3 Port USB 2.0 Hub with 16-in-1 Card Reader
ST4205READ

Introduction

Thank you for purchasing a StarTech.com 3 Port
USB 2.0 Hub with 16-in-1 Card Reader. This product
allows you to add 3 USB 2.0 ports to your computer,
and also functions as a Card Reader supporting the
most popular types of flashcard media.

Features

• Compact, space-saving design
• Supports USB 2.0 transfer rates up to 480Mbps
• Backwards compatible with USB 1.1 devices
• Easy installation
• Can be powered by external power adapter or USB
• Sturdy aluminum construction
• 16-in-1 Card Reader supports the following flash
media:
CF Type I, II
IBM Micro Drive
SM
MS, MS Pro, MS Duo, MS Pro Duo,
MS Magic Gate,
MS Pro Magic Gate,
MS Select Function, SD, MMC,
Mini SD, SM RAM Card

Before You Begin

System Requirements

• Operating system: Windows 98SE or higher
Mac OS 8.6 or higher
• An available USB port

Contents

• USB 2.0 Hub with Card Reader (1)
• USB Cable (1)
• User Manual (1)
• 5V DC Power Supply (1)

Basic Setup

Installation

1. Ensure the host computer is powered on.
2. Plug the provided USB cable into an available USB
port on the computer.
3. Plug the opposite end of the USB cable into the
Mini B port on the USB hub.
4. If you will be using several high-powered devices
with the USB hub, you may need to use the power
adapter. If this is the case, plug the adapter into
the DC power port on the USB hub, and connect
the opposite end to an available power source.

Verifying Installation

Mac: To verify installation in a Mac system, please
go to Apple System Profiler\Devices and
Volumes\USB
Windows: To verify installation is complete in
Windows, browse to Control Panel >
System > Hardware > Device
Manager. Under the Universal Serial
Bus heading, you should see Generic
USB Hub. If installed
correctly, there will be no question or
exclamation marks beside the device
name. Similarly, The 16-in-1 card reader
should appear under Disk Drives.
Please note: In Windows ME, the device may be list-
ed with a green question mark beside its name. This
is due to the fact that Windows ME cannot identify the
USB Hub brand name, however this will not affect
device performance.

Overcurrent status

If you are using several high-current devices with the
USB Hub, you may exceed the current limit. If this
occurs, the hub will disconnect power from the related
port, and the device will stop functioning. In this
case, please use the optional power adapter included
with the hub.

Specifications

Cerfifications (Regulatory and other) FCC, CE, RoHS, WEEE
Bus type
USB
1 x USB Mini B Male
Connectors
4 x USB Type A Male
Power adapter
5V DC
Maximum data transfer rate
480 Mbps
Windows 98SE and higher
Operating System support
Mac OS 8.6 and higher
Operating temperature
0 to 70° C

Support, Warranty Information, and Regulatory Compliance Statement

If you ever need help with your product, visit www.startech.com/support and access our com-
prehensive selection of online tools, documentation, and downloads. This product is backed by a
one-year warranty. In addition, StarTech.com warrants its products against defects in materials
and workmanship for the periods noted, following the initial date of purchase. During this period,
the products may be returned for repair, or replacement with equivalent products at our discre-
tion. The warranty covers parts and labor costs only. StarTech.com does not warrant its products
from defects or damages arising from misuse, abuse, alteration, or normal wear and tear.
Limitation of Liability: In no event shall the liability of StarTech.com Ltd. and StarTech.com USA
LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect,
special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any
pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for
the product. Some states do not allow the exclusion or limitation of incidental or consequential
damages. If such laws apply, the limitations or exclusions contained in this statement may not
apply to you.
FCC Compliance Statement: This equipment has been tested and found to comply with the lim-
its for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be deter-
mined by turning the equipment off and on, the user is encouraged to try to correct the interfer-
ence by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is con-
nected.
• Consult the dealer or an experienced radio/TV technician for help.
Revised: 13 July 2006 (A)
