Summary of Contents for Costway JV10469
- Page 1 USER’S MANUAL Buffet Cabinet JV10469 THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
-
Page 2: Before You Start
Before You Start Please read all instructions carefully. Retain instructions for future reference. Separate and count all parts and hardware. Read through each step carefully and follow the proper order. We recommend that, where possible, all items are assembled near to the area in which they will be placed in use, to avoid moving the product unnecessarily once assembled. - Page 4 PACKAGE CONTENT (A) CODE DESCRIPTION Cabinet panel Panel Bottom Panel Left side panel Right side panel Left middle side plate Right middle side plate Movable Shelf Backboard Front cross rail Vertical partition Diaphragm Door plank 01 Door plank 02 Upper side plate Bottom Apron Bottom Side Apron...
- Page 5 Ø8x30mm Ø15 36X+1X 36X+1X 22X+1X Ø5/32"×19mm Ø3.5x16mm 29X+1X 32*19*19mm Ø3.9×15mm Silvery 24X+1X 2X+4X 2X+2X Ø1/4"×30mm Ø3.9×15mm Ø3.9x50 10X+1X...
- Page 8 Adjust the foot pads for added stability when the product is placed on uneven floor.
- Page 14 Each part C matches with one part J.
- Page 16 In order to ensure the same distance between the top and bottom of the door seam, you should first install the lower door hinges of the door panel, and then install the upper part. Adjust the distance between the front and rear of the cabinet door here.
- Page 18 Replacements for missing or damaged parts will be shipped ASAP ! US office: Fontana UK office: Ipswich AU office: Truganina DE office: Hamburg FR office: Saint Vigor d'Ymonville PL office: Gdańsk Contact Us! Do NOT return this item. US:cs.us@costway.com UK:cs.uk@costway.com AU:cs.au@costway.com...
