Washing Machine
WMY 50831 YW2
User's Manual
Document Number
2820524474_EN/
13-01-15.(16:36)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WMY 50831 YW2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Beko WMY 50831 YW2

  • Page 1 Washing Machine WMY 50831 YW2 User’s Manual Document Number 2820524474_EN/ 13-01-15.(16:36)
  • Page 2 This product was manufactured using the latest technology in environmentally friendly conditions.
  • Page 3: General Safety Instructions

    General safety instructions This section includes security instructions which may help prevent the injuries and material damage risks. All kinds of warranties shall be invalid if these instructions are not observed. 1.1 Life and property safety Never place the product on a carpet-covered floor. Electrical parts will get overheated since air cannot circulate from under the device.
  • Page 4: Electrical Safety

    Do not forget to close the loading door when leaving the room where the product is located. store all detergents and additives in a safe place away from the reach of the children by closing the cover of the detergent container or sealing the detergent package.
  • Page 5: Important Instructions For Environment

    Important instructions for environment 2.1 Compliance with WEEE Directive This product complies with EU WEEE Directive (2012/19/EU). This product bears a classification symbol for waste electrical and electronic equipment (WEEE). This product has been manufactured with high quality parts and materials which can be reused and are suitable for recycling.
  • Page 6: Technical Specifications

    Complying Commission Delegated Regulation (EU) No 1061/2010 Supplier name or trademark Beko Model name WMY 50831 YW2 Rated capacity (kg) Energy efficiency class / Scale from A+++ (Highest Efficiency) to D (Lowest Efficiency) Annual Energy Consumption (kWh) Energy consumption of the standard 60°C cotton programme at full load (kWh) 0.743...
  • Page 7: Appropriate Installation Location

    4.1 Installation • Apply to the nearest authorized service agent for the installation of your product. • Preparation of the location and electrical, tap water and waste water installations at the place of installation is under customer's responsibility. • Make sure that the water inlet and discharge hoses as well as the power cable are not folded, pinched or crushed while pushing the product into its place after installation or cleaning procedures.
  • Page 8: Connecting Water Supply

    4.1.4 Connecting water supply The water supply pressure required to run the product is between 1 to 10 bars (0.1 – 1 MPa). It is necessary to have 10 – 80 liters of water flowing from the fully open tap in one minute to have your machine run smoothly. Attach a pressure reducing valve if water pressure is higher.
  • Page 9: Adjusting The Feet

    4.1.6 Adjusting the feet CAUTION: In order to ensure that the product operates more silently and vibration-free, it must stand level and balanced on its feet. Balance the machine by adjusting the feet. Otherwise, the product may move from its place and cause crushing and vibration problems.
  • Page 10: Preparing Laundry For Washing

    4.2 Preparation 4.2.1 Sorting the laundry * Sort laundry according to type of fabric, color, and degree of soiling and allowable water temperature. * Always obey the instructions given on the garment tags. 4.2.2 Preparing laundry for washing • Laundry items with metal attachments such as, underwired bras, belt buckles or metal buttons will damage the machine.
  • Page 11: Using Detergent And Softener

    4.2.6 Using detergent and softener When using detergent, softener, starch, fabric dye, bleacher and decolorant, descaling agents; read the manufacturer's instructions written on the package and follow the dosages specified. Use measuring cup if available. The detergent drawer is composed of three compartments: –...
  • Page 12 Using liquid detergents If the product contains a liquid detergent cup: • Put the liquid detergent container into the compartment no “2”. • If the liquid detergent lost its fluidity, dilute it with water before putting it into the detergent container.
  • Page 13: Tips For Efficient Washing

    4.2.7 Tips for efficient washing Clothes Light Colours and Black/Dark Delicates/ Colours Whites Colours Woolens/Silks (Recommended (Recommended (Recommended temperature (Recommended temperature range temperature range based temperature range range based on soiling level: based on soiling level: cold -40 on soiling level: cold based on soiling 40-90 level: cold -30...
  • Page 14: Operating The Product

    4.3 Operating the product 4.3.1 Control panel 1 - Programme Selection knob (Uppermost position On 5 - Start / Pause button / Off) 6 - Auxiliary Function buttons 2 - Display 7 - Spin Speed Adjustment button 3 - Delayed Start button 8 - Temperature Adjustment button 4 - Programme Follow-up indicator 4.3.2 Programme selection...
  • Page 15 • Cotton Economic Use to wash your normally soiled, durable cotton and linen laundry. Although it washes longer than all other programmes, it provides high energy and water savings. Actual water temperature may be different from the stated wash temperature. When you load the machine with less laundry (e.g. ½ capacity or less), programme time may automatically get shorter.
  • Page 16: Temperature Selection

