- Page 1 Built-In Ceramic Hob CC302GC Installation and Operating Manual...
-
Page 2: Table Of Contents
CONTENTS: Installation Part 1: Safety warnings Operation & Maintenance Part 2: Installation Installation Instructions Product Overview Using your Hob Child Lock Part 3: Operating Pause Function Instructions Using the Timer Warning Indicators and Safety Mechanisms Cooking Guidelines Part 4: Cleaning and Cleaning and Maintenance Maintenance Troubleshooting... -
Page 3: Part 1: Safety Warnings
Congratulations on the purchase of your new hob and thank you for choosing our product. Please read all the safety instructions carefully before use and keep this Manual for future reference. Part 1. Safety Warnings Your safety is important to us. Please read below information carefully before installing or using your Hob. - Page 4 • This appliance is to be properly installed and earthed only by a suitably qualified person. • This appliance should be connected to a circuit which incorporates an isolating switch providing full disconnection from the power supply. • Failure to install the appliance correctly could invalidate any warranty or liability claims.
- Page 5 • Handles of saucepans may be hot to touch. Check saucepan handles do not overhang other cooking zones. Keep handles out of reach of children. • Failure to follow this advice could result in burns and scalds. Important safety instructions •...
- Page 6 hob, as these can scratch the ceramic glass. • If the power supply cable is damaged, it must only be replaced by qualified technician. •This appliance is intended to be used in domestic or similar applications such as: -staff kitchen areas in non-commerical kitchens; farm houses; by clients in hotels, motels and other residential type environments;...
-
Page 7: Part 2: Installation
(measure by unit: mm): - Cut out the work surface according to the sizes shown in the diagram below. Dimensions in mm Model CC302GC 265+5 495+5 50 min Under all circumstances, make sure the electric hob is well ventilated and the air inlet and outlet are not blocked. - Page 8 Note: The safety distance between the hotplate and the cupboard above the hotplate should be at least 760mm. A(mm) B(mm) C(mm) 760mm 50mm min. 20mm min. Air intake Air outlet 5mm Ensure cabinetry, rear and adjacent walls are able to resist temperatures up to 150 Installing the foam gasket Before inserting the hob into the cabinetry cutout, the supplied foam gasket (in a...
- Page 9 The gasket is to be attached with the following method: ▪ Remove the protection film from the gasket. ▪ Then attach the gasket to the lower side of the glass, next to the edge. ▪ The gasket must be attached along the entire length of the glass edge and should not overlap at the corners.
- Page 10 Fix hob to work surface : Insert the hob into the work surface as below diagrams, the fixing clips on the sides will secure your hob sturdily. Connecting the hob to the mains power supply The manufacturer will not be liable for any direct or indirect damaged caused by faulty installation.
- Page 11 Product Model : CC302GC Rated Voltage 240V~ Rated Frequency 50Hz Max. Rated Input 3000W Supply Connection : 16A (double pole switched fused outlet with 3mm contact gap) Notes: 1. If the cable is damaged or needs replacing, this should be done by an after-sales technician using the proper tools, so as to avoid any accidents.
- Page 12 Part 3. Operating Instructions Product Overview Model: CC302GC 1. 1800W Cooking Zone 2. 1200W Cooking Zone 3. Glass plate 4. Control panel Control Panel 1. Pause button 2. Timer control button 3. Cooking Zone selection button 4. Heating level/Timer decrement button 5.
- Page 13 Before using your new Hob • Read this guide, taking special note of the ‘Safety Warnings’ section. • Remove any protective film that may still be on your new electric hob. Using the Touch Controls • The controls respond to touch, so you don’t need to apply any pressure. •...
-
Page 14: Using Your Hob
Using your Hob To start cooking 1. After the hob be connected to the power supply. Press and hold the ON/OFF control button for about 3 seconds till you hear a “beep” to turn the hob on. Now the hob enters into Standby mode, all heat setting indicators and Timer setting indicators shows “-”... - Page 15 To turn off the Hob 1. You can turn the cooking zone off by selecting the zone (if you are using more than one zone at a time) then adjust the heat setting to level 0 indicated by “-“ sign 2.
-
Page 16: Pause Function
Pause function • This function can be used when you are being interrupted whilst cooking or you need to leave the cooking area temporarily. • The Pause function can turn off all zones. With one more touch of the button , the hob restarts with the previous settings to carry on cooking. - Page 17 Touch control models: • Set heat setting by touching the button. • Press and hold either of the adjustment buttons to adjust the setting rapidly. Note: When the timer indicator is flashing, touch timer control button one more time, to quickly confirm the timer setting. 3.
- Page 18 5. When cooking timer elapses, the corresponding cooking zone will switch off automatically. Note: The default setting of the minute reminder and timer is 30 minutes. Note: After adjusting, the timer indicator will flashing for 5 seconds and when flashing is stop, the setting is registered. Note: The minute reminder and timer can be used at the same time, timer indicator shows the lowest time setting.
-
Page 19: Cooking Guidelines
Cooking Guidelines Take care when frying as the oil and fat heat up quickly. At extremely high temperatures oil and fat can ignite spontaneously and present a risk of fire. Cooking Tips • When food comes to the boil, reduce the power setting. •... - Page 20 Heat Settings The settings below are guidelines only. The exact setting will depend on factors including your cookware and the amount you are cooking. Experiment with the hob to find the settings that best suit you. Heat setting Suitability • delicate warming for small amounts of food 1 - 2 •...
-
Page 21: Cleaning And Maintenance
Part 4. Cleaning and Maintenance Cleaning and Maintenance Important: Before any maintenance or cleaning work is carried out, DISCONNECT the appliance from power supply and ensure the appliance is completely cool. Cleaning the Hob Surface Clean spillages from the hob surface as soon as possible after use. Always ensure the surface is cool enough before cleaning. -
Page 22: Troubleshooting
Boil over, Remove these immediately • Remove stains left by melts melts, and hot with a scraper suitable for and sugary food or spillovers sugary spills ceramic glass of hobs, but as soon as possible. If left to on the glass beware of hot cooking zone cool on the glass, they may surfaces:... - Page 23 2. The touch control panel buttons cannot be activated: - Check if it’s under “Child Lock”, whereby a “Lo” shows in timer display; - Check whether liquid/wet cloth is over the touch control panel and overflow protection has been activated. Wipe dry area; 3.
- Page 24 Important Note: This appliance is labeled in compliance with European directive 2002/96/EC for Waste Electrical and Electronic Equipment (WEEE). By ensuring that this appliance is disposed of correctly, you will help prevent any possible damage to the environment and to human health, which might otherwise be caused if it were disposed of in the wrong way.
