Storage between uses: □ Turn the control knob to “OFF” position. □ Disconnect LP source. □ Store heater upright in an area sheltered from direct contact with inclement weather (such as rain, sleet, hail, snow, dust and debris). □ If desired, cover heater to protect exterior surfaces and to help prevent build up in air passages. NOTE: Wait until heater is cool before covering.

  • Page 15: Troubleshooting

    Troubleshooting PROBLEM PROBLEM CAUSE SOLUTION The flame and heat are The propane lighting Ensure lighting procedure is followed carefully. The valve low when the valve is procedure was not followed must be in the off position when the tank valve is turned on. turned to high.
  • Page 16 PV-102-BE...
  • Page 18 M6x35...
  • Page 21 PV-103-BE...
  • Page 23 M6x35 M6x90...
  • Page 27 PV-104-BE...
