- Page 1 Refrigerator User manual RT65*/RT62*/RT61*/RT58* Free Standing Appliance Untitled-2 1 2018-08-30 2:35:11...
-
Page 2: Table Of Contents
Contents Safety information Important safety symbols and precautions: Severe warning signs for transportation and site Critical installation warnings Installation cautions Critical usage warnings Usage cautions Cleaning cautions Critical disposal warnings Additional tips for proper usage Saving Energy Tips This appliance is intended to be used in household and similar applications such as Instructions about the WEEE Installation Refrigerator at a glance... -
Page 3: Safety Information
Safety information • Before using your new Samsung Refrigerator, please read this manual thoroughly to ensure that you know how to operate the features and functions that your new appliance offers safely and efficiently. • This appliance is not intended for use by persons (including... - Page 4 Safety information • In order to avoid the creation of a flammable gas-air mixture if a leak in the refrigerating circuit occurs, the size of the room in which the appliance may be sited depends on the amount of refrigerant used. •...
-
Page 5: Important Safety Symbols And Precautions
Important safety symbols and precautions: WARNING Hazards or unsafe practices that may result in severe personal injury or death. CAUTION Hazards or unsafe practices that may result in minor personal injury or property damage. These warning signs are here to prevent injury to you and others. Please follow them carefully. -
Page 6: Critical Installation Warnings
Safety information Critical installation warnings WARNING • Do not install the refrigerator in a damp location or place where it may come in contact with water. - Deteriorated insulation on electrical parts may cause an electric shock or fire. • Do not place this refrigerator in direct sunlight or expose it to the heat from stoves, room heaters, or other appliances. - Page 7 • Never unplug your refrigerator by pulling on the power cord. Always grip the plug firmly and pull straight out from the outlet. - Damage to the cord may cause a short-circuit, fire, and/or electric shock. • Do not store explosive substances such as aerosol cans with a flammable propellant in this appliance.
- Page 8 Safety information • If any dust or water is in the refrigerator, pull out power plug and contact your Samsung Electronics service center. - Otherwise there is a risk of fire. • Do not stand on top of the appliance or place objects (such as laundry, lighted candles, lighted cigarettes, dishes, chemicals, metal objects, etc.) on the appliance.
-
Page 9: Installation Cautions
• If the power cord is damaged, have it replaced immediately by the manufacturer or one of its service agents. • The fuse on the refrigerator must be changed by a qualified technician or service company. - Failing to do so may result in an electric shock or personal injury. -
Page 10: Critical Usage Warnings
Safety information Critical usage warnings WARNING • Do not insert the power plug into a wall socket with wet hands. - This may result in an electric shock. • Do not store articles on the top of the appliance. - When you open or close the door, the articles may fall and cause personal injury and/or material damage. - Page 11 • If you smell pharmaceutical or smoke, pull out power plug immediately and contact your Samsung Electronics service center. • If any dust or water is in Refrigerator, pull out power plug and contact your Samsung Electronics service center.
- Page 12 Safety information • Do not use or place any substances sensitive to temperature such as flammable sprays, flammable objects, dry ice, medicine, or chemicals near or inside of the refrigerator. • Do not use a hair dryer to dry the inside of the refrigerator. Do not place a lighted candle in the refrigerator for removing bad odours.
- Page 13 • If the interior or exterior LED lamp has gone out, contact your nearest service center. • If the refrigerator emits a burning smell or smoke, unplug the refrigerator immediately and contact your Samsung Electronics service center. - Failing to do so may result in an electric or fire hazards.
-
Page 14: Usage Cautions
• If the product is equipped with LED lamps, do not disassemble the Lamp Covers and LED lamps yourself. - Contact a Samsung service center. • Plug the power plug into the wall socket firmly. • Do not use a damaged power plug, damaged power cord or loose wall socket. - Page 15 - Any changes or modifications performed by a 3rd party on this finished appliance are not covered under Samsung warranty service, nor is Samsung responsible for safety issues that result from 3rd party modifications. • Do not block the air vents inside the refrigerator.
- Page 16 Safety information • Do not strike or apply excessive force to any glass surface. - Broken glass may result in a personal injury and/or property damage. • Fill the water tank and ice cube trays with potable water only (tap water, mineral water, or purified water).
