PRODUCT MANUAL
PNEUMATIC ASSIST ARM
for TC24 Tire Changer
MODEL:TMG-PAT24
Please read the product manual completely before assembly
Check against the parts list to make sure all parts are received
Wear proper safety goggles or other protective gears while in assembly
Missing parts or questions on assembly?
Please call: 1-877-761-2819 or email: cs@tmgindustrial.com
Do not return the product to dealer, they are not equipped to handle your
requests
WWW.TMGINDUSTRIAL.COM
Toll Free:1-877-761-2819
Advertisement
Related Manuals for TMG TMG-PAT24
Summary of Contents for TMG TMG-PAT24
- Page 1 PRODUCT MANUAL PNEUMATIC ASSIST ARM for TC24 Tire Changer MODEL:TMG-PAT24 Please read the product manual completely before assembly Check against the parts list to make sure all parts are received Wear proper safety goggles or other protective gears while in assembly Missing parts or questions on assembly? Please call: 1-877-761-2819 or email: cs@tmgindustrial.com...
- Page 2 Installation Instructions Step1: Open the side plate. Step2: ①Cut the air pipe 1 above the bead breaker cylinder. ②Connect air pipe 1 and air pipe 3 with a tee-junction. ③Put the air pipe 3 through the hole at the back of box. ④At the back of box, connect the air pipe 3 with a straight joint.
- Page 3 Explosion diagram WW W . T M G I N D U S T RI A L . C O M P3 / 4 T o l l F r e e :1 - 8 7 7 - 7 6 1 - 2 8 1 9...
- Page 4 PART# PART# DESCRIPTION DESCRIPTION cylinder 80 assembly lifting valve assembly right angle terminal of quick right angle terminal of quick insert insert φ8 G1/8” φ6 G1/8” hand lifting valve o-ring seal φ20X2.65 hexagon nut M6 metal silencer spring washer 6 handle on the table holding the tire of the side column cylinder head of the side...
