- Page 1 USER MANUAL SPIRAL MIXER EMP-SM25RB EMP-SM60RB User Manual Warning: Please read the user manual carefully before operating the machine...
-
Page 2: Installation
Switch Warnin 1/ Keep in order your working area. Disorder can cause dangerous accidents. The machines are provided with the following 2/ Consider environmental conditions. Do not operation and safety devices： use the machine in humid, wet or badly lit 1/ Operating devices environments, close to inflammable liquids or 1.1 / Sing-phase or Three-phase machines (LFM10... - Page 3 Safety Device Safety guard (Pict.4) Micro-switch(Auto-stop when the guard is up) Check pin of the head Locking disk of the bowl. Pict.4 1/ the safety devices G, H, I, J can be installed only in the machines with raising top and removable bowl (LR series). 2/ The safety devices are applicable when: - Raising the safety guard F (pict.4).
- Page 4 Usage of the machine 1/ After lifted up the safety guard F, pour ingredients to the bowl, close the safety guard, and press the operating switch a or D, with timer setting. 2/ The movement made by the hook, which is synchronized with the rotation of the bowl, gives an amalgamation of flour, water, salt, yeast and other eventual ingredients till you obtain a mixture of the consistence required.
- Page 5 Maintenanc Warning: 1/ Before effecting any kind of maintenance or cleaning, you must cut off the power supply. In any case of malfunctioning or damage of the machine, you must apply for authorized assistance from the manufacturer or dealer. 2/ The cleaning must be done every time the machine has been used following all the rules to prevent malfunctioning of the machine and for hygienic purposes.
- Page 6 Specification Table Single phase & single speed JFM/EMP-S JFM/EMP-S Model JFM10 JFM/JRM20 JFM/JRM30 JFM/JRM50 M25RB M60RB Voltage(V) Cycle(Hz) Power(KW) 0.75 Max Dough capacity(KG) Hook speed(rpm) Bowl speed(rpm) Dimension(cm) 28x54x55 72x40x62 72x40x62 82x45x72 84x50x72 88x55x72 Three phase & single speed Model JF/JR20 JF/JR25 JF/JR30...
- Page 7 JFM10 /5 Singlephase single speed SS: Micro Switch M: Motor FA: Thermo-protect of motor KLD-28A: Switch Power Source Wire: L(red) N(blue) Ground Wire E:(yellow-green) EMP-SM25RB EMP-SM60RB/JFM SS: Micro Switch Singlephase & single speed M: Motor SP: Sensor QS: Main Switch T: Transformer KM: Contactor...
- Page 8 Machine illustration diagram & Part list LFM 10 JF serial illustration Part list Item Item Description Part No. Description Part No. Safety guard 10-005 Top cover 10-004 Bowl 10-006 Nylon ring 22-029 Transit ring 10-023 screw 22-070 Bearing 6204 10-025 Wheel 22-032...
- Page 9 LF Series illustration diagram LF serial illustration Part list Part no. Item Description Remark LFM/LF/LF-2V 20 LFM/LF/LF-2V 25 Safety guard 17-003 22-005 Bowl 17-002 22-006 Transit ring 22-053 22-053 Bearing 6205 22-055 22-055 Bearing support 22-019 22-019 Chain126 22-041 22-041 Chain wheel 72 22-042 22-042...
- Page 10 LF serial illustration Part Continue……… list Part no. Item Description Remark LFM/LF/LF-2V 20 LFM/LF/LF-2V 25 22-152 22-152 Motor 22-046 22-046 22-153 22-153 LF-2V Top cover 22-009 22-009 Nylon ring 22-029 22-029 Electrical box 22-096 22-096 Wheel 22-032 22-032 22-155 22-155 Contactor 22-108 22-108...
- Page 11 JF serial illustration Part list Part no. Item Description Remark JFM/JF/JF-2V 30 JFM/JF/JF-2V 50 JFM/JF/JF-2V 60 Safety guard 33-005 42-003 53-002 Bowl 33-006 42-002 53-001 Transit ring 22-053 22-053 22-053 Bearing 6205 22-055 22-055 22-055 Bearing support 22-019 22-019...
- Page 12 JF serial illustration Part Continue……… list Part no. Item Description Remark JFM/JF/JF-2V 30 JFM/JF/JF-2V 50 JFM/JF/JF-2V 60 Electrical panel 22-097 22-097 22-097 Start Switch 22-100 22-100 22-100 Timer 22-103 22-103 22-103 Chain 33-028 42-007 53-005 Chain wheel 29 33-032 33-032...
- Page 13 EMP-SM25RB EMP-SM60RB Series illustration diagram LR serial illustration Part list Part no. Item Description Remark JRM/JR/JR-2V 20 JRM/JR/JR-2V 25 Safety guard 17-003 22-005 Bowl 17-002 22-006 Bowl Flange 22-022 22-022 Locking Flange 17-005 22-008 Transit ring 22-053 22-053 Bearing 6205...
- Page 14 22-108 22-108 22-108 22-108 LR-2V Emergency stop 22-099 22-099 Transit ring 22-093 22-093 Gear box 22-074 22-074 Back cover 22-010 22-010 22-154 22-154 22-107 22-107 Transformer 22-107 22-107 LR-2V Applicable model : JRM20 EMP-SM25RB JR20 JR25 JRM20-2V JRM25-2V JR20-2V JR25-2V...
- Page 15 22-187 22-187 Adjusting screw 22-192 22-192 Auxiliary relay PCB 22-281 22-281 Hook washer 22-193 22-193 110-LRM 110-LRM Electrical complete 110-LR 110-LR 110-LR-2V 110-LR-2V LR-2V Spiral support complete 111-TR17/22 111-TR17/22 Applicable model : JRM20 EMP-SM25RB JR20 JR25 JRM20-2V JRM25-2V JR20-2V JR25-2V...
- Page 16 JR serial illustration Part list Part no. Item Description Remark JRM/JR/JR-2V 30 JRM/JR/JR-2V 50 JRM/JR/JR-2V 60 Safety guard 33-005 42-003 53-002 Bowl 33-006 42-002 53-001 Bowl Flange 22-022 22-022 22-022 Locking Flange 33-008 42-005 53-004 Transit ring 22-053 22-053...
- Page 17 JR serial illustration Part Continue……… list Part no. Item Description EMP-SM60RB/JR/JR Remark JRM/JR/JR-2V 30 JRM/JR/JR-2V 50 -2V 60 Fuse holder 22-101 22-101 22-101 Gear box 33-034 33-034 33-034 Back cover 33-010 33-010 33-010 Transformer 22-107 22-107 22-107 Main Switch 22-169 22-169 22-169 Electrical panel...
- Page 18 Trouble shooting Trouble Cause Solution Lack of electric energy in the power supply Check the main switch, the The Emergency stop switch is locked plug, the wire. The safety guard and/or the head are up Rotate the button following the The knob of the general switch is in direction of the arrow.
