Mercusys MS108GS Installation Manual

Installation Guide
Desktop Switch
* MS108 is used for demonstration in this guide.
Images may differ from actual product.
© 2023 MERCUSYS 7107500274 REV1.0.2
Connection Diagram
Connect the hardware according to the connection diagram.
Ethernet Ports
8 7 6
Router
WAN Port LAN Port
Internet
FAQ (Frequently Asked Questions)
Q1. What should I do if the Power LED is off ?
A1: Make sure the power adapter is connected to the switch
with power source properly.
A2: Make sure the voltage of the power supply meets the
requirements of the input voltage of the switch.
A3: Make sure the power source is ON.
Q2. What should I do if the Ethernet LED is off when a device
is connected to the corresponding port?
A1: Make sure that the cable connectors are firmly plugged
into the switch and the device.
A2: Make sure the connected device is turned on and working
properly.
A3: The cable must be less than 100 meters long (328 feet).
Switch
Power Adapter
5 4 3 2 1
PC
LED Explanation
Power
On: The power is on.
Off: The power is off.
8 7 6 5 4 3 2 1
Ethernet Ports
On: The port is connected.
Blinking: The port is sending or receiving
data.
Off: The port is not connected.
Español (Latinoamérica)
Conecte el equipo de acuerdo con el diagrama de conexión.
Explicación del LED
Encendido: La alimentación está encendida.
Alimentación
Apagado: La alimentación está desconectada.
Encendido: El puerto está conectado.
Parpadeo: El puerto está enviando o
Puertos Ethernet
recibiendo datos.
Apagado: El puerto no está conectado.
Français
Connectez le matériel conformément au schéma de connexion.
Explication de la LED
On: le courant est allumé.
Alimentation
Off: l'alimentation est éteinte.
On: le port est connecté.
Clignotant: le port envoie ou reçoit des
Ports Ethernet
données.
Off: le port n'est pas connecté.
Türkçe
Donanımı bağlantı şemasına göre bağlayın.
LED Açıklaması
Açık: Güç açıktır.
Güç
Kapalı: Güç kapalı.
Açık: Port bağlı.
Ethernet Portları Yanıp sönüyor: Port veri gönderiyor veya alıyor.
Kapalı: Bağlantı noktası bağlı değil.
