Ra ilw a y Eq uip me nt C omp an y
MODEL 520603-2V150
and 520603-2V151
VOLTAGE MONITOR
The Cragg Railcharger® Battery Voltage Monitor is
a free standing unit that features the ability to
monitor two DC voltage sources and has optional
temperature and current monitoring ability.
CRAGG RAILCHARGER
Instruction Manual for Digital
Voltage Monitor
Installation, Operation & Maintenance
15400 Medina Rd.
Plymouth, MN 55447
(763) 972-2200
(763) 972-2900 Fax
E-mail: mail@rwy.com
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CRAGG RAILCHARGER 520603-2V150 and is the answer not in the manual?

Questions and answers

Summary of Contents for RECO CRAGG RAILCHARGER 520603-2V150

  • Page 1 Ra ilw a y Eq uip me nt C omp an y Installation, Operation & Maintenance MODEL 520603-2V150 and 520603-2V151 VOLTAGE MONITOR The Cragg Railcharger® Battery Voltage Monitor is a free standing unit that features the ability to monitor two DC voltage sources and has optional temperature and current monitoring ability.
  • Page 2: Table Of Contents

    Voltage Monitor – Instruction Manual Model 520603-2V150 Table of Contents 1. WARNINGS, CAUTIONS, AND NOTES ..................1 2. FEATURES ............................. 2 2.1 The standard features of the Voltage Monitor are listed as follows: ..........2 2.2 Optional Features: ........................2 3.
  • Page 3: Warnings, Cautions, And Notes

    Voltage Monitor – Instruction Manual Model 520603-2V150 1. WARNINGS, CAUTIONS, AND NOTES Please read the entire instruction manual before using the voltage monitor. Also, read the warnings, cautions, and notes in Table 1. Failure to observe the warnings and cautions can lead to equipment damage or personal injury. If you have any questions concerning the manufacture, design, function, installation, operation or maintenance, contact Railway Equipment Company before proceeding.
  • Page 4: Features

    Voltage Monitor – Instruction Manual Model 520603-2V150 2. FEATURES 2.1 The standard features of the Voltage Monitor are listed as follows: • Two Channel Battery Voltage Monitor with form C Relay Outputs • Model 520603-2V150 is the standard model and does not include an Ethernet port •...
  • Page 5: Operation

    Voltage Monitor – Instruction Manual Model 520603-2V150 3. OPERATION The model 520603-2V150 voltage monitor is equipped to monitor up to two DC voltage sources. The unit is powered by the voltage source that it monitors on channel 1. The channel 1 voltage range is 10 to 48 VDC.
  • Page 6: Digital Display

    Voltage Monitor – Instruction Manual Model 520603-2V150 4.1 Digital Display The idle screen displays the input voltage. If only channel 1 has input voltage, only channel 1 will be displayed. If both channels are monitoring voltage sources, both will be displayed. If the optional current or temperature probes are being used, the lower screen will alternate between displaying channel 2 voltage, temperature, and current.
  • Page 7 Voltage Monitor – Instruction Manual Model 520603-2V150 LOW AMP SET ___ - Amp setting below which channel 2 will trip. Amp range is -120 to +120 amps. Factory default is -120 amps. There is also an optional temperature probe that can control the channel 2 output. If the probe is used, the temperature can be displayed as Fahrenheit or Celsius.
  • Page 8: Push Buttons

    Voltage Monitor – Instruction Manual Model 520603-2V150 4.2 Push Buttons Below the digital display are three control push buttons: INCREASE – This is used to increase the value of the displayed parameter, if enabled. DECREASE – This button will decrease the value of the displayed parameter, if enabled. MODE –...
  • Page 9: Temperature Sensor

    Voltage Monitor – Instruction Manual Model 520603-2V150 4.6 Temperature Sensor On the top of the monitor case is a temperature sensor jack. The temp sensor is an optional thermocouple that can be placed to monitor battery, equipment, or air temperature. By setting the temp parameters, the temperature level can be used to trigger a fault condition on channel 2, either independently, or in conjunction with channel 2 voltage, and/or with the current sensor.
  • Page 10: History Page

    Voltage Monitor – Instruction Manual Model 520603-2V150 5.2 History Page The History page shows any historical data that has been transmitted to our servers. The graph is interactive, which allows you to select specific date ranges, zoom in/out and add/remove data pens. Figure 3.
  • Page 11 Voltage Monitor – Instruction Manual Model 520603-2V150 DHCP IS ENABLED – Enable or Disable DHCP. By default this is set to Enabled, which will require the Voltage Monitor to acquire and IP address from a DHCP server. IP LB xxx… – Configures the first 3 digits of the IP address. This cannot be changed if DHCP is set to Enabled.
  • Page 12: Drawings

    Voltage Monitor – Instruction Manual Model 520603-2V150 PDNS LB xxx… – Configures the first 3 digits of the Primary DNS. This cannot be changed if DHCP is set to Enabled. PDNS HB . xxx.. – Configures the second 3 digits of the Primary DNS. This cannot be changed if DHCP is set to Enabled.