-
Page 17: Cleaning Cautions
Cleaning cautions CAUTION • Do not spray water directly on the inside or outside the refrigerator. - There is a risk of fire or electric shock. • Do not use a hair dryer to dry the inside of the refrigerator. •... - Page 18 Safety information • Do not use abrasive or harsh cleansers such as window sprays, scouring cleansers, flammable fluids, muriatic acid, cleaning waxes, concentrated detergents, bleaches, or cleansers containing petroleum products on exterior surfaces (doors and cabinet), plastic parts, door and interior liners, and gaskets. - These can scratch or damage the material.
-
Page 19: Critical Disposal Warnings
Critical disposal warnings WARNING • Please dispose of the packaging material from this product in an environmentally friendly manner. • Ensure that none of the pipes on the back of the refrigerator are damaged prior to disposal. • R-600a or R-134a is used as a refrigerant. Check the compressor label on the rear of the appliance or the rating label inside the fridge to see which refrigerant is used for your refrigerator. -
Page 20: Additional Tips For Proper Usage
Safety information Additional tips for proper usage • In the event of a power failure, call the local office of your electric company and ask how long the failure is going to last. - Most power failures that are corrected in an hour or two will not affect your refrigerator temperatures. -
Page 21: Saving Energy Tips
Saving Energy Tips • Install the appliance in a cool, dry room with adequate ventilation. Ensure that it is not exposed to direct sunlight and never put it near a direct source of heat (a radiator, for example). • Not to block any vents and grilles is recommended for energy efficiency. -
Page 22: Instructions About The Weee
Safety information Instructions about the WEEE Correct Disposal of This Product (Waste Electrical & Electronic Equipment) (Applicable in countries with separate collection systems) This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g. charger, headset, USB cable) should not be disposed of with other household waste at the end of their working life. -
Page 23: Installation
Installation Follow these instructions carefully to ensure a proper installation of this refrigerator and to prevent accidents before using it. WARNING • Use the refrigerator only for its intended purpose as described in this manual. • Any servicing must be performed by a qualified technician. •... - Page 24 Installation Optional accessories * Cool pack: This helps keep the refrigerator cool. Twist Ice Maker: Used to make ice. * Your refrigerator may not include optional accessories listed above. Provision of optional accessories depends on the model and the country. To secure more room for storage in the freezer compartment Remove the ice maker, which can be detached manually without a tool.
-
Page 25: Step-By-Step Installation
Step-by-step installation STEP 1 Select a site Site requirements: • Solid, level surface without carpeting or flooring that may obstruct ventilation • Away from direct sunlight • Adequate room for opening and closing the door • Away from a heat source •... - Page 26 Installation Clearance See the pictures and table below for space requirements for installation. Model RT61, RT58 1507 1352 120˚ RT65, RT62 1507 1352 120˚ (unit: mm) 01 100 mm 02 50 mm 03 at least 50 mm English Untitled-2 26 2018-08-30 2:35:14...
- Page 27 Please check with your dealer for availability. CAUTION • The Samsung Smart Home Adapter comes in two types: one that is dedicated to Samsung smart TVs, and the other one that is dedicated to Samsung home appliances. • You must purchase the Samsung Smart Home Adapter (HD39N1230GW) dedicated to home appliances.
- Page 28 Installation 4. Insert the upper area of the adapter cover first, and then close to lock as shown. NOTE The marked area is the cover of the optional adapter, not a crack or defect. STEP 3 Flooring • The surface to install the refrigerator must support a fully loaded refrigerator, or approximately 100 kg.
- Page 29 STEP 4 Adjust the levelling feet Level the refrigerator by manually adjusting the levelling feet. Turn the levelling feet clockwise to lower the position, or turn counter clockwise to raise. Leave the feet at least 35 mm (A) from the floor as shown.
- Page 30 Installation STEP 5 Unpack and put accessories in place (applicable models only) The accessories that ship with this refrigerator are properly packed for transportation and safety reasons. Unpack those accessories and put them in place. Door bins There are door bins provided with the product.
- Page 31 STEP 7 Final check When installation is complete, confirm that: • The refrigerator is plugged into an electrical outlet and grounded properly. • The refrigerator is installed on a flat, level surface with a reasonable clearance from the wall or the cabinet. •...
-
Page 32: Operations
Operations Feature panel TYPE A TYPE B TYPE C 01 Freezer / Power Freeze 02 Freezer Convert 03 Fridge / Power Cool / Vacation 04 Cool Select+ / Cool 05 Door Alarm / Control 06 Network connection Select Zone (Type A and Lock (applicable models only) Type B models only) - Page 33 01 Freezer / Power Freeze The Freezer button can be used to set the freezer temperature. Available temperatures are between -15 °C and -23 °C. CAUTION Freezer • To prevent system failure or food spoiling, do not set the temperature to -15 °C in summer (above 35 °C). •...