    4.3.4 Temperature selection Whenever a new programme is selected, the recommended temperature for the selected programme appears on the temperature indicator. To decrease the temperature, press the Temperature Adjustment button. Temperature will decrease gradually. If the programme has not reached the heating step, you can change the temperature without switching the machine to Pause mode.
  • Page 17: Programme And Consumption Table

    4.3.6 Programme and consumption table Auxiliary functions Programme Temperature 2.25 1600 • • • • Cold-90 Cottons 1.45 1600 • • • • Cold-90 0.85 1600 • • • • Cold-90 60** 0.74 1600 • 40-60 Cotton Economic 60** 0.69 1600 •...
  • Page 18: Auxiliary Function Selection

    4.3.7 Auxiliary function selection Select the desired auxiliary functions before starting the programme. Whenever a programme is selected, if a relevant auxiliary function is selected its related indicator light will illuminate. Indicator lights of the auxiliary functions that are not allowed to be selected with the current programme will flash and an audio warning is given.
  • Page 19: Starting The Programme

    At the end of the countdown, duration of the selected programme will be displayed. “_” symbol will disappear and the selected programme will start. Changing the Delayed Start period If you want to change the time during countdown: Press Delayed Start button. Time will increase by 1 hour each time you press the button. If you want to decrease the delayed start time, press Delayed Start button repeatedly until the desired delayed start time appears on the display.
  • Page 20 4.3.12 Child Lock Use Child Lock function to prevent children from tampering with the machine. Thus you can avoid any changes in a running programme. If the Programme Selection knob is turned when the Child Lock is active, “Con” appears on the display. The Child Lock does not allow any change in the programmes and the selected temperature, speed and auxiliary functions.
  • Page 21: Maintenance And Cleaning

    4.4 Maintenance and cleaning Service life of product extends and frequently experienced problems will be reduced if it is cleaned at regular intervals. 4.4.1 Cleaning the detergent drawer Clean the detergent drawer at regular intervals (every 4-5 washing cycles) as shown below in order to prevent accumulation of powder detergent in time.
  • Page 22: Cleaning The Body And Control Panel

    4.4.3 Cleaning the body and control panel Wipe the body of the machine with soapy water or non-corrosive mild gel detergents as necessary, and dry with a soft cloth. Use only a soft and damp cloth to clean the control panel. 4.4.4 Cleaning the water intake filters There is a filter at the end of each water intake valve at the rear of the machine and also at the end of each water intake hose where they are connected to the tap.
  • Page 23 In order to clean the dirty filter and discharge the water: 1 Unplug the machine to cut off the supply power. CAUTION: Temperature of the water inside the machine may rise up to 90 ºC. To avoid the burning risk, clean the filter after the water inside the machine is cooled down.
  • Page 24: Troubleshooting

