SKYRAIDER DS10
[Version 3.4]
Michael Burns
Rock Mallin
Revision History
[
SkyRaider DS10 User Manual
This document will quickly introduce you to the wonders of the MallinCam SkyRaider
DS10 Camera. It will include instructions on how to install the Software and Drivers and
how connect the SkyRaider to your computer along with explanations of the
camera's major settings. The purpose of this guide is to quickly get you up and
running with the SkyRaider Camera so that you can image.
SkyRaider DS10 User Manual
Revision Sheet
]
Page i
