Panasonic EXC14CX Quick Start Manual

Common Mode Noise Filters
EXC14CX type

Features

● Small and thin (L 0.85 mm×W 0.65 mm×H 0.45 mm)
● Effective noise suppression of smartphones by eliminating common mode noises and removing differential
signal components
● Strong multilayer/sintered structure, excellent reflow resistance and high mounting reliability
● RoHS compliant

Recommended applications

● Smartphones, Tablet PCs and DSC
● Noise suppression of high-speed differential data lines such as MIPI, USB and LVDS

Explanation of part numbers

1 2
E X C
Product code Code Dimensions (mm)
Noise filter
0.85×0.65×.045
1
(L)×(W)×(H)

Construction

Inner conductor

Dimensions in mm (not to scale)

Part No.
(inch size)
EXC14CX (0302) 0.65 ± 0.05
Design and specifications are each subject to change without notice. Ask factory for the current technical specifications before purchase and/or use.
Should a safety concern arise regarding this product, please be sure to contact us immediately.
3 4 5
1 4
Number of
terminals
4 Terminals
Ferrite
Electrode
C
A B
0.85 ± 0.05 0.45 ± 0.05
6 7 8
C X 9
Code Type Code
Characteristics
Both common
Coupled
C
mode and
type
differential
X
mode noise
suppression
type

Circuit configuration (No polarity)

4
1
※ The pin numbers shown here are for reference purposes only.
F
E
D
A
B
Dimensions
C D
0.10 min.
9 10 11
0 0 U
Code
Nominal impedance
The first two digits are
U
significant figure of
impedance value, and
the third one denotes
the number of zeros
following.
3 4
2 1
E F
0.50 ± 0.10 0.27 ± 0.10
12
Suffix
Packing form
Embossed carrier
taping
2 mm pitch,
10,000 pcs
3
2
Unit : mm
Mass (Weight)
(mg/ pc.)
1.4
20-Jan-23
