- Page 1 OPERATOR AND PARTS MANUAL Rotary Cutter Series II - 5' & 6' 052013 FK379...
-
Page 3: Table Of Contents
Table of Contents - Series II Rotary Cutter Table of Contents Introduction ..........................5 Safety ............................6 • Safety Instruction ......................6 • General Safety ........................7 • Start-up Safety .........................7 • Operation Safety ......................7 • Transport Safety .......................7 • Service and Maintenance Safety ..................8 •... - Page 4 Table of Contents - Series II Rotary Cutter • 510 Gearbox Drawing ....................34 • 510 Gearbox Parts List ....................35 • 620 Gearbox Drawing ....................36 • 620 Gearbox Parts List ....................37 • Cylinder Drawing and Parts List ...................38 Shipping Kit and Bundle Numbers ..................39 •...
-
Page 5: Introduction
Introduction The Farm King Series II Rotary Cutter is available in widths of 60", 72" and 84" and can be equipped with either trailing style or 3-point hitch. The 3-point hitch is Quick Hitch compatible so it is easy to attach and unhook. -
Page 6: Safety
Safety - Series II Rotary Cutter Safety Safety Instructions Remember, YOU are the key to safety. Good safety practices not only protect you, but also the people around you. Make these practices a working part of your safety program. Be certain that everyone operating this equipment is familiar with the recommended operating and maintenance procedures and follows all the safety precautions. -
Page 7: General Safety
• Read and understand the Operator’s Manual and all safety signs before operating, servicing, adjusting, repairing, or unplugging the equipment. • Do not attempt any unauthorized modifications to your Farm King product as this could affect function or safety, and could affect the life of the equipment. -
Page 8: Service And Maintenance Safety
Safety - Series II Rotary Cutter • Never have the equipment in operation during transport. • Always travel at a safe speed. Service and Maintenance Safety • Stop engine, set brake, remove ignition key, and wait for all moving parts to stop before servicing, adjusting, repairing, or unplugging. - Page 9 Safety - Series II Rotary Cutter...
-
Page 10: Assembly
Assembly - Series II Rotary Cutter Assembly Instructions 3-Point Hitch Mounted Assembly Instructions Mount the hitch assembly (906389/906390) to the deck using the category 1 lift arm pins (965809/965926) supplied. The bushings (906416/906418) and the 1" I.D. washer (967140 & 907309) should allow the hitch to swivel freely. -
Page 11: Chain Kit Assembly Instructions
Assembly - Series II Rotary Cutter 4. Bolt the welded end of the level control rod (966526/906122) to the front tongue as shown on drawing using a 5/8" x 2-1/2" hex bolt and lock nut. The control rod clevis (966525/902341) must be adjusted so the cutter will sit level with the ground when it is pinned to the swivel assembly. -
Page 12: Operation
Operation - Series II Rotary Cutter Operation Instructions Connecting to Tractor: All cutters are supplied with a standard 1-3/8" 6-spline yoke on the PTO shaft. This cutter is designed to operate only with a 540 rpm PTO. After connecting cutter to tractor and before doing any cutting, check WARNING to see that the PTO shaft is not touching anywhere on the cutter when raising and lowering or when cornering. - Page 13 Operation - Series II Rotary Cutter 4. Cutting: The cutter should be run with the front end a little low or just level for normal light cutting. For brush or dense tall weeds, running front end high may give a better shredding job.
-
Page 14: Theory Of Operations
Operation - Series II Rotary Cutter Theory of Operations... -
Page 15: Maintenance
Maintenance - Series II Rotary Cutter Maintenance Service Gearbox: The gearbox should be filled with SAE90 oil to the bottom edge of the lower oil plug when shipped. Check this before using the cutter and at regular intervals to see that this oil level is maintained. -
Page 16: Bolt Torque
Bolt Torque - Series II Rotary Cutter Bolt Torque Checking Bolt Torque The tables shown below give correct torque values for various bolts and hex bolts. Tighten all bolts to the torques specified in chart unless otherwise noted. Check tightness of bolts periodically, using bolt torque chart as a guide. -
Page 18: Part Drawings
Parts - Series II Rotary Cutter 3-Point Hitch Mounted Drawing... -
Page 19: Trailing Drawing
Parts - Series II Rotary Cutter Trailing Drawing... -
Page 20: Parts List
Parts - Series II Rotary Cutter When Ordering Parts Always give your dealer the Model, Color and Serial Number of your machine to assist him in ordering and obtaining the correct parts. Use the exploded view and tabular listing of the area of interest to exactly identify the required part. - Page 21 Parts - Series II Rotary Cutter Item Part Number Description 909703 Safety Chain - All 909767 Wheel Yoke Rc 909768 Spindle Bolt Seri Rc 909769 Slotted Hex Nut 909770 Cotter Pin 0.250 x 2.00 Znpl 909771 15" Solid Wheel & Rim 909772 Hub w/ Bush Rc 909773...
- Page 22 Parts - Series II Rotary Cutter Item Part Number Description 12779 Hairpin Clip #9 24791M Cyl 3.0 Diam x 8.00 84335 Bolt Hex 5/8" x 2-1/2" Unc 87553 Bolt Hex 0.500Nc x 1.75 Gr5 Pl 966528 Bushing Hitch 5' Rc 906418 Bushing Hitch 6' Rc 960327...
- Page 23 Parts - Series II Rotary Cutter...