    Troubleshooting Problem Reason Solution Program does not start after Start / Pause / Cancel button was not pressed. Š *Press the Start / Pause / Cancel button. closing the door. Programme cannot be started or Washing machine has switched to self protection Š...
  • Page 25 Problem Reason Solution Programme time does not Timer may stop during water intake. Š Timer indicator will not countdown until the countdown. (On models with machine takes in adequate amount of water. The display) (*) machine will wait until there is sufficient amount of water to avoid poor washing results due to lack of water.
  • Page 26 Problem Reason Solution It does not rinse well. The amount, brand and storage conditions of the Š Use a detergent appropriate for the washing detergent used are inappropriate. machine and your laundry. Keep detergents closed in an environment free of humidity and do not expose them to excessive temperatures.
  • Page 27 Problem Reason Solution Laundry remains wet at the end of Excessive foam might have occurred and automatic Š Use recommended amount of detergent. the programme. (*) foam absorption system might have been activated due to too much detergent usage. (*) Machine does not switch to spinning step when the laundry is not evenly distributed in the drum to prevent any damage to the machine and to its surrounding environment.
  • Page 31 ‫راه حل‬ ‫علت‬ ‫مشکل‬ ‫کف از کشوی شوینده باال‬ ‫1 قاشق غذا خوری نرم کننده و نیم لیتر‬ .‫مقدار ماده شوینده استفاده شده بیش از حد بوده است‬ Š ‫آب را مخلوط کنید و در بخش شستشوی اصلی‬ .‫می زند‬ .‫کشوی...
  • Page 32 ‫راه حل‬ ‫علت‬ ‫مشکل‬ ‫البسه بعد از شسته شدن‬ ‫اگر سختی آب باالتر باشد، استفاده کردن از‬ .‫• از مقدار شوینده ناکافی استفاده شده است‬ Š ‫ماده شوینده ناکافی باعث می شود که البسه در‬ )**( .‫سخت می شوند‬ ‫طول زمان سفت شوند. از مقدار شوینده مناسب‬ .‫بر...
  • Page 33 ‫راه حل‬ ‫علت‬ ‫مشکل‬ :‫عملکرد شستشو خوب نیست‬ ‫از مقدار توصیه شده شوینده مناسب برای‬ .‫• از مقدار شوینده ناکافی استفاده شده است‬ Š .‫سختی آب موجود و البسه استفاده کنید‬ ‫لکه باز هم وجود دارد و‬ ‫بار اضافی در ماشین نگذارید. دستگاه را‬ .‫بار...
  • Page 34 ‫راه حل‬ ‫علت‬ ‫مشکل‬ ‫زمان شستشو بیشتر از زمان‬ ‫دستگاه تا دریافت مقدار آب مورد نیاز‬ .‫• فشار آب کم است‬ Š ‫برای جلوگیری از شستشوی نامناسب بخاطر‬ ‫تعیین شده در دفترچه راهنما‬ ‫کاهش مقدار آب، صبر می کند. بنابراین، زمان‬ )*(.‫به...
  • Page 35 ‫یبای بیع و داریا‬ ‫راه حل‬ ‫علت‬ ‫مشکل‬ ‫پس از بستن در برنامه شروع‬ ‫*دکمه های شروع / مکث / لغو، را فشار‬ .‫دکمه های شروع / مکث / لغو، فشار داده نشد‬ Š .‫دهید‬ .‫به کار نمی کند‬ ‫برنامه را نمی توان آغاز کرد‬ ‫برای...
  • Page 36 :‫برای تمیز کردن فیلتر کثیف و تخلیه آب موارد زیر را انجام دهید‬ .‫1 دوشاخه دستگاه را بیرون بکشید تا برق دستگاه قطع شود‬ ‫احتیاط: درجه حرارت آب داخل دستگاه ممکن است تا 09 درجه سانتی گراد برسد. برای جلوگیری از خطر‬ .‫سوختگی،...
  • Page 37 ‫4.4.4 تمیز کردن فیلترهای ورودی آب‬ ‫یک عدد فیلتر در انتهای هر کدام از شیرهای آب در پشت ماشین و همچنین در هر کدام از شیلنگهای ورود آب در محلی‬ ‫که به شیر وصل شده اند، وجود دارد. این فیلترها از ورود مواد خارجی و خاک به ماشین لباس شویی جلوگیری بعمل می‬ .‫آورند.
