- Page 1 OPERATOR AND PARTS MANUAL Rotary Cutter Series I 092013 FK372...
-
Page 3: Table Of Contents
Table of Contents - Series I Rotary Cutter Table of Contents Introduction ..........................5 Safety ............................6 • Safety Instruction ......................6 • General Safety ........................7 • Start-up Safety .........................7 • Operation Safety ......................7 • Transport Safety .......................7 • Service and Maintenance Safety ..................8 •... - Page 4 Table of Contents - Series I Rotary Cutter Shipping Kit and Bundle Numbers ..................28 Warranty .............................30 Manufacturer’s statement: for technical reasons Buhler Industries Inc. reserves the right to modify machinery design and specifications provided herein without any preliminary notice. Information provided herein is of descriptive nature. Performance quality may depend on soil fertility, applied agricultural techniques, weather conditions and other factors.
-
Page 5: Introduction
Introduction - Series I Rotary Cutter Introduction The Farm King Series 1 Rotary cutter available in 48" and 60" and is equipped with a 3-point hitch. The 3-point hitch is Farm King Quick Hitch compatible so it is easy to attach and unhook. 3-point hitch models include a single solid rubber training wheel. -
Page 6: Safety
Safety - Series I Rotary Cutter Safety Safety Instructions Remember, YOU are the key to safety. Good safety practices not only protect you, but also the people around you. Make these practices a working part of your safety program. Be certain that everyone operating this equipment is familiar with the recommended operating and maintenance procedures and follows all the safety precautions. -
Page 7: General Safety
• Read and understand the Operator’s Manual and all safety signs before operating, servicing, adjusting, repairing, or unplugging the equipment. • Do not attempt any unauthorized modifications to your Farm King product as this could affect function or safety, and could affect the life of the equipment. -
Page 8: Service And Maintenance Safety
Safety - Series I Rotary Cutter • Never have the equipment in operation during transport. • Always travel at a safe speed. Service and Maintenance Safety • Stop engine, set brake, remove ignition key, and wait for all moving parts to stop before servicing, adjusting, repairing, or unplugging. - Page 9 Safety - Series I Rotary Cutter...
-
Page 10: Assembly
Assembly - Series I Rotary Cutter Assembly Instructions Raise the hitch arms (#1) and the hitch supports (#4) from the deck. Remove the bolt holding on the top link (#12). Line up the end holes on the hitch supports with the holes on the outside of the hitch arms where you just removed the bolt. -
Page 11: Operation
Operation - Series I Rotary Cutter Operation Instructions Connecting to Tractor: All cutters are supplied with a standard 1-3/8" (35 mm) 6-spline yoke on the PTO shaft. This cutter is designed to operate only with a 540 rpm PTO. After connecting cutter to tractor and before doing any cutting, check WARNING to see that the PTO shaft is not touching anywhere on the cutter... -
Page 12: Theory Of Operation
Operation - Series I Rotary Cutter Theory of Operation... -
Page 13: Maintenance
Maintenance - Series I Rotary Cutter Maintenance Service Gearbox: The gearbox should be filled with SAE90 oil to the bottom edge of the lower oil plug when shipped. Check this before using the cutter and at regular intervals to see that this oil level is maintained. -
Page 14: Bolt Torque
Bolt Torque - Series I Rotary Cutter Bolt Torque Checking Bolt Torque The tables shown below give correct torque values for various bolts and hex bolts. Tighten all bolts to the torques specified in chart unless otherwise noted. Check tightness of bolts periodically, using bolt torque chart as a guide. -
Page 16: Part Drawings
Parts - Series I Rotary Cutter 4' and 5' Drawing... -
Page 17: 4' And 5' Parts List
Parts - Series I Rotary Cutter When Ordering Parts Always give your dealer the Model, Color and Serial Number of your machine to assist him in ordering and obtaining the correct parts. Use the exploded view and tabular listing of the area of interest to exactly identify the required part. - Page 18 1" Slotted Hex Nut - 4' 967217 1" Slotted Hex Nut - 5' 815061 410 Rotary Cutter Decal 815065 Farm King Rotary Cutter Decal 909767 Wheel Yoke 909768 M24 x 2 x 186 Spindle Bolt 909769 M24 x 2 Spindle Nut...
-
Page 20: Chain Kit Drawing
Parts - Series I Rotary Cutter Chain Kit Drawing... -
Page 21: Chain Kit Parts List
Parts - Series I Rotary Cutter Item Part Number Description 9812430 Cotter Pin 0.125 x 1.00 (Pl) 966596 Chain, 5 Link 5&6 Rc 116888 Front/Rear Center Chain Rod, 4'Rc 116795 Front/Rear Center Chain Rod, 5'Rc 116889 Rear Chain Rod, Sides, 4'Rc 116793 Rear Chain Rod, Sides, 5'Rc 117021... -
Page 22: Pto Shaft Drawing
Parts - Series I Rotary Cutter PTO Shaft Drawing... -
Page 23: Pto Shaft Parts List
Parts - Series I Rotary Cutter Item Part Number Description F0879 Shaft Complete 907186 Quick Disconnect Yoke (6 Spline) 540rpm 966211 Repair Kit 936344 Outer Tube w/ Yoke 936345 Inner Tube w/ Yoke 966216 Shear Yoke 909766 Shield Kit 9812034 Shear Bolt 1/2"... -
Page 24: Gearbox Drawing - 410
Parts - Series I Rotary Cutter Gearbox Drawing - 410... -
Page 25: Gearbox Parts List - 410
Parts - Series I Rotary Cutter Item Part Number Description 814425 Gearbox Assembly 909785 Cotter Pin 5 x 45 909786 Blade Nut 909787 Washer - Blade Hub 909788 Blade Hub 909789 Shaft - Output 909790 Oil Seal 1.56 x 2.215 x 0.375 909791 Bolt - Output Cap 909792... -
Page 26: Gearbox Drawing - 510
Parts - Series I Rotary Cutter Gearbox Drawing - 510... -
Page 27: Gearbox Parts List - 510
Parts - Series I Rotary Cutter Item Part Number Description 966108 Gearbox Assembly 914018 Housing 914006 Cap - Input 914015 Cap - Output 904022 Gear - Output, w/ Shaft 15T 904021 Gear - Input 22T 966824 Shaft - Input 1-3/8" 966542 Bearing - Ball 207K 966555... - Page 28 Shipping Kit and Bundle Numbers - Series I Rotary Cutter Shipping Kit and Bundle Numbers The following is a list of Kit Numbers for this product and the Bundle Numbers, Descriptions, and Quantities for each Kit. Quantity Bundle Number Description Y410LS - Model 410 Series 1 Rotary Cutter (3-point) F0870 Deck Assembly...
- Page 30 Repair Parts Limited Warranty Buhler Industries Inc. warrants Farm King replacement parts purchased after the expiration of the Buhler Industries Inc. Limited Warranty, and used and serviced as provided for in the Operator’s Manual, to be free from defects in materials or workmanship for a period of thirty (30) days from the invoice date for the parts.
- Page 31 Warranty Requirements To be covered by warranty, each Farm King new product must be registered with Buhler Industries Inc. within thirty (30) days of delivery to original retail purchaser. If the customer decides to purchase replacement components before the warranty disposition of such components is determined, Buhler Industries Inc.
- Page 32 Warranty - Series I Rotary Cutter (Note that some provinces or states do not allow limitations on how long an implied warranty lasts or the exclusion or limitation of incidental or consequential damages, so the above limitations and exclusion may not apply to you.) This warranty gives you specific legal rights and you may also have other rights, which vary from province to province or state to state.
