EVERGEN M SERIES
1710 EVERGEN EMS RETROFIT INSTALLATION GUIDE
Document: 88136_INSTALL_1710_EMS-replacement-RevB
Sol by Sunna Design | 990 Biscayne Boulevard, Office 701, Miami, FL 33132, USA | 1.800.959.1329 | customerservice@solarlighting.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Sol EVERGEN M Series and is the answer not in the manual?

Questions and answers

Related Manuals for Sunna Design Sol EVERGEN M Series

Summary of Contents for Sunna Design Sol EVERGEN M Series

  • Page 1 EVERGEN M SERIES 1710 EVERGEN EMS RETROFIT INSTALLATION GUIDE Document: 88136_INSTALL_1710_EMS-replacement-RevB Sol by Sunna Design | 990 Biscayne Boulevard, Office 701, Miami, FL 33132, USA | 1.800.959.1329 | customerservice@solarlighting.com...
  • Page 2 To ensure proper operation of this equipment, it is important that the equipment be used for its intended purpose. Any use of this equipment for purposes other than those intended will void all warranties. Sol by Sunna Design | 990 Biscayne Boulevard, Office 701, Miami, FL 33132, USA | 1.800.959.1329 | customerservice@solarlighting.com...

  • Page 3: Warnings And Precautions

    Changes or modifications to Sol N N OTE equipment not expressly approved by Sol could void the user's authority to operate the equipment. Sol by Sunna Design | 990 Biscayne Boulevard, Office 701, Miami, FL 33132, USA | 1.800.959.1329 | customerservice@solarlighting.com...

  • Page 4: Tools And Equipment

    9/32" drill bit d. 2" hole saw e. Cordless drill Wire cutters/strippers g. Adjustable wrench h. Deburring tool or sharp knife Sol by Sunna Design | 990 Biscayne Boulevard, Office 701, Miami, FL 33132, USA | 1.800.959.1329 | customerservice@solarlighting.com...