  • Page 38 ‫4.4 نگهداری و تمیز کردن‬ .‫عمر مفید دستگاه و مسائلی که معموال بوجود می آید با تمیز نگاه داشتن دستگاه با فواصل معین بهبود می یابد‬ ‫1.4.4 نگهداری و تمیز کردن کشوی ماده شوینده‬ ‫کشوی ماده شوینده را در فواصل زمانی منظم )هر 4 تا 5 بار شستشو( به صورتی که در‬ ‫زیر...
  • Page 39 ‫31.3.4 انصراف از برنامه‬ ‫برای لغو برنامه، دکمه انتخاب برنامه را بچرخانید تا برنامه دیگری را انتخاب کنید. برنامه قبلی لغو خواهد شد. چراغ‬ .‫پایان/لغو به صورت ممتد روشن باقی می ماند تا لغو شدن برنامه را اعالم نماید‬ .‫هنگامی که دکمه انتخاب برنامه را بچرخانید، برنامه پایان خواهد یافت، با این حال آب داخل را تخلیه نخواهد کرد‬ ‫هنگامی...
  • Page 40 ‫2.11.3.4 عوض کردن عملکرد کمکی ، سرعت و برنامه‬ ‫با توجه به مرحله ای که برنامه رسیده است ، شما می توانید عملکردهای کمکی را انصراف داده یا انتخاب کنید. انتخاب‬ ‫عملکرد کمکی‬ »‫می توانید تنظیمات سرعت و درجه حرارت را هم تغییر دهید؛ به «انتخاب سرعت چرخش» و «انتخاب درجه حرارت‬ .‫مراجعه...
  • Page 41 ‫8.3.4 زمان خاتمه‬ ‫شروع تاخیری‬ ‫با عملکرد شروع تاخیری شروع برنامه ممکن است 91 ساعت تاخیر داشته باشد. زمان شروع تاخیری را می توان با‬ .‫فواصل 1 ساعته افزایش داد‬ ‫ )شروع تاخیری( استفاده نکنید! این کار خطر‬Delayed Start ‫از ماده شوینده مایع هنگام فعال بودن‬ .‫لکه...
  • Page 42 ‫7.3.4 انتخاب عملکرد کمکی‬ .‫عملکردهای کمکی دلخواه را قبل از شروع برنامه انتخاب کنید‬ ‫هرموقع که برنامه ای انتخاب می شود، اگر عملکرد کمکی مربوط انتخاب شده باشد ، چراغ نشانگر مربوط روشن می‬ .‫شود‬ ‫چراغ های نشانگر عملکردهای کمکی که مجاز نیستند با برنامه فعلی انتخاب بشوند چشمک خواهند زد و‬ .‫هشدار...
  • Page 43 .‫عملکردهای کمکی در جدول ممکن است بر اساس مدل دستگاه شما متفاوت باشد‬ ،‫مصرف آب و برق و طول برنامه ممکن است با جدول نمایش داده شده متفاوت باشد که این موضوع به فشار آب‬ ‫سختی و درجه حرارت آب، درجه حرارت محیط، نوع و مقدار لباس، انتخاب عملکردهای کمکی، سرعت چرخش و‬ .‫تغییرات...
  • Page 44 ‫وظيفة مساعدة‬ ‫درجة الحرارة‬ ‫برنامه‬ -90‫بارد‬ • • • • 1600 2.25 ‫کتاتی‬ -90‫بارد‬ • • • • 1600 1.45 -90‫بارد‬ • • • • 1600 0.85 40-60 • 1600 0.74 60** ‫نخی اکونومی‬ 40-60 • 1600 0.69 60** 40-60 •...
  • Page 45 ‫• چرخش + پمپ‬ .‫از این برنامه برای تخلیه آب دستگاه استفاده کنید‬ ‫4.3.4 انتخاب درجه حرارت‬ .‫هنگامی که یک برنامه جدید انتخاب شد، درجه حرارت توصیه شده برنامه در نشانگر درجه حرارت ظاهر می شود‬ ‫" )تنظیم درجه حرارت( را فشار دهید. درجه‬Temperature Adjustment" ‫برای کاهش درجه حرارت، دکمه‬ .‫حرارت...
  • Page 46 ‫• نخی اکونومی‬ ‫از این برنامه برای شستن البسه کثیف مقاوم نخی و پنبه ای استفاده کنید. اگرچه دستگاه لباسها را نسبت به تمام برنامه‬ ‫های دیگر طوالنی تر می شوید، صرفه جویی در مصرف آب و برق آن بسیار باال می باشد. درجه حرارت واقعی آب‬ ‫ممکن...
  • Page 47 ‫3.4 استفاده از محصول‬ ‫1.3.4 پانل کنترل‬ (‫1- دکمه انتخاب برنامه )باالترین وضعیت روشن/خاموش‬ ‫2- نمایشگر‬ ‫3- دکمه شروع تاخیری‬ ‫4- نشانگر پیگیری برنامه‬ ‫5- دکمه شروع/مکث‬ ‫6- دکمه های مخصوص کارکردهای کمکی‬ ‫7- دکمه تنظیم سرعت چرخش‬ ‫8- دکمه تنظیم درجه حرارت‬ ‫2.3.4 انتخاب...
