Operation & Installation Instructions
LB4 Series
NSF/ANSI Standard 55 Class A
System Tested and Certified by
NSF International against CSA
B483.1 and NSF/ANSI 55
for Disinfection
Performance, Class A
**
C
US
System
Rated Flow
System
LB6-02XA
1.6 gpm
LBH6-05XA
LB6-03XA
2.2 gpm
LBH6-10XA
LB6-06XA
3.4 gpm
LBH6-15XA
LB6-10XA
6.3 gpm
LBH6-25XA
LB6-15XA
7.9 gpm
LBH6-40XA
illuminating technologies for life
LBH4 Series
NSF/ANSI Standard 55 Class B
C
US
Rated Flow
System
Rated Flow
LB5-02XB
2.2 gpm
2.9 gpm
LB6-02XB
4.1 gpm
LB5-03XB
5.2 gpm
LB6-03XB
5.4 gpm
LB5-06XB
7.9 gpm
7.6 gpm
LB6-06XB
18 gpm
LB5-10XB
13 gpm
LB6-10XB
LB5-15XB
22 gpm
LB6-15XB
BLACKCOMB
OWNER'S MANUAL
LB5 Series
LB6 Series
System Tested and Certified by
NSF International against CSA
B483.1 and NSF/ANSI 55
for Disinfection
Performance, Class B
**
System
Rated Flow
LBH5-05XB
5.4 gpm
LBH6-05XB
LBH5-10XB
7.6 gpm
LBH6-10XB
LBH5-15XB
13 gpm
LBH6-15XB
LBH5-25XB
22 gpm
LBH6-25XB
LBH5-40XB
28 gpm
LBH6-40XB
LBH5 Series
LBH6 Series
LUMINOR - Standard Systems
Rated
System
System
Flow
LB4-02X
LBH4-05X
2
LB5-02X
LBH5-05X
gpm
LB6-02X
LBH6-05X
LB4-03X
LBH4-10X
3
LB5-03X
LBH5-10X
gpm
LB6-03X
LBH6-10X
LB4-06X
LBH4-15X
6
LB5-06X
LBH5-15X
gpm
LB6-06X
LBH6-15X
LB4-10X
LBH4-25X
11
LB5-10X
LBH5-25X
gpm
LB6-10X
LBH6-25X
LB4-15X
LBH4-40X
15
LB5-15X
LBH5-40X
gpm
LB6-15X
LBH6-40X
LB4-20X
21
LB5-20X
gpm
LB6-20X
Rated
Flow
5 gpm
10
gpm
15
gpm
25
gpm
40
gpm
Advertisement
Table of Contents
Related Manuals for Luminator BLACKOMB LB6-02 A Series
Summary of Contents for Luminator BLACKOMB LB6-02 A Series
- Page 1 BLACKCOMB OWNER’S MANUAL Operation & Installation Instructions LB4 Series LBH4 Series LB5 Series LBH5 Series LB6 Series LBH6 Series NSF/ANSI Standard 55 Class A NSF/ANSI Standard 55 Class B LUMINOR - Standard Systems Rated Rated System System System Tested and Certified by System Tested and Certified by Flow Flow...