- Page 34 Operations 02 Freezer Convert You can use the entire refrigerator with Fridge mode, or turn off the freezer. To change the default freezer mode, press and hold Freezer Convert for 3 seconds to enter the selection mode. Then, press Freezer Convert to select a desired mode.
- Page 35 NOTE If you want to use Freezer Convert, it is strongly recommend to use plastic containers to store food, especially vegetables. 03 Fridge / Power Cool / Vacation To adjust the fridge temperature, press Fridge to select the corresponding temperature. You can change the temperature between 1 °C and 7 °C.
- Page 36 Operations If you are going on vacation or a business trip, or if you do not intend to use the fridge for an extended time, use the Vacation mode. (Type A and Type B models only) • To activate Vacation mode, press Fridge with the 1 °C indicator selected.
- Page 37 To deactivate, press and hold again for 3 seconds. The controls will be enabled as normal. When connecting the refrigerator to Samsung Smart Home App or Samsung smart devices such as Samsung Smart TVs, follow the app's or device's onscreen instructions and press and hold Door Alarm for Device authentication 5 seconds.
- Page 38 • If your Internet service provider has registered the MAC address of your PC or modem for identification, your Samsung Smart Refrigerator may fail to connect to the Internet. If this happens, contact your Internet service provider for technical assistance.
-
Page 39: Smartthings (Available Only With The Optional Adapter)
Samsung account You are required to register with a Samsung account to use the app. If you don’t have a Samsung account, follow the app’s onscreen instructions to create a free Samsung account. -
Page 40: Key Features
Operations Key features Register Samsung smart home appliances to the SmartThings server for remote access. Menu overview You can control your Samsung smart home appliances remotely, Chat control or check the operating status. Home view By using the built-in camera of a Samsung smart home (applicable models appliance, you can monitor your living room. - Page 41 • Displays the product information including the current version, tutorial, Self Check, and Help Desk. The user manual is downloadable, and the contact information for customer support is also provided. About Device Self Check By referencing Self Check, you can check the diagnostic results of your refrigerator.
-
Page 42: Special Features
Operations Special features The actual image and special functions of your refrigerator may differ, depending on the model and the country. Ice making (applicable models only) Twist ice maker 1. Open the freezer door, and slide open the ice tray. 2. - Page 43 Water dispenser With the water dispenser, you can dispense water without opening the fridge door. The water tank must be filled with potable water before use. To fill the water tank with potable water Open the door and locate the water tank that is located in the door shelf area. 1.
- Page 44 Operations 4. Put a water glass under the water outlet of the dispenser, and gently push the dispenser lever to dispense water. Make sure the water dispenser is unlocked. CAUTION • The water dispenser is designed to dispense potable water. Fill the water tank only with potable water.
-
Page 45: Maintenance
Maintenance Handle and care Freezer and fridge shelves • To remove a shelf, first open the door completely. Pull the shelf forward, lift up, and then pull out. • When reinserting the shelf, make sure the “Front” label of the shelf faces forward. -
Page 46: Cleaning
(A). Replace the filter, and then reinsert the case. Lamps and anti-bacteria filter Neither lamps nor the anti-bacteria filter are user-serviceable. Do not attempt to replace them yourself. To replace them, contact a local Samsung service centre. English Untitled-2 46 2018-08-30... -
Page 47: Troubleshooting
Troubleshooting If you encounter an abnormal situation with the refrigerator, first check the table below and try the suggestions. General Symptom Action • Make sure the power cord is connected properly. • Make sure the temperature control is set correctly. •... - Page 48 Troubleshooting Symptom Action • To prevent condensation from forming, the refrigerator has heat-proof piping in the front corners. If the ambient The front corners temperature rises, this equipment may not work effectively. and sides become This is not a system failure. warm and form •...
-
Page 49: Smartthings
• The old Samsung Smart Refrigerator app cannot connect with fails to operate. SmartThings models. • You must log into your Samsung account to use the app. • Make sure that your router is operating normally. The SmartThings app • Make sure that the Smart Home Adapter is inserted properly. - Page 50 Memo Untitled-2 50 2018-08-30 2:35:18...
- Page 51 Memo Untitled-2 51 2018-08-30 2:35:18...
- Page 52 Contact SAMSUNG WORLD WIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. Country Contact Center Web Site 0800 726 786 (All Product) NEW ZEALAND www.samsung.com/nz/support 0800 6 726 786 (Support for Smart...