  • Page 48 ‫7.2.4 نکته هایی برای شستشوی خوب و موثر‬ ‫لباسها‬ /‫لباسهای ظریف‬ ‫رنگ های سیاه/تیره‬ ‫رنگها‬ ‫رنگ های روشن و سفیدها‬ ‫پشمی/ابریشمی‬ ‫)میزان درجه‬ ‫)میزان درجه حرارت‬ ‫)میزان درجه حرارت توصیه‬ ‫)محدوده درجه حرارت توصیه‬ ‫حرارت توصیه‬ ‫توصیه شده مطابق‬ :‫شده مطابق کثافت‬ 40- ‫شده...
  • Page 49 ‫استفاده کردن از مواد شوینده مایع‬ :‫اگر دستگاه دارای پیمانه شوینده مایع است‬ ‫محفظه مواد شوینده مایع را در قسمت «2» قرار‬ • .‫دهید‬ ‫اگر شوینده مایع غلیظ شده باشد، آن را قبل از ریختن‬ • .‫در پیمانه شوینده مایع با آب رقیق کنید‬ :‫اگر...
  • Page 50 ‫هشدار: لطفا از اطالعات موجود در "جدول برنامه و مصرف" پیروی کنید. هنگامی که بار بیش از حد در‬ ‫دستگاه قرار داده شود، عملکرد ماشین لباسشویی کاهش خواهد یافت. بعالوه، سر و صدا و لرزش هم ممکن است‬ .‫ایجاد شود‬ ‫6.2.4 استفاده...
  • Page 51 ‫2.4 آماده سازی‬ ‫1.2.4 مرتب کردن رخت ها‬ .‫* البسه را بر اساس نوع پارچه، رنگ، میزان لکه دار بودن و درجه حرات مجاز آب تفکیک کنید‬ .‫* همیشه از دستورالعمل های ارائه شده در برچسب های لباس پیروی کنید‬ ‫2.2.4آماده...
  • Page 52 ‫6.1.4 تنظیم کف ماشین‬ ‫احتیاط: برای اطمینان از اینکه دستگاه بی صدا کار می کند و بدون لرزه است، باید آن را روی یک سطح صاف‬ ‫قرار داد و دستگاه را باالنس نمود. دستگاه را با تنظیم پایه ها باالنس کنید. در غیر این صورت دستگاه ممکن‬ .‫است...
  • Page 53 ‫4.1.4 اتصال آب مصرفی‬ ‫(. در عمل باید‬MPa 1 – 0.1) ‫فشار تامین آب مورد نیاز برای شروع به کار ماشین بین 1 تا 01 آتمسفر است‬ ‫بین 01-08 لیتر آب در دقیقه از شیر کامال باز جاری شود تا دستگاه شما روان کار کند. در صورتی که فشار آب‬ .‫باالتر...
  • Page 54 ‫1.4 نصب‬ .‫• برای نصب به نزدیک ترین سرویس مجاز نصب این محصول مراجعه شود‬ .‫• آماده کردن محل و جریان برق و شیر آب و نصب لوله آب مواد زائد در محل نصب با مسئولیت مشتری است‬ ، ‫• مطمئن شوید که لوله های خرطومی ورودی و خروجی بعد از نصب و قرار دادن و عملیات تمیز کردن تا نخورده‬ .‫پیچیده...
  • Page 55 2010/1061 ‫مقررات پیروی از کمیسیون منتخب (اتحادیه اروپا) شماره‬ ‫نام یا عالمت اختصاری شرکت تامین کننده‬ Beko ‫نام مدل‬ WMY 50831 YW2 (‫ظرفیت تائید شده )کیلوگرم‬ ‫ )پائین ترین‬D ‫+++ )باالترین کارآیی انرژی( تا‬A ‫طبقه بندی صرفه جویی در انرژی / مقیاس از‬ (‫کارآیی انرژی‬...
  • Page 56 ‫دستورالعملهای مهم برای محیط زیست‬ WEEE ‫1.2 هماهنگی با راهنمایی های‬ ‫(. مطابقت دارد. این محصول دارای عالمت گروه بندی ویژه‬EU WEEE (2012/19/EU ‫این محصول با راهنمای‬ .(WEEE) ‫تجهیزات برقی و الکترونیکی می باشد‬ ‫این دستگاه با قطعاتی با باالترین کیفیت ساخته شده است و می توان این مواد را برای باز یافت مورد استفاده قرار داد. این‬ ‫دستگاه...
  • Page 57 ‫کلیه مواد شوینده و مواد افزودنی را در مکانی امن دور از دسترس کودکان قرار دهید‬ .‫و در ظرف شوینده یا بسته مواد شوینده را ببندید‬ ‫3.1 ایمنی الکتریکی‬ ‫اگر دستگاه خراب شد تا زمانی که توسط نماینده مجاز سرویس تعمیر نشود نباید با‬ !‫دستگاه...
  • Page 58 ‫دستورالعمل های ایمنی عمومی‬ ‫این قسمت شامل دستورالعمل های ایمنی است که از وارد شدن آسیب و جراحت و آسیب‬ ‫مادی جلوگیری می کند. در صورت رعایت این اصول ایمنی، کلیه ضمانت ها معتبر‬ .‫خواهند بود‬ ‫1.1 عمر وایمنی دستگاه‬ ‫هرگز...
  • Page 59 .‫این محصول با استفاده از آخرین فناوری ها در شرایط دوستدار محیط زیست ساخته شده است‬...
  • Page 60 ‫ماشین لباسشویی‬ WMY 50831 YW2 ‫دفترچه راهنمای کاربر‬ 2820524474_FA/ ‫شماره سند‬ 19-01-15.(10:51)