- Page 2 Congratulations on purchasing this LUMINOR UV system. P a g e...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Safety Considerations ......................4 Before You Begin ........................ 4 Water Quality Parameters ....................5 Assembly ..........................6 System Sizing ........................8 Location ..........................8 Installation ......................... 9 System Preparation ......................12 Cleaning the Quartz Sleeve ....................12 Cleaning the UV Sensor .................... -
Page 4: Safety Considerations
Safety Considerations It is important that care is taken when operating and/or maintaining your system. Please read the instructions • The appliance is not to be used by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction. -
Page 5: Water Quality Parameters
• The system should be directly installed into a ground fault circuit interrupter (GFCI). If the use of an extension cord is required, the cord must be manufactured with a minimum of 16 gauge wire and care should be taken to avoid potential tripping hazards. •... -
Page 6: Assembly
Assembly Unpack the system and ensure all the components are included with the system. Your system is shipped with the following components: BLACKCOMB (Standard output lamp systems) LAMP KEY GLAND NUT CONTROLLER 320006 4.1 SYSTEMS O-RING RC-B4.01 5.1/6.1 SYSTEMS 300038 RC-B56.01 UV LAMP RL-210- “-02”... - Page 7 BLACKCOMB-HO (High output lamp systems) LAMP KEY GLAND NUT CONTROLLER 320006 4.1 SYSTEMS O-RING RCHO-B4.12 300038 (fits all units) 5.1/6.1 SYSTEMS UV LAMP RCHO-B56.12 RL-210HO “-05” series (fits all units) RL-330HO “-10” series RL-420HO “-15” series RL-600HO “-25” series RL-950HO “-40” series GLOW PLUG (BLACKCOMB units only)
-
Page 8: System Sizing
System Sizing All LUMINOR UV systems are rated for a specific flow rate in water that meets the quality param- eters on page 5. PLEASE NOTE that increasing the flow above this rating or disinfecting water that does not meet the quality parameters will decrease the dose and therefore compromise the efficacy of the system. -
Page 9: Installation
Installation Step 1: The reactor can be installed either horizontally or vertically using the clamps provided. Vertical installation is the preferred method with the inlet at the bottom (lamp connection at the top) as it allows any air that may be in the lines to be easily purged from the system. - Page 10 Step 6: Once the system has been plumbed in, gently remove the quartz sleeve from its packaging being careful not to touch the length with your hands. The use of cotton gloves is recommended for this pro- cedure as oils from the hands can leave residue on the sleeve and lamp which can ultimately block the UV light from getting to the water.
- Page 11 Step 11: Always hold UV lamps by their ceramic ends, not by the lamp quartz. Remove the lamp from its packaging. Again, the use of cotton gloves is recommended. Remove the lamp key from the lamp’s connector and set it aside for the next step. Be careful to not touch the key’s exposed contacts.
-
Page 12: System Preparation
System Preparation With a new installation, or any time the UV system is shut down for service, without power, or is inoperative for any other reason, the lines in the home or facility could be contaminated. Use the following steps to prepare the lines throughout the entire home or facility. Step 1: Check for and remove any “dead ends”... -
Page 13: Cleaning The Uv Sensor
Step 10: Dry the sleeve with separate cloth. Step 11: Replace the o-ring and slide the sleeve back into the reactor following steps 7 and 8 from the installation section of the manual. Cleaning the UV Sensor Depending on the water quality, the UV sensor may require periodic cleaning. At a minimum, the UV sensor should be cleaned on an annual basis. -
Page 14: Blackcomb 4.1 Controllers
BLACKCOMB Controllers Simplistic in operation, these systems feature a tri-colour LED that indicating system status and a 4-digit display to in- dicate lamp life remaining. Pressing the button will change the display to indicate total running time. When the UV lamp is on and within its operating age, the LED will be green. -
Page 15: Blackcomb 5.1 Operational Screens
A final module screen is displayed showing which specific modules were initialized. The controller then displays the lamp optimization screen for 60 seconds to allow the lamp to reach its optimum output. Finally, a final “start-up complete” screen is displayed. The system will now be ready to disinfect water flow. -
Page 16: Lamp Countdown Sequence
audible chirp every audible chirp every constant audible cycles with red low 15 seconds 15 seconds alarm UV screen Lamp Countdown Sequence The system counts down the number of days until a lamp change is required. BLACKCOMB BLACKCOMB BLACKCOMB At thirty days remaining, the LED or display screen will change to a yellow caution indicator. At seven days remaining, the system will additionally repeat an audible chirp. -
Page 17: System Service Suggested
System Service Suggested BLACKCOMB 5.1 & 6.1 controllers will display the System Service Suggested Screen every 6 months to remind consumers to maintain both their UV and other prefiltration. This will serve as a prompt only and will not put the system into alarm. -
Page 18: System Troubleshooting
System Troubleshooting Hard Alarms: The following give a constant audible alarm. If present, the solenoid valve is closed, and the 4-20, remote alarm and wifi modules transmit the alarm. System Display Problem Resolution Reset lamp protection circuit -unplug unit for 10 seconds. The system has detected Replace the lamp with the a problem with the... - Page 19 Soft Alarms: The following remaining errors give a 15 second audible chirp only System Display Problem Resolution Ensure all modules are connected properly to the system and to each other. The module Modules can be tested indicated is no longer individually by plugging in communicating to with one at a time and cycling...
