- Page 1 USER’S MANUAL Barstools JV10439 THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
-
Page 2: Before You Start
Before You Start Read each step carefully before starting. It is very important to ensure each step followed in correct order, otherwise assembly difficulties may occur. Most of board parts are labeled or stamped on the raw edges. Have a check to make sure all parts are included. Work in a spacious area, preferably on a carpet close to where the unit will be used. -
Page 3: Part List
PART LIST 1. Back Rest x 2pcs 2. Seat x 2pcs 3. Seat Frame x 2pcs 4. Swivel Plate x 2pcs 5. Leg(Front-Right/ Rear-Left) 6. Leg(Front-Left/ Rear-Right) x 4pcs x 4pcs 7. Crossbar x 8pcs... -
Page 4: Hardware List
HARDWARE LIST Allen Key 1 pcs Screw 16 pcs LONG Spring Washer 16 pcs SMALL Flat Washer 16 pcs SMALL Screw 8 pcs SHORT Screw 24 pcs Spring Washer 4 pcs Flat Washer 4 pcs Hexagon Nut 4 pcs Spanner 1 pcs... - Page 5 Step 1...
- Page 6 Step 2...
- Page 7 Step 3...
- Page 8 Step 4...
- Page 9 Step 5 Rotate the upper swivel plate before using screws for the bottom swivel plate.
- Page 10 Step 6...
-
Page 11: Care And Maintenance
Care and Maintenance Use a soft, clean cloth that will not scratch the surface when dusting. Use of furniture polish is not necessary. Should you choose to use polish, test first in an inconspicuous area. Using solvents of any kind on your furniture may damage the finish. Never use water to clean your furniture as it may cause damage to the finish. - Page 12 Contact our friendly customer service department for help first. Replacements for missing or damaged parts will be shipped ASAP ! US office: Fontana UK office: Ipswich AU office: Truganina Contact Us ! Do NOT return this item. US:cs.us@costway.com UK:cs.uk@costway.com AU:cs.au@costway.com...