  • Page 5: Installation

    Remove 1710 door by loosening screw and lifting door off chassis. The door is heavy. Be careful not to drop it. W W A A RNI RNIN N G G Sol by Sunna Design | 990 Biscayne Boulevard, Office 701, Miami, FL 33132, USA | 1.800.959.1329 | customerservice@solarlighting.com...
  • Page 6 Unplug battery harness connectors in locations shown. Also, unplug battery temperature sensor connector. Undo latch on battery strap and remove battery. Repeat for other battery. Sol by Sunna Design | 990 Biscayne Boulevard, Office 701, Miami, FL 33132, USA | 1.800.959.1329 | customerservice@solarlighting.com...
  • Page 7 Locate and disconnect the MC4 connector on the solar panel negative cable. Push the latches together and pull connectors apart. To solar switch & To solar panel (-) 1710 EMS Sol by Sunna Design | 990 Biscayne Boulevard, Office 701, Miami, FL 33132, USA | 1.800.959.1329 | customerservice@solarlighting.com...
  • Page 8 Center EMS adapter bracket on back of 1710 chassis in the location shown. Orient as shown and mark centers of 3 holes shown. Sol by Sunna Design | 990 Biscayne Boulevard, Office 701, Miami, FL 33132, USA | 1.800.959.1329 | customerservice@solarlighting.com...
  • Page 9 Drill third mark through with 2" hole saw. Use a round file to remove any burrs and sharp edges from the 2" hole. C C AUTION AUTION Sol by Sunna Design | 990 Biscayne Boulevard, Office 701, Miami, FL 33132, USA | 1.800.959.1329 | customerservice@solarlighting.com...
  • Page 10 Mount EMS to adapter plate using 1/2" standoffs provided in hardware kit and bolts on EMS. Insert foam gasket around EMS harnessing. Sol by Sunna Design | 990 Biscayne Boulevard, Office 701, Miami, FL 33132, USA | 1.800.959.1329 | customerservice@solarlighting.com...
  • Page 11 Insert EMS harnessing into 2" hole in 1710 chassis from outside. Hold EMS assembly against back of 1710 chassis while inserting stainless steel bolt and lock washer through left hole inside 1710 chassis and into EMS assembly standoff. Sol by Sunna Design | 990 Biscayne Boulevard, Office 701, Miami, FL 33132, USA | 1.800.959.1329 | customerservice@solarlighting.com...
  • Page 12 The star washer ensures good ground contact. Thread bolt through right hole in the back of 1710 chassis and into EMS standoff. Star washer Flat washer EMS ground harness Ground extension harness Bolt Sol by Sunna Design | 990 Biscayne Boulevard, Office 701, Miami, FL 33132, USA | 1.800.959.1329 | customerservice@solarlighting.com...
  • Page 13 There are 2-wire (for single fixture) and 4-wire (for dual fixture) versions of the harness. To LED fixture(s) Cut the two or four wires of the fixture cable as close as possible to the 4-position connector. Sol by Sunna Design | 990 Biscayne Boulevard, Office 701, Miami, FL 33132, USA | 1.800.959.1329 | customerservice@solarlighting.com...
  • Page 14 Twist negative (black) wire of fixture adapter together with black wire(s) from fixture cable. Trim to 0.5", insert into wire nut and twist together firmly. Repeat steps 21-23 with positive (red) fixture and adapter cable wires. Sol by Sunna Design | 990 Biscayne Boulevard, Office 701, Miami, FL 33132, USA | 1.800.959.1329 | customerservice@solarlighting.com...
  • Page 15 Trim to 0.5" and twist together firmly with wire nut. Cable tie solar positive cable so that wires entering wire nuts isn't being pulled. Sol by Sunna Design | 990 Biscayne Boulevard, Office 701, Miami, FL 33132, USA | 1.800.959.1329 | customerservice@solarlighting.com...
  • Page 16 (black wire) Locate battery harness kit, shown below, and follow battery harness installation steps on following page. Main battery harness Battery 2 harness Sol by Sunna Design | 990 Biscayne Boulevard, Office 701, Miami, FL 33132, USA | 1.800.959.1329 | customerservice@solarlighting.com...

  • Page 17: Risk Of Electric Shock

    ± .0005 THIRD ANGLE PROJECTION ORIGINALLY DESIGNED BY DATE SIZE DRAWING NO REVISION Sol by Sunna Design | 990 Biscayne Boulevard, Office 701, Miami, FL 33132, USA | 1.800.959.1329 | customerservice@solarlighting.com 82064-1 Ben Jolie 05/29/2017 ORIGINALLY DRAWN BY DATE Ben Jolie...
  • Page 18 Main battery harness Fuses Battery 2 harness Protective cap Insert a fuse into the fuseholder and install the protective cap onto the fuseholder. Sol by Sunna Design | 990 Biscayne Boulevard, Office 701, Miami, FL 33132, USA | 1.800.959.1329 | customerservice@solarlighting.com...
  • Page 19 Use the EverGen Setup App on your mobile device to commission the system so the lights will operate at the prescribed settings. Sol by Sunna Design | 990 Biscayne Boulevard, Office 701, Miami, FL 33132, USA | 1.800.959.1329 | customerservice@solarlighting.com...
  • Page 20 The EverGen will then run an internal diagnostics test, then power the light for one minute. Repeat this commission process for each EverGen EMS in the project. Sol by Sunna Design | 990 Biscayne Boulevard, Office 701, Miami, FL 33132, USA | 1.800.959.1329 | customerservice@solarlighting.com...

  • Page 21: Warranty

    990 Biscayne Boulevard, Office 701, Miami, FL 33132, USA Phone: 1.772.286.9461 1.800.959.1329 (Toll Free in U.S. and Canada) Email: customerservice@solarlighting.com Website: solarlighting.com Document: 88136_INSTALL_1710_EMS-replacement-RevB Sol by Sunna Design | 990 Biscayne Boulevard, Office 701, Miami, FL 33132, USA | 1.800.959.1329 | customerservice@solarlighting.com...
