- Page 1 Mounting and User Instructions Lotus-Liva Lotus Liva 5, Liva 5G, Liva 6, Liva 6G, Liva 7G, Liva 8G Version 2 02/08-2016...
-
Page 3: Mounting Of Stove
Introduction Congratulations on your new Lotus Wood Stove We sincerely trust that your Lotus Wood Stove will bring many happy hours for you. However, to benefit fully from your investment, you should read these instructions thoroughly. They contain some specific advice on how to benefit fully from your stove –... - Page 4 Technical Specifications Model Height Width Depth Weight 100,2 cm 51 cm 41 cm 121 kg Liva 5 Liva 5 G 100,2 cm 51 cm 41 cm 122 kg Liva 5 102,2 cm 51 cm 41 cm 175 kg Natural stone...
- Page 5 Safety distance as shown on the drawing: (Liva 5G-6G) B = 150 mm C = 300 mm Distance in front = 800 mm Safety distance as shown on the drawing: (Liva 7G) B = 500 mm C = 800 mm Distance in front = 800 mm Fire protection outside the heat radiation area.
- Page 6 Distance to flammable materials and furniture For combustible materials and furniture is the minimum distance of 20 cm to obtain sufficient thermal protection. Fire protection within the radiation range Within the radiation area must be no flammable material or furniture. The distance may be reduced to 40 cm by placing a fan-jet plate between the apparatus and the combustible objects.
- Page 7 Mean Values at testing to DS/EN 13240: Flue Gas Temperature: 330 C Flue Gas Mass Flow: 4, 6 g/s Rate of Efficiency: Rated Output: 5 Kw Flue: 12 pa Chimney A good draught in your chimney is paramount to how well a stove will burn. Note that there should be access to cleaning doors.
- Page 8 Floor When placing your new Lotus stove on the floor, it should be put on a non- combustible plate, for instance of steel or stone material. The plate should be so large that it will reach a minimum of 30 cm in front of the stove, and 15 cm at each side of the fireplace opening.
-
Page 9: Use Of Stove
and the chimney should also be cleaned by the chimney sweep in the time ahead. Use of Stove Below, the procedure applied at the stove testing at the EN Test. This is the procedure generating optimal combustion on the particular chimney. -
Page 10: Sound Advice
Cleaning of Stove All Lotus stoves have been factory surface treated with original Senotherm lacquer in”coke” or”grey” colour. Due to this treatment, the stove will, during the first kindlings, exude a special odour but that will vanish after a few times. -
Page 11: Stove Maintenance - Use Original Spare Parts Only
Chimney Fire In case of a chimney fire, doors and register should be shut so as to cut off the oxygen supply. Relevant authorities etc. may be called if necessary. Stove Maintenance – use original spare parts only Packings may seem to look nice; they will, however, collapse in the heat, thereby losing their ability to keep your stove tight. -
Page 12: Operating Trouble
Exemption of the Liva for use in a smoke control area applies when burning untreated wood only. Wood for your Lotus stove should have a diameter of 7-9 cm and be max. appr. 30 cm long as it will otherwise come too close to the stove sides (at the DS testing 25 cm long wood has been used). - Page 13 Depending on the type of problem you may have to contact your Lotus distributor or a chimney sweep.
-
Page 15: Warranty
WARRANTY Lotus Wood Stove – 10-Year Warranty From 1 September 2014, Lotus is offering a 10-year warranty instead of a five-year warranty. This warranty applies to stoves which are supplied by Lotus after this date. This warranty covers Lotus Wood Stove model _________ production no.
