SD card real time datalogger

HUMIDITY/BAROMETER/

TEMP. METER

ATE-9382

OPERATION MANUAL

www.tmatlantic.com

Your purchase of this

HUMIDITY/BAROMETER/

TEMP.

MONITOR

S D

C A R D

DATALOGGER marks a

step

forward

into

the

precision measurement.

A l t h o u g h

DATALOGGER

complex

and

instrument, its durable

structure

will

many years of use if

p r o p e r

o p e r a t i n g

t e c h n i q u e s

developed. Please read

t h e

f o l l o w i n g

instructions

and always keep this

manual

within

reach.

with

for

you

field

t h i s

delicate

allow

a r e

carefully

easy

Table of Contents

Summary of Contents for Aktakom ATE-9382

Page 1 SD card real time datalogger HUMIDITY/BAROMETER/ TEMP. METER ATE-9382 Your purchase of this HUMIDITY/BAROMETER/ TEMP. MONITOR with C A R D DATALOGGER marks a step forward into field precision measurement. A l t h o u g h t h i s...
Page 2 TABLE OF CONTENTS 1. FEATURES................2. SPECIFICATIONS................ 3. FRONT PANEL DESCRIPTION..............3-1 Display..................3-2 Logger button, Enter button..............▲ button, Time button............▼ button................3-5 SET button..................3-6 Humidity/Temp./Barometer sensor..........3-7 Hanging holes................3-8 Stand................ 3-9 Battery cover/Battery compartment............3-10 Screw for battery cover............. 3-11 Reset button................
Page 3: Specifications
1. FEATURES * Monitor with real time data logger, save the measuring data along the time information ( year, month, date, hou, minute, second ) into the SD memory card and can be down load to the Excel, extra software is no need. user can make the further data or graphic analysis by themselves.
Page 4 Datalogger 5/10/30/60/120/300/600 seconds Sampling Time or Auto. * Default sampling time is 60 seconds. * The " Auto " sampling . means when the measuring value is changed ( > ℃ ± 1 %RH or > ± 1 or > ± 1 hPa ) will save the data one time only.
Page 5 Weight 285 g/0.63 LB. Dimension 132 x 80 x 32 mm ( 5.2 x 3.1 x 1.3 inch ) Accessories Instruction manual......1 PC Included Hanging unit ( with sticker )....Optional SD Card ( 2 GB ) Accessories AC to DC 9V adapter. USB cable, USB-01.
Page 6: Front Panel Description
3. FRONT PANEL DESCRIPTION Fig. 1 3-1 Display 3-2 Logger button, Enter button ▲ button, Time button ▼ button 3-5 SET button 3-6 Humidity/Temp./Barometer sensor 3-7 Hanging holes 3-8 Stand 3-9 Battery cover/Battery compartment 3-10 Screw for battery cover 3-11 Reset button 3-12 RS-232 output terminal 3-13 SD card socket 3-14 DC 9V power sdapter input socket...
Page 7: Measuring Procedure
4. MEASURING PROCEDURE 1) Install the batteries into the battery compartment : * Loose the " Screw of the battery cover " ( 3-10, Fig. 1 ) and take away the " Battery Cover " ( 3-9, Fig. 1 ) from the meter.
Page 8 c. Time setting If the meter is used at first time, it should to adjust the clock time exactly, please refer chapter 7-2 ( page 11 ). d. Decimal format setting The numerical data structure of SD card is default used the " . " as the decimal, for example "20.6"...
Page 9 5-2 Datalogger a. Start the datalogger Press the " Logger button ( 3-2, Fig. 1 ) > 2 seconds continuously, until the Display show the indicator " DATALOGGER ", release the " Logger Button " ( 3-2, Fig. 1 ), then the measuring data along the time information will be saved into the memory circuit.
Page 10 5-4 SD Card Data structure 1) When the SD card is used into the meter, the SD card When the first time, the SD card is used into the meter, the SD card will generate a folder : HBA01 2) If the first time to execute the Datalogger, under the route HBA01\, will generate a new file name HBA01001.XLS.
Page 11 6. Saving data from the SD card to the computer ( EXCEL software ) 1) After execute the Data Logger function, take away the SD card out from the " SD card socket " ( 3-13, Fig. 1 ). 2) Plug in the SD card into the Computer's SD card slot ( if your computer build in this installation ) or insert the SD card into the "...
Page 12: Advanced Setting
EXCEL graphic screen ( for example ) 7. ADVANCED SETTING Under do not execute the Datalogger function, press the " SET button " ( 3-5, Fig. 1 ) > 2 seconds continuously will enter the " Setting " mode., then release the " SET button ". Following press the "...
Page 13 Remark : During execute the " Setting " function, if within 5 seconds , do not press any buttons further, the LCD Display will return to normal screen. 7-1 SD memory card Format When the Display show " Sd F " ▲...
Page 14 Remark : The adjusted unit will be flashed. 2) After set all the time value ( Year, Month, Date, Hour, Minute, Second ), press the " SET button " ( 3-5, Fig. 1 ) once will save the time value, then the screen will jump to Sampling time "...
Page 15 yES - Meter's beep sound will be ON with default when save each data. no - Meter's beep sound will be OFF with default. when save each data. 2) After select the upper text to " yES " or " no ", press the "...
Page 16 ℃ ℉ 7-6 Select the Temp. unit to When the Display show " t-CF " ▲ ▼ 1) Use the " Button " ( 3-3, Fig. 1 ) or " Button " ( 3-4, Fig. 1 ) to select the upper Display text to " C " or "...
Page 17: Power Supply From Dc Adapter
7-8 Set the unit of Barometer When the Display show " bAro " ▲ ▼ 1) Use the " Button " ( 3-3, Fig. 1 ) or " Button " ( 3-4, Fig. 1 ) to select the upper Display text to hPA ", "...
Page 18: Battery Replacement
9. BATTERY REPLACEMENT 1) When the left corner of LCD display show " ", it is necessary to replace the battery. However, in-spec. measurement may still be made for several hours after low battery indicator appears before the instrument become inaccurate. 2) Loose the "...
Page 19: Rs232 Pc Serial Interface
11. RS232 PC SERIAL INTERFACE The instrument has RS232 PC serial interface via a 3.5 mm terminal ( 3-12, Fig. 1 ) if the RS232 function already select to " ON ", refer to chapter 7-7, page 14. The data output is a 16 digit stream which can be utilized for user's specific application.
Page 20: Patent Pending
Decimal Point(DP), position from right to the left 0 = No DP, 1= 1 DP, 2 = 2 DP, 3 = 3 DP Polarity 0 = Positive 1 = Negative D11 & D12 Annunciator for Display ℃ ℉ = 01 = 02 % RH = 04 hPa = 91...
