Instructions - Parts
Agitator
Conversion Kit
For converting agitator 1.5.5B to 24K360. For professional use only.
Part 24K408
Important Safety Instructions
Read all warnings and instructions in this manual and
the Gusmer-Decker RC system manuals. Save all
instructions.
Contents
Related Manuals . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Remove Agitator 1.5.5B . . . . . . . . . . . . . . . . . . . . 2
Install Kit 24K408 Components . . . . . . . . . . . . . . 3
Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Graco Standard Warranty . . . . . . . . . . . . . . . . . . . . 6
Graco Information . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Related Manuals

Manuals are available at www.graco.com. Related manuals
listed are in English.
Gusmer-Decker RC Manuals
Part
Description
312750
Gusmer-Decker RC Operation
312751
Gusmer-Decker RC Repair and Parts
313264
Gusmer-Decker RC Electrical Diagrams
Get other manuals https://www.bkmanuals.com
Kit is shown assembled with agitator motor, gear
reducer, and tank lid for reference only
3A1931A
ENG
ti17565a

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 24K408 and is the answer not in the manual?

Questions and answers

Related Manuals for Graco 24K408

Summary of Contents for Graco 24K408

  • Page 1: Table Of Contents

    Graco Standard Warranty ....6 Graco Information ......6 Related Manuals Manuals are available at www.graco.com.

  • Page 2: Installation

    11. Remove four socket head cap screws (A06) then remove agitator housing (A07) and seal (A09) from tank lid. NOTE: Prior to beginning the Install Kit 24K408 Com- 2. Disconnect incoming power from agitator motor. ponents procedure, discard or set aside all items except those noted in F .

  • Page 3: Install Kit 24K408 Components

    Installation Install Kit 24K408 Components 4. Insert agitator shaft (13) through housings (4, 12) then use snap ring pliers to install snap ring (14) onto groove in shaft (13). 5. Rotate agitator shaft (13) so that flat spot for set A12◆...
  • Page 4 Installation NOTE: In the following step, the agitator shaft must be rotated by turning the gear reducer input sleeve shaft (A01a). Attempting to rotate the agitator shaft by rotating the agitator shaft itself will not work. This is due to the design of the gear reducer. See F .

  • Page 5: Parts

    SCREW, socket head set screw, 5/16-18 x 0.75 113500 ADHESIVE, anaerobic, 0.017 fl oz, 0.5 ml --- Not for sale. ti17568a ◆ Items are not included with kit 24K408. Shown for reference only. Technical Data See Gusmer-Decker RC system manual for technical data. 3A1931A...

  • Page 6: Graco Standard Warranty

    With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.