-
Page 24: Chain Kit Drawing (Optional)
Parts - Series II Rotary Cutter Chain Kit Drawing (Optional) -
Page 25: Chain Kit Parts List (Optional)
Parts - Series II Rotary Cutter Item Part Number Description 966586 Front Chain Holder, 5' - (60" Long) 966147 Front Chain Holder, 6' - (72" Long) 966587 Front Chain Rod, 5' - (3/8" x 30-1/2") 966148 Front Chain Rod, 6' - (3/8" x 36-3/8") 966588 Rear Center Chain Holder, 5' - (29"... -
Page 26: 510 Pto Shaft Drawing
Parts - Series II Rotary Cutter Model 510 PTO Shaft Drawing... -
Page 27: 510 (Shear Pin) Trailing Parts List
Parts - Series II Rotary Cutter Item Part Number Description Model 510 - (Shear Pin) Trailing Parts List F0439 Shaft Complete 907286 Tractor Half 907287 Implement Half 936347 Outer Cardan Tube 936349 Inner Cardan Tube 966248 Outer Shield Tube 966249 Inner Shield Tube 966207 Outer Shield Cone... -
Page 28: 510 (Shear Pin) 3-Point Hitch Parts List
Parts - Series II Rotary Cutter Item Part Number Description Model 510 - (Shear Pin) 3-Point Hitch Parts List F0438 Shaft Complete 907292 Tractor Half 907293 Implement Half 936346 Outer Cardan Tube 936348 Inner Cardan Tube 966205 Outer Shield Tube 966206 Inner Shield Tube 966207... -
Page 30: 620 & 720 Pto Shaft Drawing
Parts - Series II Rotary Cutter Models 620 PTO Shaft Drawing... -
Page 31: 620 (Slip Clutch) 3-Point Hitch Parts List
Parts - Series II Rotary Cutter Item Part Number Description Model 620 - (Slip Clutch) 3-Point Hitch Parts List F0440 Shaft Complete 907295 Tractor Half 907296 Implement Half 936354 Outer Cardan Tube 936356 Inner Cardan Tube 966230 Outer Shield Tube 966231 Inner Shield Tube 966232... -
Page 32: 620 (Slip Clutch) Trailing Parts List
Parts - Series II Rotary Cutter Item Part Number Description Model 620 - (Slip Clutch) Trailing Parts List F0441 Shaft Complete 907297 Tractor Half 907298 Implement Half 936355 Outer Cardan Tube 936357 Inner Cardan Tube 966256 Outer Shield Tube 966257 Inner Shield Tube 966232 Outer Shield Cone... -
Page 34: 510 Gearbox Drawing
Parts - Series II Rotary Cutter Model 510 Gearbox Drawing... -
Page 35: 510 Gearbox Parts List
Parts - Series II Rotary Cutter Item Part Number Description 966108 Gearbox Assembly 914018 Housing 914006 Cap - Input 914015 Cap - Output 904022 Gear - Output, w/Shaft 15T 904021 Gear - Input 22T 966824 Shaft - Input 1-3/8" 966542 Bearing - Ball 207K 966555 Bearing - Ball 208K... -
Page 36: 620 Gearbox Drawing
Parts - Series II Rotary Cutter Model 620 Gearbox Drawing... -
Page 37: 620 Gearbox Parts List
Parts - Series II Rotary Cutter Item Part Number Description 966109 Gearbox Assembly 966825 Housing 966830 Output Shaft 966832 Bearing Cone 368 966835 Bearing Cup 362 966828 Output Gear 13T 966831 Input Shaft 966833 Bearing Cone LM603049 966834 Bearing Cup LM603014 966846 Retaining Ring 966829... -
Page 38: Cylinder Drawing And Parts List
Parts - Series II Rotary Cutter 3 x 8 Cylinder Drawing Item Part Number Description 24791M Cylinder Complete X3914 Seal Kit... -
Page 39: Shipping Kit And Bundle Numbers
Shipping Kit and Bundle Numbers - Series II Rotary Cutter Shipping Kit and Bundle Numbers The following is a list of Kit Numbers for this product and the Bundle Numbers, Descriptions, and Quantities for each Kit. Quantity Bundle Number Description 510 Rotary Cutter - 3-Point Hitch (Y510S) F1527 Deck Assembly w/ Shear Pin... -
Page 40: Optional Bundle Numbers
Shipping Kit and Bundle Numbers - Series II Rotary Cutter Optional Bundle Numbers The following is a list of options available for the Kits listed above. Quantity Bundle Number Description F9415 Jack c/w Mounting Plate F630 Hydraulic Cylinder & Hose Kit Y514 510 3-Point Hitch Kit Y625... -
Page 42: Warranty
Repair Parts Limited Warranty Buhler Industries Inc. warrants Farm King replacement parts purchased after the expiration of the Buhler Industries Inc. Limited Warranty, and used and serviced as provided for in the Operator’s Manual, to be free from defects in materials or workmanship for a period of thirty (30) days from the invoice date for the parts. - Page 43 Warranty Requirements To be covered by warranty, each Farm King new product must be registered with Buhler Industries Inc. within thirty (30) days of delivery to original retail purchaser. If the customer decides to purchase replacement components before the warranty disposition of such components is determined, Buhler Industries Inc.
- Page 44 Warranty - Series II Rotary Cutter (Note that some provinces or states do not allow limitations on how long an implied warranty lasts or the exclusion or limitation of incidental or consequential damages, so the above limitations and exclusion may not apply to you.) This warranty gives you specific legal rights and you may also have other rights, which vary from province to province or state to state.
- Page 46 www.farm-king.com 1330 43rd Street NW Fargo, ND USA 58102 Ph.: 701.282.7014 | Fax: 701.282.5865 Toll Free: 888.524.1004 E-mail: info@buhler.com www.farm-king.com Equipment shown is subject to change without notice. ©2012 Buhler Trading Inc. Printed in USA. TSX:BUI a division of Buhler Industries Inc.
