Art. no.: FMUD5500REG
Operating instructions
1 Safety instructions
Electrical devices may only be mounted and connected by electrically skilled persons.
Serious injuries, fire or property damage possible. Please read and follow manual fully.
Danger of electric shock. Always disconnect before carrying out work on the device or load. In
so doing, take all the circuit breakers into account, which support dangerous voltages to the
device and or load.
Danger of electric shock. Device is not suitable for disconnection from supply voltage. The load
is not electrically isolated from the mains even when the device is switched off.
Danger of electric shock. During installation and cable routing, comply with the regulations and
standards which apply for SELV circuits.
Risk of destruction if the set operating mode and load type do not match. Set correct operating
mode when connecting or exchanging the load.
Fire hazard. For operation with inductive transformers, each transformer must be fused on the
primary side in accordance with the manufacturer's instructions. Only safety transformers ac-
cording to EN 61558-2-6 may be used.
Fire hazard! Operation exclusively with the power supplies listed under accessories
These instructions are an integral part of the product, and must remain with the end customer.
2 Intended use
– Switching and dimming of lighting
– Operation with power supply RMD and receiver module RMD cover or eNet server (see
accessories)Operation with power supply RMD and receiver module RMD cover or eNet
server (see accessories)
– Operation with suitable radio transmitters
– Installation in small distributors on DIN rail according to EN 60715
Product characteristics
– Switch-on via bulb-preserving soft start
– Switch-on brightness can be saved permanently
– Minimum brightness can be saved permanently
– Scene operation possible
– Status indication with LED
– Status feedback to radio transmitter
– Switchable with Prog. button
– Electronic short-circuit protection with permanent switch-off after 7 seconds at the latest
– Electronic over-temperature protection
– Automatic or manual setting of the dimming principle suitable for the load
– It is possible to increase power by means of power packs
Can be set with eNet server:
– Maximum brightness
– Dimming speed
– Switch-on delay / switch-off delay
– Dim up/dim down ramp
– Switch-off warning
