- Page 1 Electric Induction Hob IC603GKB Installation and Operating Manual...
-
Page 2: Table Of Contents
CONTENTS: Part 1: Safety warnings Installation Operation & Maintenance Part 2: Installation Dimensions & Installation Instructions Power Connection Part 3: Operating Product Overview Instructions Using your Hob Using Booster Function Flexible Zones Child Lock Pause Function Using the Timer Warning Indicators and Safety Mechanisms Cooking Guidelines Part 4: Cleaning and... -
Page 3: Part 1: Safety Warnings
Congratulations on the purchase of your new hob and thank you for choosing our product. Please read all the safety instructions carefully before use and keep this Manual for future reference. Part 1. Safety Warnings Safety Warnings Your safety is important to us. Please read below information carefully before installing or using your Hob. - Page 4 • This appliance is to be properly installed and earthed only by a suitably qualified person. • This appliance should be connected to a circuit which incorporates an isolating switch providing full disconnection from the power supply. • Failure to install the appliance correctly could invalidate any warranty or liability claims.
- Page 5 overhang other cooking zones. Keep handles out of reach of children. • Failure to follow this advice could result in burns and scalds. Important safety instructions • Never leave the appliance unattended when in use. Boil over causes smoking and greasy spillovers that may ignite. •...
- Page 6 • If the power supply cable is damaged, it must only be replaced by qualified technician. •This appliance is intended to be used in domestic or similar applications such as: -staff kitchen areas in non-commerical kitchens; farm houses; by clients in hotels, motels and other residential type environments;...
-
Page 7: Part 2: Installation
(measure by unit: mm): - Cut out the work surface according to the sizes shown in the diagram below. Dimensions in mm Model IC603GKB 555+5 495+5 50 min Under all circumstances, make sure the electric hob is well ventilated and the air inlet and outlet are not blocked. - Page 8 Note: The safety distance between the hotplate and the cupboard above the hotplate should be at least 760mm. A(mm) B(mm) C(mm) 760mm 50mm min. 20mm min. Air intake Air outlet 5mm Ensure cabinetry, rear and adjacent walls are able to resist temperatures up to 150 Installing the fixing brackets The unit should be placed on a stable, smooth surface (use the packaging).
- Page 9 cabinet/work surface. Fix hob to work surface: Insert the hob into the work surface as below diagrams, the fixing clips on the sides will secure your hob sturdily. Power Connection The manufacturer will not be liable for any direct or indirect damaged caused by faulty installation.
- Page 10 Notes: 1. If the cable is damaged or needs replacing, this should be done by an after- sales technician using the proper tools, so as to avoid any accidents. 2. IMPORTANT: For direct connection to the mains, there must be a double pole switch fused outlet with 3mm or greater contact gap.
- Page 11 Part 3. Operating Instructions Product Overview Model: IC603GKB 1. 1500W boost 2000W Cooking Zone 2. 2000W boost 2600W Cooking Zone 3. 3000W boost 3600W Flexi area-Left 4. 2000W boost 3000W Cooking Zone 5. 1500W boost 2000W Cooking Zone 6. Glass surface 7.
- Page 12 Before using your new Hob • Read this guide, taking special note of the ‘Safety Warnings’ section. • Remove any protective film that may still be on your new electric hob. Using the Touch Controls • The controls respond to touch, so you don’t need to apply any pressure. •...
- Page 13 Make sure that the base of your pan is smooth, sits flat against the glass, and is the same size as the cooking zone. If you use smaller pot efficiency could be less than expected. Always centre your pan on the cooking zone. Always lift pans off the hob –...
-
Page 14: Using Your Hob
Using your Hob To start cooking 1. After the hob be connected to the power supply. Press and hold the ON/OFF control button for about 3 seconds till you hear a “beep” to turn the hob on. Now the hob enters into Standby mode, all heat setting indicators and Timer setting indicators shows “-”... - Page 15 Note: The cooling fan of induction hob will remain on for about 1 minute after the hob is turned off. Using Booster Function-Induction Hob Some of induction hob models might have one or several cooking zones which has a Booster function. You can use the “Booster” function to boost power of relevant cooking zone for a maximum power rating for 5 minutes.
- Page 16 Important: Ensure cookware are centered on the single cooking zone. In the case of big pots, oval,rectangular and elongated pans make sure the pan covers the flexi-induction printing. Activate the Flexible Induction Zone To activate the flexible area as a single big zone, first press any of the two cooking zone selection buttons in this flexible area, then press the flexible zone control button (5).
-
Page 17: Pause Function
2. Touch and hold the Child Lock control button for 3 seconds, the buzzer beeps once and “Lo” disappears from the timer indicator, the Child Lock is deactvated 3. You can now start using your electric hob. Under the child lock mode, all controls button be disable except the ON/OFF button and child lock button. -
Page 18: Using The Timer
Using the Timer When the hob is turned on, you can use the timer in two different ways: • You can use it as a minute minder. In this case, the timer will not turn any cooking zone off when the set time is up. •... - Page 19 immediately, the display will show the remaining time. 4. Buzzer will beep for 30 seconds and timer indicator shows “- - “when the set time has finished. Setting the timer to turn cooking zone off 1. Select the cooking zone you wish to set timer for. 2.
- Page 20 NOTE: If more than one heating zone has a timer setting, the timer indicator will show the shortest set time. The red dot next to the applicable zone indicator will flash. 5. When the cooking time expires, the corresponding cooking zone will switch off automatically. Note: The default setting of minute reminder and timer is 30 minutes.
-
Page 21: Cooking Guidelines
Another safety feature of the hob is auto shutdown. This occurs whenever you forget to switch off a cooking zone. The default shutdown times as below table: Power level Default working timer (hour) Over-heat Protection A temperature sensor monitors the temperature inside the hob. When excessive temperature is registered, the hob will auto stop operations. - Page 22 4. Turn the steak only once during cooking. The exact cooking time will depend on the thickness of the steak and how cooked you want it. Times may vary from about 2 – 8 minutes per side. Press the steak to gauge how cooked it is –...
-
Page 23: Cleaning And Maintenance
Part 4. Cleaning and Maintenance Cleaning and Maintenance Important: Before any maintenance or cleaning work is carried out, DISCONNECT the appliance from ELECTRICITY supply and ensure the appliances is completely cool. Cleaning the Hob Surface Clean spillages from the hob surface as soon as possible after use. Always ensure the surface is cool enough before cleaning. - Page 24 Boil over, Remove these immediately • Remove stains left by melts melts, and hot with a scraper suitable for and sugary food or spillovers sugary spills ceramic glass of hobs, but as soon as possible. If left to on the glass beware of hot cooking cool on the glass, they may zone surfaces:...
-
Page 25: Troubleshooting
Troubleshooting Before you contact the service centre, the below actions may resolve the issue: 1. There is no power to the appliance: - Check whether there is a power failure in your area; - Check whether the appliance be connected to power supply and mains switched on;... -
Page 26: Error Codes
Error Codes If an abnormality comes up, the induction hob will enter a protective state automatically and display corresponding error codes: Problem Possible causes What to do E1/E2 Abnormal supply voltage Please check whether power supply is normal, Power on after the power supply is normal.
