Baby Monitor
User Manual
Contact us: service@getbabytone.com
Website:
www.getbabytone.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BM-1T and is the answer not in the manual?

Questions and answers

Summary of Contents for Babytone BM-1T

  • Page 1 Baby Monitor User Manual Contact us: service@getbabytone.com Website: www.getbabytone.com...
  • Page 2: Table Of Contents

    Contents 1. Introduction ..........1 2. Warnings ........... 1 3. Packing List ..........2 4. Guide to Parts .......... 3 4.1. Overview of the Camera Unit..3 4.2. Overview of the Baby Monitor ... 4 5. Activate the Device ........ 6 5.1.
  • Page 3: Introduction

    1. Introduction It is intended to monitor infants or children when they are alone through real-time images captured by the camera and audio communication. Also, paired with the optional device Baby Sleep Monitor, data of oxygen level and heart rate can be tracked and displayed through the integrated communication module of the camera, ensuring your acknowledgement of the...
  • Page 4: Packing List

    Connect the power adapters to easily ⚫ accessible electrical outlets. 3. Packing List Baby Monitor (Display screen, Model:BM-1R) ⚫ Camera Unit ( Model:BM-1T) ⚫ Charging Plug and Power Cable for Baby ⚫ Monitor Charging Plug and Power Cable for ⚫...
  • Page 5: Guide To Parts

    4. Guide to Parts 4.1. Overview of the Camera Unit Camera Lens Indicator LED Temperature & Humidity Sensor Speaker Reset Key Power Adapter Socket Bracket Screw Holes Connection Hole Note: You can either fix the camera to anywhere you need by adjusting the bracket or to the wall after inserting screws.
  • Page 6: Overview Of The Baby Monitor

    4.2. Overview of the Baby Monitor LCD Screen Joystick Camera mode: Tilt up or down, pan left or right. Menu mode: Up, down, left, right. OK Key Menu/Exit Key Press to open the Menu options or exit. Indicator LED Blue light: talking. Green light: charging, it turns off when charging is complete.
  • Page 7 Baby Monitor menu icons Icon Description Talk mode ON Recording Volume Ambient humidity Ambient temperature TF card full Vox monitor state Signal intensity Oxygen level (if paired with ‘Baby Sleep Monitor’) Heart rate(if paired with ‘Baby Sleep Monitor’) * The Baby Sleep Monitor is an optional device.
  • Page 8: Activate The Device

    5. Activate the Device 5.1. Camera Unit a) Connect the micro USB interface of the power adapter to the Camera Unit, and the other end to the electrical outlet. Note: Compatible power adapter output: ⚫ DC 5V, 1A. 5.2. Baby Monitor Connect the Type C interface of the power adapter to the Baby Monitor and the other end to the electrical...
  • Page 9: Using The Device

    Wait patiently for automatic pairing, you can monitor the pairing process through the LED light on the camera. Indicator Status Description Purple, red, Power on, and blue alternating waiting for light flashing configuration Red light 30s quick Unpaired, flashing disconnected Blue light 30s on then Paired,...
  • Page 10: Pan, Tilt, And Zoom

    location (e.g. on a table) and point the camera lens towards the area you want to monitor. Adjust the Camera Unit's angle by controlling the joystick to rotate the camera up, down, left and right until you are satisfied with the image in the Baby Monitor.
  • Page 11: Night Vision Mode

    Remove the TF card and check the pictures in your computer. 6.4. Night vision mode The Camera Unit has high-intensity infrared LEDs for picking up clear images in the dark. When the built-in photo sensor detects a low level of ambient light, the LEDs will automatically activate and the screen on the Baby Monitor will display in black and white.
  • Page 12: Playback (Tf Card Required)

    confirm, and press the Menu key to exit. 7.1. Playback (TF card required) This function is turned on by default (prompt the user to install TF card), you can activate it after inserting the TF card, please follow the procedures below: Press Menu>Playback, and select the record of a specific date.
  • Page 13: Feeding Clock

    continuously or 8 songs in turn. Note: The device cannot be muted in this page, the default volume is level 1. The volume can be changed in camera setting page, Menu>Setting>Camera. 7.4. Feeding Clock Press Menu>Setting>Feeding Clock. Choose the desired duration and repeat or not.
  • Page 14: Bluetooth

    before it is overwritten. One-eighth of the storage space ⚫ is reserved for storing the exported video. It may need to be exported in stages when the video file is too large. Exporting will take more time ⚫ when too many files are selected. No other operations are possible ⚫...
  • Page 15 Pair with Baby Sleep Monitor (BBSM) If the monitor has never been paired with an BBSM, please press Menu>Setting>Bluetooth>Add device to start searching. Press and hold the Power key of BBSM to turn it on, and select its right name (BBSM S1+the last four number of SN) on the Monitor screen.
  • Page 16: General Settings

    Manage the bluetooth device Press MENU>Setting>Bluetooth to start managing Reminder and Unbind. Modify reminder thresholds. Available Step- Default Range size value Avg O level 80-99 Heart rate 110-200 (High) Heart rate 40-100 (Low) Note: The reminders are off by default. ⚫...
  • Page 17: Maintenance

    Date & Time ⚫ Select 12 Hour mode or 24 Hour mode. You can also press date or time to calibrate. Language ⚫ Select the desired language from provided options. Temperature ⚫ You can switch the temperature unit here. System ⚫...
  • Page 18: Troubleshooting

    Every effort has been made to ensure ⚫ high standards of reliability of the device. However, if something does go wrong, please do not try to repair it yourself - contact Customer Service for assistance. Note: Always power off and disconnect the power adapter before cleaning the device.
  • Page 19 for about 15 seconds before reconnecting. See 5.3 Pairing, if there is a need to ⚫ re-register the units. The reset key may be mistakenly ⚫ pressed. Please unbind the Camera Unit from Baby Monitor, then wait for the automatic pairing with Camera Unit powered on.
  • Page 20: Specifications

    10. Specifications Baby Monitor Frequency 2.4 GHz Brightness 4 steps control Volume control 4 steps Resolution ratio 720P Temperature –10°C~45°C (Operating) –30°C~70°C (Storage) Humidity 20%~85% (Operating) 20%~85% (Storage) Battery 4400mAh rechargeable lithium-polymer battery Adapter 5V/2A Interface Type-C Camera Unit Frequency 2.4 GHz Image sensor GC2053(1/2.9)...
  • Page 21: Symbols

    11. Symbols Symbol Description Manufacturer Date of manufacture Serial number Indicates a medical device that is not to be disposed of as unsorted municipal waste. Follow Instructions for Use. This product complies with the rules and regulations of the Federal Communication Commission.
  • Page 22: Fcc Statement

    12. FCC Statement FCC Warning: FCC ID: 2ADXK-1662(Model: BM-1T) 2ADXK-1663 (Model: BM-1R) Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with part 15 of the FCC Rules.
  • Page 23 The device has been evaluated to meet general RF exposure requirement. The following Warning only applies to model BM-1T: To maintain compliance with FCC's RF exposure guidelines, the distance must be at least 20 cm between the radiator and your...
  • Page 24 Shenzhen Viatom Technology Co., Ltd 4E, Building 3, Tingwei Industrial Park No. 6 LiufangRoad, Block 67 Xin’an Street, Baoan District, Shenzhen, 518101, Guangdong, China Product name: Baby Monitor Model: BM-1T Product name: Baby Monitor Model: BM-1R Version: A Date: September 22, 2022...