-
Page 20: Temperature Management Devices
Temperature Management Devices Your LUMINOR BLACKCOMB system is designed to run continuously to ensure optimal disinfection . However, during periods when no water is drawn through the system, the energy from the disinfection process can cause the temperature of the water inside the chamber to rise. - Page 21 SOLENOID CONNECTION MODULE: Connects a NORMALLY CLOSED line voltage solenoid valve to the controller. Maximum contact rating is 240VAC (50-60Hz) / 30VDC / 2A. On a non-monitored sys- tem, the solenoid will only close on a lamp fail- ure error. On a monitored system, the solenoid is closed when the UV level drops below 50%.
-
Page 22: Blackcomb Standard Output System Specifications
BLACKCOMB Standard Output System Specifications LUMINOR EQUIPMENT SPECIFICATIONS Residential systems (standard output lamps) Multi-Use / LB4-02X LB4-03X LB4-06X LB4-10X LB4-15X LB4-20X MODEL LB5-02X LB5-03X LB5-06X LB5-10X LB5-15X LB5-20X LB6-02X LB6-03X LB6-06X LB6-10X LB6-15X LB6-20X 1.6 gpm 2.2 gpm 3.4 gpm 6.3 gpm 7.9 gpm NSF Class A Flow Rate... -
Page 23: Blackcomb-Ho High Output System Specifications
BLACKCOMB-HO High Output System Specifications LUMINOR EQUIPMENT SPECIFICATIONS Residential Crossover systems (high output lamps) LBH4-05X LBH4-10X LBH4-15X LBH4-25X LBH4-40X MODEL LBH5-05X LBH5-10X LBH5-15X LBH5-25X LBH5-40X LBH6-05X LBH6-10X LBH6-15X LBH6-25X LBH6-40X 2.2 gpm 4.0 gpm 5.4 gpm 7.9 gpm 18 gpm NSF Class A Flow Rate 40mJ/cm @ 70% UVT... -
Page 24: Performance Data Sheet (On All Nsf/Ansi Standard 55, Class A Systems)
Performance Data Sheet (on all NSF/ANSI Standard 55, Class A Systems) System Tested and Certified by NSF International against CSA B483.1 and NSF/ANSI 55 for Disinfection Performance, Class A LB6-02XA LB6-03XA Model LB6-06XA LB6-10XA LB6-15XA LBH6-05XA LBH6-10XA LBH6-15XA LBH6-25XA LBH6-40XA LB6-02A-12V LB6-03A-12V LB6-02A-24V... -
Page 25: Performance Data Sheet (On All Nsf/Ansi Standard 55, Class B Systems)
Performance Data Sheet (on all NSF/ANSI Standard 55, Class B Systems) System Tested and Certified by NSF International against CSA B483.1 and NSF/ANSI 55 for Disinfection Performance, Class B LB5-06XB LB5-10XB LB5-15XB LBH5-05XB LBH5-10XB LBH5-15XB LBH5-25XB LBH5-40XB Model LB5-03XB LB6-06XB LB6-10XB LB6-15XB LBH6-06XB... -
Page 26: Limited Warranty Statement
Limited Warranty Statement: Products manufactured by LUMINOR Environmental Inc., (LUMINOR) are warranted to the origi- nal user only to be free of defects in material and workmanship for a period as specified below. This warranty only applies to the original purchaser and is not transferable. UV SYSTEMS Ten (10) year Limited Warranty on the stainless steel reactors, from the date of original purchase, or installation (proper documentation required for verification). -
Page 27: Warranty Registration
TO GET WARRANTY SERVICE To obtain service under this warranty, you must first contact where the product was originally purchased to obtain a Warranty Return Authorization. You will require proof of purchase and installation date, failure date, and any other requested data. Unless otherwise provided, the Dealer or Distributor will contact LUMINOR for instructions on returning the product. - Page 28 illuminating technologies for life 80 Southgate Drive, Unit 4 Guelph, Ontario, CANADA N1G 4P5 P: 519-837-3800 TF: 855-837-3801 F: 519-837-3808 info@luminoruv.com www.luminoruv.com PN: 910001 Version Date: 03-2023...
