ZyXEL Communications PRESTIGE P-2002 Specifications

Prestige 2002 Series
VoIP Analog Telephone Adapter
Models:
P-2002, VoIP ATA
P-2002L, VoIP ATA with PSTN Lifeline
ZyXEL's P-2002 is an Analog Telephone Adapter (ATA) that
provides customers with an easy-to-use solution for Voice over IP
service deployment. Connecting a traditional phone set to the
POTS phone port of the P-2002 series instantly establishes an IP
B e n e f i t s
Supports Open Standard
ZyXEL's P-2002 series supports standard SIP (RFC 3261), which is
suitable for IP telephony service deployment and addresses the
needs of users who are connecting to emerging SIP-based
communication networks.
Easy to Deploy
ZyXEL's P-2002 series supports multiple methods of configuration
including Web-based configuration, Telnet management, and TFTP
Auto-Provisioning. It eliminates the time and effort associated with
complicated installation procedures.
Multiple SIP and Voice Channels
Based on ZyXEL's flexible VoIP technology platform, one or more
SIP phone number may be configured with the P-2002 ATA. Each
SIP phone number can be freely assigned to either phone port
individually, or to both ports at the same time.
By using the P-2002 ATA to deploy VoIP service, service providers
need only provide a minimum of one SIP number to each
subscriber. Billing and service deployment are simplified by
A p p l i c a t i o n
IP Telephony Service
Provider Application
IP-PBX based Corporate
VoIP Application
D i a g r a m
Cable/DSL Modem
FXS
RJ-45 Ethernet
P-2002L
FXS
Life Line Relay
Home
PSTN
Network
IP-PBX
Traditional
Phone
Network
RJ-45 Ethernet
P-2002
Headquarters
phone device, allowing users to place VoIP calls without the use of
a PC. Based on industry standard SIP (Session Initiation protocol,
RFC 3261) call control protocol and sophisticated voice
compression technology, the P-2002 series offers smooth IP-based
voice communication with superb sound quality.
ZyXEL's P-2002 series Analog Telephone Adapter is an ideal
solution for IP Telephony service deployment as well as SOHO
and Home VoIP applications.
allowing subscribers to use two phones with the same SIP number.
If one telephone is in use, users may use a secondary telephone to
place a call while using the same SIP number. Additionally, users
may also receive incoming calls even when the SIP number is in use.
The advantages of the P- 2002 ATA include increased traffic and
service revenue.
Cost Effective
ZyXEL's P-2002 series turns a traditional phone into an IP phone
device at a very low cost. Not only does the Prestige 2002 series
deliver VoIP service at a low per-port cost but the built-in two-port
Ethernet switch also allows user to connect their PC to the reserve
Ethernet port without adding an extra Ethernet switch or hub.
Lifeline Support (Option, P-2002L)
ZyXEL's P-2002L allows users to maintain PSTN phone service and
VoIP service at the same time. When ATA power down occurs or
VoIP service is not available, outgoing phone calls will be relayed
to PSTN automatically. When VoIP service is active, users can
place calls to a PSTN phone by dialing pre-fix numbers. Emergency
calls or important calls can be relayed to PSTN automatically.
IP Telephony Service Provider
Internet
Cable/DSL Modem
FXS
RJ-45 Ethernet
P-2002
FXS
Home
PSTN Phone
PSTN
Network
P-2002
IP Network
RJ-45 Ethernet
Branch Office
PSTN Phone
Trunking
VoIP
PSTN
Gateway
Call
Network
Server
FXS
FXS
